Summary of Contents for Clocking Systems ANALOGUE
- Page 1 Electronic Time Recorder ANALOGUE Instruction Manual...
-
Page 2: Table Of Contents
CONTENTS 1, Introduction………..……………………………….. …………..4 1.1, Package content ……………………………………….……...5 1.2, Parts identification……………………………………….…..5 1.3 Setting select key……………………………………….……..6 2, Function options………………………………………….…….. .7 2.1, Quick codes’ selection…………………………………….…..7 2.2, Detail codes’ selection………………………………………...8 Initial Setup………………………………………..……………..10 4, Function setting………………………..………………………..10 4.1, Setting the Year……………………..………………………...11 4.2, Setting the Month and Data………………………………..11 4.3, Setting the time system……………………………………..11 4.4, Setting the Hour and Minute………………………………..11 4.5, Setting the day changing time……………………………..11... - Page 3 4.16, Setting the regular time signal (0-99Seconds)……………15 4.17, Setting the shifting time……………………………………...15 4.18, Setting the 2-color printing…………………………………..16 5. All reset……………………………..……………………………..16 6. Trouble shooting……………...…………………………………..17 7. Replacing ribbon cartridge………………………………………18 8. Cautions…………………………………………………………...18 9. Specifications……………………………………………….…….19 10. Error Code……………………………………………………….19 - 3 -...
-
Page 4: 1, Introduction
1. Introduction In order to operate your time recorder accurately and efficiently with a longer product life, please read this manual thoroughly. Models Analogue Functions LCD Display Clock Face Two color printing Time Signal Perpetual calendar Back up battery Auto In-Out adjustment... -
Page 5: Package Content
1.1 Package Contents Unpack the time recorder and check its contents to ensure that the time recorder unit and all accessories as shown below are included. Time Recorder Instruction Manual 2 pcs key Card 1.2 Parts identification (a) Keypad (b)LCD on the top - 5 -... -
Page 6: Setting Select Key
1.3 Setting select key to increase the set value by 1 to decrease the set value by 1 Enter to save the set value & enter the next step Back to backspace the set value Clear to cancel the set value Mode to select function codes Program switch Normal/ Programming... -
Page 7: 2, Function Options
2. Function options The function options will be started by unlocking and removing the lid from the time recorder with the program switch to right side. Here are a total of 73 function codes, which are from “00, 01, 02…” to “ 73” ; different codes are for different settings. - Page 8 Code Functions Setting the Year Setting the Month and Date Setting the time system Setting the Hour and Minute Setting the day changing time Setting the Monthly, Weekly, Bi-weekly pay period ending day Setting the DST start (month and day) Setting the DST start (hour and minute) Setting the DST end (month and day) Setting the DST end (hour and minute)
- Page 9 Setting the time of 18 group of ringing Setting the time of 19 group of ringing Setting the time of 20 group of ringing Setting the time of 21 group of ringing Setting the time of 22 group of ringing Setting the time of 23 group of ringing Setting the time of 24...
-
Page 10: Initial Setup
Setting the time of 8 group of changing color(Black) Setting the time of 9 group of changing color(Red) Setting the time of 10 group of changing color(Black) Setting the time of 11 group of changing color(Red) Setting the time of 12 group of changing color(Black) Setting the time of 13 group of changing color(Red) -
Page 11: Setting The Year
(00 display on the left corner indicates the program Code). The digital display reads 2014 indicates year 2014. The year “14” flashes on the right of the digital display, press the + or – button to set the year. Press Enter to register the setting. ( The default setting is current year.) 4.2 Setting the Month and Date Press Enter or Back to enter the program Code 01,... -
Page 12: Setting The Monthly, Weekly, Bi-Weekly Pay
4.6 Setting the Monthly, Weekly, Bi-weekly pay period ending Press Enter or Back to enter the program Code 05, press + or – button to set the card type. Press Enter again to register the setting value ( The default setting is card type 01,and weekly pay card type 04,and the pay period ending day is Sunday.) Card Type Functions... -
Page 13: Setting The Bi-Weekly Pay Period Ending Day
4.8 Setting the Bi-Weekly pay period ending day Press Enter or Back to enter the program code 05, press + or – button to set the card type to 02 press Enter again to register the setting value press Clear button to select the required pay period ending day and then Press Enter again to register the setting value. -
Page 14: Setting The Dst End (Month And Day)
press + or – button to set the start minute. Press Enter again to register the setting value. ( The default setting is 01:00.) 4.11 Setting the DST end (month and day) Press Enter or Back to enter the program code 08, press + or –... -
Page 15: Detecting Front/Back Of Cards
press + or – button to set the printing position <0~9> Press Enter again to register the setting value. ( The default setting is 0005.) 4.15 Detecting front/back of cards Press Enter or Back to enter the program code 12. Press + or –... -
Page 16: Setting The 2-Color Printing
Press + or – button to set the Hour. Press Enter again to register the setting value. Press + or – button to set the Minute. Press Enter again to register the setting value. Press + button to set the week. Press –... -
Page 17: Trouble Shooting
& Clear & Mode (Key 1, 5, 6) all together to restore the default Press + value, including Date, Time, Time Signal, Color Change, Printing Position. 6. Trouble Shooting ◎ Press RESET button to re-start the program when it is not work properly. Trouble Causes Corrective Measures... -
Page 18: Replacing Ribbon Cartridge
2. As shown in the figure below, pull the ribbon holders towards you and, holding them steady in the position, use the handle to take out the cartridge. 3. Correctly insert a new cartridge between the ribbon guide and the printer head. -
Page 19: Error Code
AC230v Input Power Supply (Refer to the indication on the label of each machine) Power Consumption Standby:2W / Work:10W Dimensions Approx. 193 x 244 x 123 mm ( L x W x H ) Weight 2.4 Kgs Usage Environment -30℃~40℃ 10%RH~80%RH Time Card Sizes 85 x 188 x 0.35 mm ( W x L x H )
