- Page 1 Qt™ Room Control Installation and Operations Guide...
-
Page 3: Table Of Contents
Table of Contents Package Contents Overview Qt Room Control Volume Settings Installing the Qt Room Control Typical Installation Options Two Zone System One Zone System A Single Room Warranty... -
Page 5: Package Contents
Package Contents QtRC Package contains: • 1 - QtRC volume control • 1 - White Decora® style wall plate • 1 - Manual • 1 - Set of white-tipped screws (2 pieces) • 1 - White knob (installed) • 1 - White Decora center plate... -
Page 6: Overview
The Qt Room Control (QtRC) can be used to adjust the sound masking level for an individual room or a space with 2-8 emitters This wall-mounted volume control unit is designed to work with any of the Cambridge Sound Management (CSM) sound masking systems. It installs easily in new or existing construction and fits in most... -
Page 7: Installing The Qt Room Control
Installing the Qt Room Control The QtRC is designed to be installed in a single gang box or low voltage bracket All power is supplied from the control module, so only CAT cables in and out are required There are also no requirements for grounding since it is done over the CAT cables Figure 6.1 Figure 6.2... -
Page 8: One Zone System
One Zone System The layout below is the optimal layout when using QtRCs With the use of a QtRC, each room’s occupant may choose sound masking levels at or below the calibrated level It is recommended that this level be at 42 dB for a closed room, if calibration was done with the QtRC set to max (clockwise) Alternatively, by calibrating the rooms’... -
Page 9: A Single Room
A Single Room In the diagram shown below (Figure 10 1), the maximum volume for the room with an QtRC is the same as the volume of the emitters in the open area The power supplied to all of the emitters in the open area is the same as the power supplied to the QtRC The QtRC has the ability to reduce the power supplied to the emitters within the closed room Since a closed room typically requires a lower sound masking level than an open area, with the use of a QtRC, a closed room can achieve this lower level by decreasing the maximum level (Figure... -
Page 10: Warranty
Please access and review on-line help resources for the product before requesting warranty service If the product is still not functioning properly after making use of these resources, please contact Cambridge Sound Management for a return authorization number All returns are to be prepaid... - Page 11 Therefore, certain additional exclusions may apply ©2015 Cambridge Sound Management, Inc All rights reserved Qt is a registered trademark and QtPro is a trademark of Cambridge Sound Management, Inc cambridgesound.com...
