LaserLyte-Flex Red Userguide
Product Overview
Thank you for purchasing the LaserLyte-Flex Red laser alignment system. It uses interchangeable optics
and a red semiconductor laser diode to project a highly visible dot, line, cross, or a combined line and
central dot. This helps you to accurately align and position garments, cloth, paper, wood, and metal of
different shapes and surface profiles.
This guide explains how to mount and operate your laser, adjust the focus, and change projection
optics. This guide also discusses the relationship between working distance, fan angle, and line length,
and some applications of the LaserLyte-Flex Red.
If you have any queries or require help when using this product then please call is on +44 (0)1495
21213, email us at sales@globallasertech.com or contact your local representative.
A G lo b a l L aser Bra nd

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LaserLyte-Flex Red and is the answer not in the manual?

Questions and answers

Summary of Contents for Global Laser LaserLyte-Flex Red

  • Page 1 LaserLyte-Flex Red Userguide Product Overview Thank you for purchasing the LaserLyte-Flex Red laser alignment system. It uses interchangeable optics and a red semiconductor laser diode to project a highly visible dot, line, cross, or a combined line and central dot. This helps you to accurately align and position garments, cloth, paper, wood, and metal of different shapes and surface profiles.
  • Page 2 Operating LaserLyte-Flex With 3.5V PS1/PS4 Power Supply If you have purchased an extension lead: 1. Plug the male DC Jack end of the extension lead into the DC socket on the PS1/PS4 2. Plug the male DC Jack of the LaserLyte-Flex cable into the DC socket on the extension lead If you have not purchased an extension lead: 3.

  • Page 3: Focus Adjustment

    Focus Adjustment The focus distance of your laser upon delivery will be set to 1000mm unless requested otherwise. This can be adjusted as follows: 1. Remove your interchangeable projection optic if one is fitted by unscrewing it from the main body of the laser module (see drawings A&B) 2.
  • Page 4 Mounting The lifetime and stability of your laser can be optimised when mounted on a suitable heat sink. This allows the case temperature to be kept within its specified range. Failure to properly heat sink your laser device could result in shortened lifetime or failure of the diode. As a general guideline, the life- time of a laser diode decreases by a factor of two (approx.) for every ten degree increase in operating temperature.
  • Page 5 two M5 hex nuts & washers are supplied) 5. Tighten machine screw A with an M3 Allen key 6. Loosen Phillips screw A with a Phillips head screwdriver 7. Slide the laser into the mounting hole 8. Rotate the mounting clamp to the desired position and then tighten Phillips screw A Mounting the LaserLyte-Flex Iin the Swivel Mounting Clamp (See Drawing F) 1.
  • Page 6 Applications The LaserLyte-Flex Red is suitable for many different applications, some of which are below. If you would like further information then please contact your local distributor or Global Laser. Pattern Alignment Saw & Cutting Guidance Machine Alignment Positioning Screen Printing...

  • Page 7: Warranty And Repair

    The LaserLyte-Flex Red is supplied with a 12 month parts and labour warranty. Our manufacturing operations are certified to ISO9001. If your product develops a fault within 12 months from the date of purchase Global Laser will repair/ replace your product. If you wish to return a faulty product then please contact your local representative or Global Laser to obtain a RMA code (Return Material Authorisation).

  • Page 8: Top View

    Diagrams A) LaserLyte-Flex 39.40 ±0.15 39.40 ±0.15 B) LaserLyte-Flex with Line/Cross Optics Fitted 44.00 44.00 C) Heavy Duty Mounting Clamp 35.00 TOP VIEW Ø25.00 SIDE VIEW 17.00 BOTTOM 8.00 SECTION SIDE VIEW 1 Hole Drill 4.2Ø & C/Bore 7.5Ø x 5.0 Deep at 1 End &...

  • Page 9: Front View

    M3 Ct/Sunk screws 2 Holes drill Ø4.50 and counterbore Hex Hole to suit M4 MS full nuts at rear Please Note: Global Laser reserve the right to change T: +44 (0)1495 212213 descriptions and specifications without notice. F:+44 (0)1495 214004 E: sales@globallasertech.com...
