Party Robotics Bartendro B107V1 Started Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Bartendro
TM
B7 / B15 Kits
Getting Started Guide
Model Nos.
B107V1
B115V1
EDITION
Thanks for backing us!
Please Read Before Operating
www.partyrobotics.com
v 1.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Bartendro B107V1 and is the answer not in the manual?

Questions and answers

Related Manuals for Party Robotics Bartendro B107V1

Summary of Contents for Party Robotics Bartendro B107V1

  • Page 1 Bartendro B7 / B15 Kits Getting Started Guide Model Nos. B107V1 B115V1 EDITION Thanks for backing us! Please Read Before Operating www.partyrobotics.com v 1.1...

  • Page 2: Important Precautions

    Bartendro B7 / B15 Kits Congratulations! You are one of the first owners of a new enabling piece of tech- nology. These precision Bartendro Dispensers and electronics are the same as what go into Bartendro cocktail bots. The appli- cations don’t stop at cocktails though, people have been coming up with lots of ideas from sno-cones to hydroponics. What will you come up with? Share your projects at: www.partyrobotics.com/community/sharing Important Precautions • Not intended for medical use. • Electronics may be sensetive to static dissipation. Observe proper precautions for handling. • Do not “hot-swap” Dispensers while system is powered. • Plug networking devices into Raspberry Pi only. Plugging them into RJ45 connectors on the Router Board will cause damage. • It is not recommended to keep clear tubing immersed in liquid for e x- tended periods of time. • Beige tube (inside the Dispensers) life is approximated to be 500 hours of use. • If storing long term without use, remove beige tubing from dispensers t o extend tube life. • Dispensers may need to be periodically re-calibrated as tubing wears.

  • Page 3: What's Included

    Bartendro B7 / B15 Kits What’s Included: B15 Part No. Item 7 15 A007V1 Bartendro Dispenser With Liquid Sensor (includes two compression nuts) 1 1 M101V1 A Chopstick (tubing replacement tool) 1 1 A017V1 Bartendro Router Board (with hardware) 1 1 E004V1 Raspberry Pi (RPI) 1 1 E007V1 SD Card 1 1 E005V1 USB WiFi Dongle 1 1 E009V1 24V, 200W Power Supply with Power Cord 1 1 A014V1 Power Adapter Cable 1 1 TXXXV1 Food Grade Tubing (about 5ft per dispenser) 4 8 M102V1 Standard Bottle Topper 2 5 M103V1 Large Bottle Topper 1 2 M104V1 Extra Large Bottle Topper 7 15 M105V1 Bottle Topper Cap 7 15 M033V1 Tubing Keeper 7 15 A009V1 Liquid Sensor Adapter www.partyrobotics.com...

  • Page 4: Quick Start Instructions

    Bartendro B7 / B15 Kits Quick Start Instructions You will need: AC Outlet Device with Web Browser (phone, tablet, laptop, etc) Wired Networking Router (for software updates) Computer (for software updates) Hardware Setup: 1. Make sure the Raspberry Pi is securely connected to the Router Board and is supported with standoffs.

  • Page 5: Getting Started With The User Interface

    Bartendro B7 / B15 Kits Getting Started with the User Interface Connect to your bot: 1. Using a WiFi enabled device, find the “bartendro” WiFi network by looking for it in your settings and connect to it. 2. Once connected (up to ~30 sec the first time) you will need to go to a web browser, such as Chrome, and type in any web addess.

  • Page 6: Cleaning And Maintenance

    Bartendro B7 / B15 Kits Admin - Booze: Displays the ingredient options and allows you to add your own custom ingredients. Adding the type, whether alcohol or sweetness / tartness will allow for customizations in the drink menu. Admin - Options: Useful mostly for software updates - your modified database file can be saved to your local machine, so when a new image is used, your database with saved drinks can be restored.
  • Page 7 Bartendro B7 / B15 Kits Getting under the hood: There are several settings that aren’t exposed through the UI yet but can be changed by modifying the config.py file on the Raspberry Pi. Things like: use of liquid level sensors, display units, default size, taster buttons, the requirement to be logged in to dispense, etc.

  • Page 8: Troubleshooting

    Bartendro B7 / B15 Kits Troubleshooting Dispenser LEDs are blue / green / blank after power up This is normal, LEDs will remain in this mode until proper communication with dispensers is established (about 1 min). If not getting there, make sure SD card is properly seated. Dispenser LEDs are flashing red A current limit has been triggered on a dispenser, press the “reset”...

This manual is also suitable for:

Bartendro b115v1
