4.11. General Purpose Input/Output (GPIO)

SIM2000S provides 2 GPIO pins. The output voltage level of the GPIO can be set by AT command "AT+ SGPIO".
The input voltage level of the GPIO can also be read by AT command "AT+ SGPIO". For more details, please
refer to document [1].
Table 28: Pin definition of the GPIO
Pin name
GPIO33
GPIO34

4.12. ADC

Table 29: Pin definition of the ADC
Pin name
ADC1
ADC2
SIM2000S provides two auxiliary ADC, which can be used to measure the voltage. User can use AT command
"AT+CADC" to read the voltage value. For details of this AT command, please refer to document [1].
Table 30: ADC specification
Parameter Min
Voltage range 0
ADC Resolution
Sampling rate
ADC precision

4.13. PWM

Table 31: Pin definition of the PWM
Pin name
PWM
SIM2000S provides a PWM interface which can be used to drive a vibrator, and a backlight LED for display or
keyboard. PWM output frequency varies from 0 to 4.8MHz. AT command "AT + SPWM" is used to set the
output period and duty cycle of the PWM. For details, please refer to document [1].
