AQUA SZUT T-HEAD 550 Instruction Manual

Impeller pump

Advertisement

Quick Links

PL
INSTRUKCJA OBSŁUGI
T-HEAD
550 / 750
BUDOWA POMPY:
PL
1.Wężyk do napowietrzania Ø 4mm 2.Regulator
napowietrzania 3.Suwak 4.Wieszak na akwarium
5.Przyssawki 6.Wieszak 7.Silnik 8.Wirnik 9.Regulator
przepływu 10.Pokrywa wirnika 11.Nasadka napowie-
trzająca 12.Kruciec ssawny

PUMP CONSTRUCTION:

GB
1.Air hose Ø 4mm 2.Aeration regulator 3.Guide bar
4.Aquarium hanger 5.Vacuum cups 6.Hanger 7.Engine
8.Impeller 9.Water flow regulator 10.Impeller cover
11.Air cap 12.Suction connection
PUMPENBAU:
D
1.Lüftungsschlauch Ø 4mm 2.Lüftungsregler 3.Schie-
ber 4.Aquariumsaufhänger 5.Saugnäppchen 6.Au-
fhänger 7.Motor 8.Rotor 9.Durchflussregler 10.Rotor-
deckel 11.Lüftungsansatz 12.Saugstutzen
Dane techniczne / Technical data / Technische Daten
T-HEAD 550 / 750
Do akwariów o pojemności
40-150 l
Capacity of the aquarium
Bis zu Aquariumsgröße
Napięcie / częstotliwość
Voltage / Frequency
Spannung / Frequenz
Pobór mocy
4 W
Power consumption
Leistungsaufnahme
Max. wydajność filtra
550 l/h
Max. filter productivity
Max. Filterleistung
Max. głębokość napowietrzania
10 cm
Max. aeration depth
Max. Belüftungstiefe
Szczelność
Leak tightness
Dichtigkeit
1
GB
D
INSTRUCTION MANUAL
BEDIENUNGSANLEITUNG
80-200 l
230 V~ / 50 Hz
5,5 W
750 l/h
25 cm
IPX 8
rys. / pic. / abb.
2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T-HEAD 550 and is the answer not in the manual?

Questions and answers

Summary of Contents for AQUA SZUT T-HEAD 550

  • Page 1 1.Lüftungsschlauch Ø 4mm 2.Lüftungsregler 3.Schie- ber 4.Aquariumsaufhänger 5.Saugnäppchen 6.Au- fhänger 7.Motor 8.Rotor 9.Durchflussregler 10.Rotor- deckel 11.Lüftungsansatz 12.Saugstutzen Dane techniczne / Technical data / Technische Daten T-HEAD 550 / 750 Do akwariów o pojemności 40-150 l 80-200 l Capacity of the aquarium Bis zu Aquariumsgröße...
  • Page 2 T-HEAD - POMPA WIRNIKOWA Dla zachowania wysokiej sprawności urządzenia zaleca się przeprowadzanie regularnego czyszczenia wkładu filtrującego, wirnika i jego komory. Do tych celów nigdy nie należy stosować detergentów (mydła, płynów do mycia Zanurzenie robocze: naczyń itp.) oraz rozpuszczalników; resztki tych środków pozostałych w filtrze mogą powodować choroby i śnięcie - minimalne: górna krawędź...
  • Page 3 - It is forbidden to make any repairs or replacements of the power supply cord! - It is forbidden to use the pump without water. GUARANTEE TERMS AND CONDITIONS. AQUA-SZUT Sp. z o.o. with permanent establishment ul. Opolska 11/19 in Wrocław (52-010) is offering to the buyer a guarantee of correct - Install the unit following the instruction.
  • Page 4 Achtung durch das Verdampfen des Wasser sinkt der Wasserspiegel kontinuierlich ! Kontrollrevisionen und Wartung: Um die gute Funktionierung der Pumpe zu halten, wird regelmäßige Filtrierungseinsatz-, Rotor- und Rotorkammer- reinigung empfohlen. Zu diesem Zweck keine Reinigungsmittel (Seife, Geschirrspülmittel usw.) oder Lösungsmittel nutzen;...
