Summary of Contents for Strongarm 218
Page 1
3 Ton Engine Crane – Heavy Duty PROD NO. 030321 MOD NO. 218 Operating Instructions WARNING: Read all instructions and safety warnings before operating this equipment. Failure to follow the instructions and safety warnings may result in personal injury or property damage.
Page 2
Owners and / or operators should be aware that repair of this equipment may require specialized knowledge and facilities. It is recommended that this equipment be inspected annually by a qualified repair facility. Defective parts, decals, safety labels or signs should be replaced with Strongarm specified parts.
Page 3
ASSEMBLY Use the parts drawing as your guide to assembly. Lay all parts and assemblies out in front of you before beginning. We recommend 2 people and the following procedure: 1) Attach rear Caster Wheels (#6) to rear of Base (F) 2) Insert Leg (G) into Base (F) and lock into position using bolt (#12) From this point, it is recommended that you leave a “loose fit until you have all of the components assembled and then tighten each piece once finished.
Page 4
MAINTENANCE 1) Use a good grade of hydraulic jack oil. Never mix different types of fluid. 2) Store the crane in the retracted position to protect the ram from dirt and water which will eventually cause rust and could damage the internal seals. 3) Moving parts should be lubricated once a month using a general purpose grease.
Page 5
3 Ton Engine Crane – Heavy Duty PROD NO. 030321 MOD NO. 218 Parts Breakdown Description Qty. Description Qty. Description Qty. Boom Extension Nut M16 16 Nut M22 Boom Caster Wheels 17 Bolt M20 x 135 Upright Mast Jack Handle...
