- Page 1 ® EGE-UHD-HDB-EXT HDBaseT Receiver...
- Page 2 EGE-UHD-HDB-EXT HDBaseT Receiver...
-
Page 3: Copyright Notice
Geratech assumes no responsibility for any inaccuracies that may be contained in this document. Geratech also makes no commitment to update or to keep current the information contained in this document. - Page 4 EGE-UHD-HDB-EXT HDBaseT Receiver SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety...
-
Page 5: Table Of Contents
EGE-UHD-HDB-EXT HDBaseT Receiver CONTENTS 1. Introduction ........... 2. Applications .......... 1 3. Package Contents ........ 4. System Requirements ......5. Features ..........6.1 Transmitter Front and Rear Panels.. 3 6.2 Receiver Front and Rear Panels ..4 6.3. -
Page 6: Introduction
EGE-UHD-HDB-EXT HDBaseT Receiver 1. INTRODUCTION The HDMI over single CAT5e/6/7 Transmitter and Receiver set can send uncompressed audio/video and IP data over a single run of CAT5e/6/7 cable at a distance up to 100 meter. It has the added bene t of control through the built -in RS-232 and IR ports and a bi- directional LAN serving connection. -
Page 7: Features
EGE-UHD-HDB-EXT HDBaseT Receiver 5. FEATURES • HDMI with 3D, 4K2K support, HDMI & DVI Compliant • Supports CEC bypass • Simultaneous transmission of uncompressed data over a single 100m/328ft CAT5e/6/7 cable • 5Play™ convergence: HDMI, LAN, PoE & Control (IR & RS-2232) •... -
Page 8: Transmitter Front And Rear Panels
EGE-UHD-HDB-EXT HDBaseT Receiver 3. 6. OPERATION CONTROLS AND FUNCTIONS 6.1 Transmitter Front and Rear Panels geratech RS - 232 POWER BLASTER HDMI IN UPDATE LINK CAT5e/6/7 EXTENDER DC 48V: Plug the 48V DC power supply into the unit and connect the adaptor to an AC outlet. -
Page 9: Receiver Front And Rear Panels
EGE-UHD-HDB-EXT HDBaseT Receiver 6.2 Receiver Front and Rear Panels RS - 232 POWER geratech BLASTER HDMI OUT CAT5e/6/7 EXTENDER LINK UPDATE IR2 BLASTER: Connect to the supplied IR Blaster cable for IR signal transmission. Place the IR Blaster in direct line -of -sight of the equipment to be controlled. -
Page 10: Ir Cable Pin Assignment
EGE-UHD-HDB-EXT HDBaseT Receiver 6.3. IR Cable Pin Assignment IR Blaster Power IR Blaster Signal IR Signal IR Extender Power Grounding 6.4. D - Sub 9 Pin De nitions De ne TX / RX TxD / RxD RxD / TxD www.geratech.com.tr... -
Page 11: Connection Diagram
EGE-UHD-HDB-EXT HDBaseT Receiver 7. CONNECTION DIAGRAM RS- 232 Equipped PC or Notebook Internet Modem or Router CAT5e/6 1.5m 60° DVD or Blu-ray Player RS- 232 IR Blaster Power Supply RS - 232 POWER UPDATE HDMI LINK BLAST HDMI IN 60°... -
Page 12: Speci Cations
EGE-UHD-HDB-EXT HDBaseT Receiver 8. SPECIFICATIONS Video Bandwidth 340MHz / 10.2Gbps Transmitter Inputs 1 x HDMI 1 x IR Extender 1 x RS -232 1 x LAN Outputs 1 x CAT5e/6/7 1 x IR Blaster Receiver Inputs 1 x CAT5e/6/7, 1 x IR Extender... -
Page 13: Cat5E/6/7 Cable Speci Cation
EGE-UHD-HDB-EXT HDBaseT Receiver Operating Temperature 0 °C~40 °C/32 °F ~104 °F Storage Temperature −20 °C~60 °C/−4 °F~140 °F Relative Humidity 20~90 % RH (non -condensing) 8.1 CAT5e/6/7 Cable Speci cation Cable Range Pixel clock Video Data Supported Video Type rate... -
Page 14: Acronyms
EGE-UHD-HDB-EXT HDBaseT Receiver 8. SPECIFICATIONS 480P/576P 720P@50/60 1080I@50/60 1080P@50/60 1080P@24/25/30 9. ACRONYMS ACRONYM COMPLETE TERM CAT5e Category 5 Cable CAT6 Category 6 Cable CAT7 Category 7 Cable Consumer Electronics Control Digital Visual Interface HDCP High -bandwidth Digital Content Protection HDMI... - Page 15 www.geratech.com.tr...
