Atherton ADE-043A User Manual

Ip cam tester

Advertisement

Quick Links

ADE-043A
IP CAM TESTER USER'S MANUAL
© 2014 Atherton Electronics Corp. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADE-043A and is the answer not in the manual?

Questions and answers

Summary of Contents for Atherton ADE-043A

  • Page 1 ADE-043A IP CAM TESTER USER’S MANUAL © 2014 Atherton Electronics Corp. All rights reserved.
  • Page 2: Table Of Contents

    Table of Contents FCC Information -------------------------------------------------------------------- 2 Safety and Environmental Precautions ------------------------------------------------ 2 1. Scope --------------------------------------------------------------------------------- 3 2. Unpacking ----------------------------------------------------------------------- 3 3. Battery Charge ---------------------------------------------------------------------- 3 4. Getting Started ----------------------------------------------------------------------- 4 5. Shutting Down Tester ------------------------------------------------------------------ 4 6. Turning the Screen On/Off ---------------------------------------------------------- 4 7.
  • Page 3: Fcc Information

    FCC INFORMATION This Equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 4: Scope

    WARRANTY VOID IF SEAL IS BROKEN 1. Scope This specification is used to define the performance of ADE-043A IP Cam Test Monitor. The Tester benefits users by providing various network protocol compatibilities. The Tester also operates on both NTSC and PAL system by standard BNC video input.
  • Page 5: Getting Started

    4. Getting Started Press and hold the power key on the right edge for 2 seconds. The Tester will start booting up then slide to unlock the screen. The START menu will come up, tap on START to proceed. 5. Shutting Down Tester Press and hold the power key until [Power Off] prompted.
  • Page 6: Menus

    No. Name Connector Function Description Switch ON to use external power bank (Optional). Power Bank Switch Switch OFF to use internal battery. PoE IN RJ-45 Connect the LAN cable to the power bank (Optional).* IP CAM RJ-45 Connect the LAN cable to the IP camera. Video IN Connect the BNC cable to the camera’s video output.
  • Page 7 ICON Description Function Setting and add IP Camera and connect to IP Camera. IP CAM SETTING Preview and manage the snapshot files. SAVE FOLDER Playback and manage the video files. CAT5 Network Cable Test. CAT5 VIEWER View analog camera connected to BNC connector. CVBS VIEWER PoE Function Enable or Disable.
  • Page 8 ˙Tap “ADD” to add IP camera and enter the submenu. ˙DHCP off: Select DHCP On or Off(static IP) ˙Add: Add new camera ˙Camera Type: Select IP camera type. ˙Camera ID: Enter ID of the IP camera. ˙Login: Enter the user name of the IP camera. ˙Password: Enter the password of the IP camera.
  • Page 9 ˙Press to image snapshot and press to start video recording. ˙Tap “BACK” to return to the Main Menu. *NOTE: Some of the camera brand does not support live snapshot and/or video recording features, the icon will gray-out if it’s not supported. SAVE FOLDER ˙Tap the “SAVE FOLDER”...
  • Page 10 ˙User can select “ES Image Browser” or “Gallery” to view a image. Playback the video files ˙Tap the file name in the list to view a video. CAT5 VIEWER ˙Connect one end of the RJ-45 cable to the UTP Terminal Block and another end to the CAT5 port at the right side of the Tester.
  • Page 11 ˙Tap the “PoE function” to enable or disable the PoE function. CVBS OUTPUT ˙Connect the BNC cable from the video input of another monitor to the BNC OUT port on the tester.. ˙Tap the “CVBS OUTPUT” icon and enter its setup page as shown below. ˙Tap “CVBS output status”...
  • Page 12 ˙External storage devices: Select SD card or USB device. ˙Internal storage folder: Created folder named “Camera_Tester”. (User editable) ˙Maximum recording time: Select 15, 30, 60 or 120 seconds. ˙Icon hidden time: Select 5, 10, 20 or 30 seconds. ˙Sleep mode: Disable or Enable. ˙Tap “Back”...
  • Page 13: Dimensions

    9. DIMENSIONS...
  • Page 14 Page intentionally left blank...
  • Page 15 Page intentionally left blank...
  • Page 16 Atherton Electronics Corp. www.athertonelectronics.com 29350 Hunco Way Ste. A, Lake Elsinore, CA 92530 © 2014 Atherton Electronics Corp. All rights reserved. 1-3121-1620G02...
