IPC6512-Z30&6522-Z30&6622-Z30
V100R001C00

Installation Guide

Issue
02
Date
2014-12-25
HUAWEI TECHNOLOGIES CO., LTD.

Advertisement

Table of Contents
loading

Subscribe to Our Youtube Channel

Summary of Contents for Huawei IPC6512-Z30

  • Page 1: Installation Guide

    IPC6512-Z30&6522-Z30&6622-Z30 V100R001C00 Installation Guide Issue Date 2014-12-25 HUAWEI TECHNOLOGIES CO., LTD.
  • Page 2 All other trademarks and trade names mentioned in this document are the property of their respective holders. Notice The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope.
  • Page 3: About This Document

    About This Document About This Document Purpose This document describes the installation and operation of HD Network Speed dome. This document applies to the IPC6512-Z30, IPC6522-Z30, IPC6622-Z30 and IPC6512L-Z30. Intended Audience This document is intended for: Policy planning engineers Installation and commissioning engineers...
  • Page 4: Change History

    Change History Issue Date Description 2014-12-25 This is the first release. 2014-05-05 This issue is used for first office application (FOA). Issue 02 (2014-12-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 5: Table Of Contents

    4 Quick Operation..........................25 4.1 Accessing Instruction..............................25 4.2 Login.....................................25 5 Trouble Shooting.........................28 5.1 Device Exceptions................................28 5.2 PTZ Control Exceptions...............................28 5.3 Upgrade Exceptions..............................29 5.4 Other Questions................................29 A Lightning and Surge Protection....................31 Issue 02 (2014-12-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 6 B.1 Waterproof Instruction..............................34 B.2 L-shape Pole Mount..............................34 C Bubble Maintenance........................36 D Tables............................37 D.1 24VAC Wire Gauge & Transmission Distance......................37 D.2 Wire Gauge Standards..............................38 E Parts and Auxiliary Equipment Table..................39 Issue 02 (2014-12-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 7: Security Precautions

    The warranty does not cover any failure of the device due to improper transportation. Do not install the device upside down. Do not squeeze the device. Move the device chip gently. Issue 02 (2014-12-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 8 Products and services are subject to change without notice. l For the latest program and supplementary documentation, contact Huawei customer center. l For any questions about the camera, contact the sales person or Huawei customer center. l Huawei is not responsible for your misoperation.
  • Page 9: Installing Instruction

    Installation Guide 2 Installing Instruction Installing Instruction 2.1 Appearance The speed dome appearance is shown below: Figure 2-1 5-inch Speed Dome Appearance Figure 2-2 IR Speed Dome Appearance Issue 02 (2014-12-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 10: Cables

    Please refer to the labels attached on the cables for identification. Figure 2-3 Cables of Network Speed dome (PC6512-Z30 &IPC6522-Z30) Issue 02 (2014-12-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 11: Reset Button

    Reset button of 5-inch speed dome Lossen the screws on both sides of the speed dome and remove the lower dome. The position of the reset button is shown in Figure 2-5. Issue 02 (2014-12-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 12: Alarm Input And Output Connection

    Figure 2-6 Reset Button of IR Speed Dome 2.4 Alarm Input and Output Connection The network speed dome can be connected with alarm inputs (0~5 VDC) Refer to the following diagrams for alarm output: Issue 02 (2014-12-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 13 For DC power supply (left diagram), the input voltage must be no more than 30VDC, 1A. For AC power supply, the external relay must be used (right diagram) to prevent damages to the speed dome and avoid risk of electric shock. Issue 02 (2014-12-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 14: Installation

    When you unpack the dome, please keep the original package properly, in case of returning or repairing the camera, you can pack the dome with the package. NOTE The user should be responsible for any damage caused when transporting with unoriginal package. Issue 02 (2014-12-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 15: Outdoor Mounting

    Step 2 Drill 4 φ12 screw holes in the wall according to the hole locations of the mount, and then insert M8 expansion screws into the screw holes. Issue 02 (2014-12-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 16: Pole Mount Installation

    The components of pole mounting are show as follows. Wall Mount Figure 3-4 Wall Mount Pole Adapter A pole adapter has to be used together with a wall mount for pole mounting applications. Issue 02 (2014-12-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 17 Step 1 Assemble the pole adapter. l Loosen the three pole mounting hoops with a screwdriver. l Insert them through the rectangle holes of the pole adapter. Issue 02 (2014-12-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 18 Attach the gasket then wall mount to the pole adapter. l Secure the wall mount to the pole adapter with 4 hex screws and the spring washers. Issue 02 (2014-12-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 19: Speed Dome Installation

    When loosening the lock screws, keeps the speed dome being inverted. Otherwise the spacers of lock screws may drop into the speed dome. Step 3 Remove the protective lens cover, foam and sticker as shown in the following figure. Issue 02 (2014-12-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 20 Step 8 Align the speed dome with wall mount and rotate it counterclockwise or clockwise to the mount tightly as shown below. Figure 3-14 Align to the Mount Issue 02 (2014-12-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 21 Step 2 Remove the cover on the back of the speed dome as shown in Figure 3-17. Insert the SD card to the SD card slot and install the cover back. Issue 02 (2014-12-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 22 Step 4 Loosen the lock screws on the wall mount. Step 5 Align the speed dome with wall mount and rotate it counterclockwise or clockwise to the mount tightly as shown below. Issue 02 (2014-12-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 23: Indoor Mounting

