1. Flip Cooler
3. Adjust Retainer
Slide Back Retainer Until
Tight Against Cooler.
Flip Your Empty
Cooler Upside Down.
Push Slide Track
Back To Access
Back Retainer
Fasteners And
Tighten Accordingly.
4. Tighten Retainer Fasteners
COOLER SLIDES
Installation Instructions
Date:
4/22/2014
2. Place Slides
A
Page
1
Place Slides Upside
Down on Bottom Of
Cooler.
Detail A
of
2
Advertisement
Summary of Contents for BOAT OUTFITTERS COOLER SLIDES
- Page 1 1. Flip Cooler 2. Place Slides Push Slide Track Back To Access Back Retainer Fasteners And Tighten Accordingly. 3. Adjust Retainer 4. Tighten Retainer Fasteners Slide Back Retainer Until Tight Against Cooler. Detail A COOLER SLIDES Installation Instructions Date: 4/22/2014...
- Page 2 To Fasten Into The Threaded Inserts. Remove Cooler And Fasten Slides To Deck Using Supplied Fasteners. Deck Fasteners 6 pcs. #10 x 1 " Locate Assembled Slides And Cooler in Desired Location 8. Mounting 7. Location COOLER SLIDES Installation Instructions Date: 4/22/2014...
