RA3109 Light Source
Overview
The portable stabilized light source can provide stable output of 1-4 wavelengths depending on user's requirements. It can not only
provide 650nm visible red light, but also provide 1310nm and 1550nm double-wavelength laser output for single-mode optical fiber
measurement, or provide laser output of four wavelength, i.e.: 850/1300/1310/1550nm, it is an ideal tester designed for optical fiber
works..
Specifications
Model
Working wavelength
(nm)
Light-emitting device
Optical output power
(dBm)
Modulation
Website: www.radiasunmeters.com, Email: sales@radiasunmeters.com, Phone: +86-22-83717689, Fax: +86-22-83717689
General
Special configurations
configurations
for PON light source
1310/1550
1310/1490/1550
-7/-7
-7/-7/-7
Features
·High-stability multi-wavelength single (multiple) mode laser
output, optional CW or modulation mode
·Large LCD display of working wavelength
·Supports continuous work up to 48 hours.
·Ability to switch working wavelength by pressing one key,
easy to operate
·
AUTO POWER OFF
D: 850/1310/1550
E: 1310/1490/1550
F: 1310/1550/1625
FP-LD
CW/270/1K/2K
Others
0DB-7DB
Advertisement
Summary of Contents for Radiasun RA3109
- Page 1 RA3109 Light Source Overview The portable stabilized light source can provide stable output of 1-4 wavelengths depending on user’s requirements. It can not only provide 650nm visible red light, but also provide 1310nm and 1550nm double-wavelength laser output for single-mode optical fiber measurement, or provide laser output of four wavelength, i.e.: 850/1300/1310/1550nm, it is an ideal tester designed for optical fiber...
- Page 2 RA3109 Light Source Type of optical fibre SM，MM Connector FC/PC Working temperature -10～+60 ℃ Storage temperature -25～+70 ℃ Auto power-off time (min) Continuous working hours (h) Dimensions (mm) 190×100×48 Power supply Rechargeable lithium battery Weight (g) Function Description 1. Optical output Connect FC optical fibre connector to the signal receiver of the device to be measured.
- Page 3 RA3109 Light Source Operating Instructions 1. Connect the optical fibre connector to output port. 2. Press ON/OFF, the working indicator turns on. 3. Press WAVE key to adjust modulation frequency of light source. 4. Press MODE key to adjust modulation frequency of light source.
