ANTI-VIBRATION TABLE
Part No. 304666011 – Rev C, September 2017
Thank you for purchasing the Adam AVT, we hope that you will be satisfied with your purchase, if you have any
questions concerning the assembly of your table then please contact your distributor or nearest Adam office,
details of which can be found on our website:
www.adamequipment.com
Advertisement
Summary of Contents for Adam Equipment ANTI-VIBRATION TABLE
- Page 1 Adam Equipment ANTI-VIBRATION TABLE Part No. 304666011 – Rev C, September 2017 Thank you for purchasing the Adam AVT, we hope that you will be satisfied with your purchase, if you have any questions concerning the assembly of your table then please contact your distributor or nearest Adam office, details of which can be found on our website: www.adamequipment.com...
- Page 2 AVT Assembly Instruction All fixings should be loosely fitted first and then firmly tightened when the table frame is assembled. This makes assembly easier. 1. Inner Frame Assembly: Step One: open the packing box, take out the top, middle and lower packing assemblies and the accessary bags, please locate the packing assemblies as Picture 1 shows.
- Page 3 Step Two: take out 2 x granite supporting rails (long), 2 x granite supporting rails (short) and accessory bag from lower packing. Fix them using four M8×40 screws with the Allen key that is in the accessory bag. Please see picture 2. Make sure the surfaces of rails are aligned and flat. Picture 2 Step Three: take out Inner side rail (left) from top packing and inner side rail (right) from middle packing, fix them using four M8×40 screws with the Allen key, see picture 3.
- Page 4 Picture 5: The position of granite Picture 6: Assembled inner frames 2. Outer Frame Assembly Take out the outer side rail (left) from top packing, table top assembly from middle packing and the outer side rail (right) from lower packing (as picture 7 shows). Fix them using four M8×40 screws. Then take out an outer table supporting rail (upper front) from the lower packing, and fix it with four M8 x 40 screws.
- Page 5 1 x Outer side rail (left) 1x Table top assembly 1 x Outer side rail (right) 1 x Outer table supporting rail 1x Inner granite supporting rail Ten M8 x 40 socket screws (upper front) (lower) Picture 8: Outer frame assembly drawing Picture 9: Assembled outer frames 3.
- Page 6 This product may include a rechargeable battery that is designed to be removed and replaced by the user. Adam Equipment warrants that it will provide a replacement battery if the battery manifests a defect in materials or workmanship during the initial period of use of the product in which the battery is installed.
- Page 7 ADAM EQUIPMENT is an ISO 9001:2008 certified global company with more than 40 years’ experience in the production and sale of electronic weighing equipment. Adam products are predominantly designed for the Laboratory, Educational, Health and Fitness, Retail and Industrial Segments. The product range can be described as follows: ‐Analytical and Precision Laboratory Balances ‐Compact and Portable Balances ‐High Capacity Balances ‐Moisture analysers / balances ‐Mechanical Scales ‐Counting Scales ‐Digital Weighing/Check‐weighing Scales ‐High performance Platform Scales ‐Crane scales ‐Mechanical and Digital Electronic Health and Fitness Scales ‐Retail Scales for Price computing For a complete listing of all Adam products visit our website at www.adamequipment.com Adam Equipment Co. Ltd. Adam Equipment Inc. AE Adam GmbH. Maidstone Road, Kingston 1, Fox Hollow Rd. Instenkamp 4 Milton Keynes 06478 D‐24242 Felde MK10 0BD Oxford, CT UK USA Germany Phone:+44 (0)1908 274545 Phone: +1 203 790 4774 Phone +49 (0)4340 40300 0 Fax: +44 (0)1908 641339 Fax: +1 203 792 3406 Fax: ...
- Page 8 ...
