Related Manuals for Hong Nor DM-ONE SPEC-e
Summary of Contents for Hong Nor DM-ONE SPEC-e
- Page 4 PLASTIC PARTS FOR USE X1-33 X1-38 #306C FRONT AND REAR GEAR BOX DIFF. CASE REAR UPRIGHT Parts for Not Use DM-12 DM-12 X1-37 ARM HOLDER REAR UPPER ARM Parts for Not Use XT-22 SHOCK PLASTIC Parts for Not Use J-36 CENTER DIFF.
- Page 8 ASSEMBLY OF THE SERVO SAVER J-33 *Tighten the steering plate hex screw all way down and then back it off 1/2 turn. X1-10H Step 1 Step 2 X1-39 X1-39 J-20 13x16x0.2mm X1-07BK Shim ..x2 X1-39 Ensure Free Movement X1-39 4x8mm Plastic Flange X1-39 Bushing...
- Page 15 ASSEMBLY OF THE REAR WHEEL HUB Assemble both right and left sides. Step 1 Step 2 #273A 5x4mm set screw ..x2 #306C #267E 2.5x16.8mm Pin ..x2 #267E #267D #267D #267D X1-26 8x16mm Ball Bearing ..x4 Ensure Free Movement 8x12x1mm #306F #306D #306F 11mm...
- Page 28 1/8 DM-1 Electric Parts List 編號 品名 數量 編號 品名 數量 轉向塑膠球頭 中差座支柱 A-40A X1-12 鋁差速齒(20Tx2,10Tx4) A-41A X1-13 6mm球型 1組 天線管 差速接杯 A-56 X1-14 4x10x0.15 墊片 A-77G X1-16 13T小傘齒 A-87B 4mm十字軸心 X1-17 43T大傘齒 1/8 中卡車殼支柱 小傘接杯 B-22 X1-19 聯結式傳動軸(前) BT-110 1/8像真胎...
- Page 29 1/8 DM-1 Electric Parts List Part No. Description Part No. Description Q'TY Q'TY A-40A 6mm Ball End (Plastic) X1-12 Center Diff. Mount Post A-41A 6mm Ball X1-13 Diff. Gear (small & large ) 1set A-56 Antenna Pipe X1-14 Cap Joint for Diff. A-77G 4x10x0.2 Washer X1-16...
