OEM Tools 24849 Operating Instructions And Parts Manual

2 ton underhoist tripod stand

Advertisement

Quick Links

Operating Instructions and Parts Manual
Please read and save these instructions. Read through this owner's manual carefully before using product. Protect yourself and
others by observing all safety information, warnings, and cautions. Failure to comply with instructions could result in personal
injury and/or damage to product or property. Please retain instructions for future reference.
FOR CUSTOMER SERVICE
Technical Question?
CALL 1-866-458-2472
customerservice@oem-tools.com
UNPACKING
After unpacking the unit, inspect carefully for any damage that
may have occurred during transit. Check for loose, missing,
or damaged parts. If any damage is observed, a shipping
damage claim must be filed with the carrier. DO NOT use
the OEMTOOLS™ 24849 2 Ton Underhoist Tripod Stand if
broken, bent, cracked or damaged parts (including labels) are
noted. Any Underhoist Tripod Stand that appears damaged
in any way, operates abnormally or is missing parts should
be removed from service immediately. If you suspect that the
Underhoist Tripod Stand was subjected to shock load (a load
that was dropped suddenly, unexpectedly, etc.), immediately
discontinue use until it has been checked by a factory
authorized service center.
WARNING
The following safety information is provided as a guideline to help you operate your Underhoist Tripod Stand under the
safest possible conditions. Any tool or piece of equipment can be potentially dangerous to use when safety or safe handling
instructions are not known or not followed. The following safety instructions are to provide the user with the information
necessary for safe use and operation. Please read and retain these instructions for the continued safe use of your tool. Failure
to follow instructions listed below may result in serious injury. In addition, make certain that anyone who uses the equipment
understands and follows these safety instructions as well.
Explanation of Safety Signal Words
WARNING
: Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION
: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.
CAUTION
: Used without the safety alert symbol indicates a potentially hazardous situation which, if not avoided, may result
in property damage.
NOTES
: Provide clarity and helpful information.
Thank you very much for choosing an OEMTOOLS™ Product!
For future reference, please register your new tool at www.oem-tools.com and complete the owner's record below:
Model: _______________ Purchase Date: ___________
Save the receipt, warranty and these instructions. It is important that you read the entire manual to become familiar with this product
before you begin using it. This product is designed for certain applications only. OEMTOOLS™ cannot be responsible for issues
arising from modification. We strongly recommend this product is not modified and/or used for any application other than that for
which it was designed. If you have any questions relative to a particular application, DO NOT use the product until you have first
contacted customer service to determine if it can or should be performed on the product.
4/19
2019 OEMTOOLS
2 TON UNDERHOIST
1
24849
TRIPOD STAND
24849

Advertisement

loading

Summary of Contents for OEM Tools 24849

  • Page 1 If any damage is observed, a shipping damage claim must be filed with the carrier. DO NOT use the OEMTOOLS™ 24849 2 Ton Underhoist Tripod Stand if broken, bent, cracked or damaged parts (including labels) are noted. Any Underhoist Tripod Stand that appears damaged in any way, operates abnormally or is missing parts should be removed from service immediately.
  • Page 2 Operating Instructions and Parts Manual 24849 2 TON UNDERHOIST TRIPOD STAND IMPORTANT INSTRUCTIONS workspace. Keep the work area free of obstructions, grease, oil, trash, and other debris. DO NOT use this AND SAFETY RULES product in a damp or wet location.
  • Page 3 Operating Instructions and Parts Manual 24849 2 TON UNDERHOIST TRIPOD STAND 32. This equipment is designed for servicing a variety 1. If you are working and the load becomes off-balance of engines in a safe, convenient manner. However, and/or the high reach stand begins to tip over, DO...
  • Page 4: Parts List

    Operating Instructions and Parts Manual 24849 2 TON UNDERHOIST TRIPOD STAND PARTS BREAKDOWN Parts Diagram Parts List Fig. Description Qty. Fig. Description Qty. M6x10 Bolt M8 Washer Saddle Pad M8x16 Bolt Saddle Base M8x12 Bolt Extension Screw Locking Bolt Adjusting Handle...
