TCi TCANT441 Mounting Information

01487 710 555
www.tci-wireless.co.uk
Dual Band 6 dBi 802.11 n/ac Outdoor Directional
802.11n/ac 2.4/5 GHz quad patch antenna is designed to operate with many manufacturers' enterprise-class 802.11n
and 802.11ac MIMO access points (APs). Whether deploying a new 802.11ac-only network or overlaying 802.11ac
onto your existing 802.11n network, this quad patch antenna can operate in both environments.
The antenna comes with four RPTNC Plug connectors, 36" cables and an articulating mount. With dual-band leads,
each cable supports both 2.4 and 5 GHz, making it an ideal antenna to support demanding indoor or outdoor
applications utilizing 802.11n and 802.11ac wireless communication systems. The antenna radome is designed with
withstand challenging environments where this is exposure to moisture and dust. The articulating mount allows for
multiple mounting options on either a wall or a mast/pole.
Specifications
Part Number
Frequency Range
Bandwidth
Gain
Vertical Beamwidth
Horizontal Beamwidth
VSWR
Normal Impedance
Polarization
Isolation
Max Power
Lightning Protection
Connector
Dimensions
Weight
Operating Temperature Range
Wind Load
Antenna With RPTNC Connectors
TCANT441
2400~2500 / 5150~5850 MHz
100 / 700 MHZ
6 dBi
60° / 70°
105° / 125°
Typical < 2.0
50 Ohms
Vertical
< 20dB
20W
N/A
4 x RPTNC Plug with 36" / 914mm Cable
10" x 5.6" x 1.4" / 254mm x 142mm x 35mm
1.2lbs / 0.544KG
-40°F to +158°F / -40°C to 70°C
60 mph
2.4 GHz
Providing more 4 wireless
5 GHz
