DOREL ASIA
Model No:
DA5673-3DR (Walnut)
DA5673-3W (White)
Langley Bookcase
UPC CODE:
DA5673-3DR 0-65857-16313-1
DA5673-3W 0-65857-16319-3
DPCI#:
DA5673-3DR 030-09-1153
DA5673-3W 030-09-1163
Lot number:
(TAKEN FROM CARTON)
_____________________________________
Date of purchase:
_______ / _______ / _______
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our customer service
department. We will replace the part FREE of charge.
NEED HELP!
Tel #: 1-800-295-1980
CALL US FOR ASSI
E-Mail: das@dorel.com
1-800-295-1980
Fax #: 514-353-7819
DO NOT RETURN P
Advertisement
Table of Contents
Related Manuals for Eddie Bauer Langley Bookcase DA5673-3DR
Summary of Contents for Eddie Bauer Langley Bookcase DA5673-3DR
- Page 1 DOREL ASIA Model No: DA5673-3DR (Walnut) DA5673-3W (White) Langley Bookcase UPC CODE: DA5673-3DR 0-65857-16313-1 DA5673-3W 0-65857-16319-3 DPCI#: DA5673-3DR 030-09-1153 DA5673-3W 030-09-1163 Lot number: (TAKEN FROM CARTON) _____________________________________ Date of purchase: _______ / _______ / _______ DO NOT RETURN PRODUCT TO THE STORE. If a part is missing or damaged, contact our customer service department.
-
Page 2: Care And Cleaning
CUSTOMER SERVICE If you are missing parts or have any questions about this product, contact our customer service representative first! CALL 1-800-295-1980 You can also order parts by writing to the address listed below. Please include the product model number, color and a detailed description of the part. Customer Service Department No. -
Page 3: Hardware List
Langley Bookcase DA5673-3DR / DA5673-3W HARDWARE LIST Ø8 X 30mm WOOD DOWEL CAM LOCK CAM BOLT 26 PCS 26 PCS 26 PCS Ø5/32" X 5/8" ROUND HEAD SCREW SHELF PIN 22 PCS 8 PCS... -
Page 4: Parts List
Langley Bookcase DA5673-3DR / DA5673-3W PARTS LIST TOP PANEL LEFT SIDE PANEL RIGHT SIDE PANEL 1 PC 1 PC 1 PC FRONT TOP RAIL FRONT BOTTOM RAIL BACK TOP RAIL 1 PC 1 PC 1 PC BACK BOTTOM RAIL ADJUSTABLE SHELF FIXED SHELF 1 PC 2 PCS... - Page 5 Langley Bookcase DA5673-3DR / DA5673-3W STEP 1: Insert cam locks (2) and wood dowels (1) into bottom panel (J). Insert cam bolts (3) into back bottom rail (G) and front bottom rail (E). Attach rails (G) & (E) to bottom panel (J) and secure by rotating cam locks (2) 1/2 turn clockwise using a Phillips head a screwdriver (not included).
- Page 6 Langley Bookcase DA5673-3DR / DA5673-3W STEP 2: Insert cam bolts (3) into left side panel (B) and right side panel (C).
- Page 7 Langley Bookcase DA5673-3DR / DA5673-3W STEP 3: Insert wood dowels (1) and cam locks (2) into front top rail (D), back top rail (F), fixed shelf (I), front bottom rail (E) and back bottom rail (G). Attach rails (D) & (F), fixed shelf (I) and the bottom unit (assembled in step 1) to left side panel (B) and right side panel (C).
- Page 8 Langley Bookcase DA5673-3DR / DA5673-3W STEP 4: Insert cam bolts (3) into top panel (A).
- Page 9 Langley Bookcase DA5673-3DR / DA5673-3W STEP 5: Insert wood dowels (1) into side panels (B) & (C). Insert cam locks (2) into side panels (B) & (C), back top rail (F) and front top rail (D). Attach top panel (A) to the assembled frame. Secure top panel (A) by rotating cam locks (2) 1/2 turn clockwise using a Phillips head a Use a Phillips head screw driver (not included) to rotate the cam locks to secure cam bolts.
- Page 10 Langley Bookcase DA5673-3DR / DA5673-3W STEP 6: Attach back panel (K) to the assembled unit with round head screws (4) using a Phillips head screw driver (not included).
- Page 11 Langley Bookcase DA5673-3DR / DA5673-3W STEP 7: Insert shelf pins (5) into the desired location on side panels (B) & (C). Place adjustable shelves (H) into the assembled unit.
- Page 12 E-Mail: das@dorel.com Fax #: 514-353-7819 1-800-295-1980 DO NOT RETURN PR E-MAIL:DAS@DORE Dorel Asia is an authorized licensee of Eddie Bauer Licensing Services LLC. Eddie Bauer® and the Eddie Bauer logos are the registered trademarks of Eddie Bauer Licensing Services LLC.
- Page 13 Furniture Wall Safety Strap SAFETY WALL STRAP WALL ANCHOR MOUNTING BRACKET SHORT SCREW LONG SCREW 1 PC 1 PC 2 PCS 1 PC 1 PC TOOLS NECESSARY: RUBBER MALLET AND PHILLIPS SCREW DRIVER ARE NOT INCLUDED. NOTE: 3/8" DRILL BIT AND ELECTRIC DRILL ARE NOT PROVIDED. WARNING: WHEN UPRIGHT, IT IS POSSIBLE THAT THE FURNITURE MAY TIP OVER.
-
Page 14: Customer Service
MODEL #: DA5673-3DR / DA5673-3W Customer Service PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE PLEASE CONTACT CUSTOMER SERVICE REPRESENTATIVES AT THE FOLLOWING NUMBERS SHOULD THERE BE ANY MISSING OR DEFECTIVE PART(S). Customer Service Phone Number 1-800-295-1980 Email: das@dorel.com Customer Service Fax Number 514-353-7819 Request Date: Name:...
