Summary of Contents for Tivdio T10D
-
Page 1: User Manual
T10D WiFi Wireless Video Door Phone User Manual EU Importer： Name：Germany Retevis Technology GmbH Address：Uetzenacker 29,38176 wendeburg... -
Page 2: Table Of Contents
Introduction Content With Hisilicon Hi3518E hardware platform, this WIFI/IP video intercom Product Introduction doorbell uses H.264 image compression. Its picture transmission data Product Diagram is small and power consumption low. Product Overview This product is easy and safe to operate. It is applicable under both APP Installation (name: idoorphone) LAN and 3G/4G network. -
Page 3: Product Introduction
Product Introduction APP(idoorphone) Installation ● a. For Android users, please log in Google Play, download and install Product Diagram ● APP (name: idoorphone); or scan QR code on color box and pairing key(long click for download APP. 3 seconds to restore factory setting) idoorphone b. -
Page 4: Connect Doorbell With Android/Ios Devices
1. Connect Doorbell with Power Supply iOs APP Main Interface a. Correctly connect DC12V power (red wire is positive and black wire negative). Please refer to power connector in Product Diagram. b. Fix rain cover well into waterproof case, and wait for about 35 seconds to finish booting. -
Page 5: Add Additional Device To A Doorbell
4. Add Additional Device to a Doorbell APP Main Interface Function Introduction a. When doorbell is not connected to router: make doorbell into pairing status, link extra (Take Android Device as an Example) phone's Wifi to doorbell's LAN and click "Add Device" on APP interface (please refer to pairing operation). -
Page 6: Edit
d. Unlock Settings: unlock password and Unlock Duration can be revised here. Click 4. Activity "Done" button after change. "Enable Pairing" button can take the role of clicking doorbell’s “pairing” key. Click ”Activity”and all activities can be previewed (included records of call, tamper alarm, e. -
Page 7: Unlock By Outdoor Unit's Keypads
Unlock by Outdoor Unit's Keypad 6-digital unlock password is put in color box. Please keep it well. It can be revised in "Unlock Settings". 1. Unlock door by smartphone In video intercom status, touch "unlock" icon, enter unlock password and click "ok" for confirmation;... -
Page 8: Installation Operation
Installation Operation Outdoor Unit Wire Connection with E-lock Installation Operation Installation Guide e-lock connector electronic lock Outdoor camera should be installed 1.4-1.7 meter above floor and avoided from direct sunshine. power on unlock slot black power off unlock slot yellow green unlock switch blue... -
Page 9: Connection With Wireless Chime
Connection with Wireless Chime Frequently Asked Questions 1. Paring failure wireless chime(optional) a. iOs devices and some Android devices do not support Wifi auto switch; manually linking mobile to doorbell’s Wifi hotspot is necessary(see image 2). Then do pairing Back Front again.