    The survey of the actual installation environment and planning the wiring is highly recommended before the accurate deployment of the wire is implemented in order to provide a safe and steady power supply and a reasonable wiring route. Issue 02 (2014-12-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 24: Installing Speed Dome

    Step 1 Loosen the two lock screws to remove the lower dome. Remove the protective lens cover, foam and sticker from the dome drive. Attach lower dome to the back box, and rotate clockwise to secure it. Figure 3-21 Disassemble the Speed dome Issue 02 (2014-12-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 25 Push the speed dome into the mounting hole in the ceiling. Tighten the lock screws with the screwdriver and the locks will automatically rotate outwards to secure the in-ceiling mount to the ceiling. Issue 02 (2014-12-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 26: Ceiling Mounting

    It is required to modify the external structure of the in-ceiling mounting speed dome before the operation of ceiling mounting. Step 1 Remove the 4 screws on the back box by a Phillips screwdriver. Issue 02 (2014-12-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 27 The cables of dome can be routed either from the top or the side of the back box. For the cables routed from the top of the back box, it is required to drill a cable hole in the ceiling. Issue 02 (2014-12-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 28 Step 2 Secure the mounting base to the ceiling with set screws. Figure 3-30 Secure the Mounting Base Step 3 Install the speed dome to the mounting base. Issue 02 (2014-12-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 29: Pendant Mounting

    Step 4 Secure the mounting base by using nuts and washers to tighten the four expansion screws. Figure 3-32 Install the Mounting Base Issue 02 (2014-12-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 30: Installation Verification

    If the speed dome cannot be powered up, please check the connectors of the speed dome; if the connectors are connected correctly and firmly, please check the wiring cables. Issue 02 (2014-12-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 31: Quick Operation

    If you enter an incorrect password three consecutive times, your account gets locked. You must wait for five minutes to enter the login information. Issue 02 (2014-12-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 32 4-3. Click Please click here to download and install the plug-in. Close the browser when installing the plug-in, and install the plug-in as prompted. Figure 4-3 Download the plug-in Issue 02 (2014-12-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 33 It may ask you to close the web browser to install the plug-in. Please reopen the web browser and login again after the plug-in is successfully installed. ----End Issue 02 (2014-12-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 34: Trouble Shooting

    Check whether the diameter of the power wire meet the standards. For detailed correlation, please see "Table D" in the User Guide corresponding to the model of the speed dome. Issue 02 (2014-12-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 35: Upgrade Exceptions

    The frame rate value that specified by the ONVIF protocol can be considered as a value range. You can only set discrete value for the frame rate of the speed dome. The system will not return Issue 02 (2014-12-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 36 For example, if the frame rate is configured as 21fps, the actual frame rate validated by the device should be 20fps. Issue 02 (2014-12-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 37: A Lightning And Surge Protection

    4Ω. The sectional area of the grounding cable should be no less than 25mm2. For grounding instructions, please refer to the Installation Manual of Speed Dome. Issue 02 (2014-12-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 38: Grounding For Cement Pole/Wall Installation

    Because the signal transmission media of fiber optical speed dome and network speed dome are isolated from the control center, they must be grounded locally to protect dome against damages. Issue 02 (2014-12-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 39: Grounding For Metal Pole Installation

    If the fiber optics, lightening protector or other device are applied during the transmission of speed dome, such devices as well as the video cables routing through must be proper grounded. Issue 02 (2014-12-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 40: B Waterproof

    Make sure that the L-shape pole mount is designed with a certain inclination angle as shown in following figure. Water won't flow from the pole into the speed dome with the inclination angle. Issue 02 (2014-12-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 41 IPC6512-Z30&6522-Z30&6622-Z30 Installation Guide B Waterproof Figure B-1 Customized Mount Issue 02 (2014-12-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 42: Bubble Maintenance

    Step 2 Use oil free cotton cloth to wipe the bubble with alcohol or detergent. Step 3 Change the cloth to wipe the bubble until the bubble is clean. ----End Issue 02 (2014-12-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 43: D Tables

    90(27) 143(43) 362(110) 47(14) 75(22) 119(36) 301(91) 40(12) 64(19) 102(31) 258(78) 35(10) 56(17) 89(27) 226(68) 31(9) 50(15) 79(24) 201(61) 28(8) 45(13) 71(21) 181(55) 25(7) 41(12) 65(19) 164(49) Issue 02 (2014-12-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 44: Wire Gauge Standards

    Gauge AWG Gauge SWG Area of Bare Wire (mm2) 0.750 0.4417 0.800 0.5027 0.900 0.6362 1.000 0.7854 1.250 1.2266 1.500 1.7663 2.000 3.1420 2.500 4.9080 3.000 7.0683 Issue 02 (2014-12-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 45: E Parts And Auxiliary Equipment Table

    Table E-1 Parts and Auxiliary Equipment Table Suited Bracket IPC Model IPC6522-Z30&6512-Z30&6512L-Z30&6622-Z30 Wall Mounting Bracket ACC2204H-W Pendant Mounting Bracket ACC2205H-H Pole Mounting Bracket ACC2204H-W+ACC2206H-P Corner Mounting Bracket ACC2204H-W+ACC2207H-C Issue 02 (2014-12-25) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
