EDER planer

EPH1

for assembly to power saws

Operating Instructions and Spare Parts List

EDER Maschinenbau GmbH

Schweigerstraße 6

DE-38302 Wolfenbüttel

Tel. +49-5331-76046

Fax +49-5331-76048

info@eder-maschinenbau.de

http://www.eder-maschinenbau.de

- 1 -

EDER planer EPH1, 01.07.09

Table of Contents

Need help?

Do you have a question about the EPH1 and is the answer not in the manual?

Questions and answers

Summary of Contents for EDER EPH1

Page 1 EDER planer EPH1 for assembly to power saws Operating Instructions and Spare Parts List EDER Maschinenbau GmbH Schweigerstraße 6 DE-38302 Wolfenbüttel Tel. +49-5331-76046 Fax +49-5331-76048 info@eder-maschinenbau.de http://www.eder-maschinenbau.de - 1 - EDER planer EPH1, 01.07.09...
Page 2 The device is apt for planing flat or round wood surfaces of all kinds. For planing round surfaces, we recommend the EDER round planer. The constructive formation of the planing barrel causes a high chipping performance at minimal effort. The device is set on the folding plate supported oscillating around the rotary axis of the barrel.
Page 3 4.All knives are adjusted the same way. 5.The clamping bolts for the knives are to be tightened at a torque of at least 35 Nm. A corresponding torque wrench can be obtained from EDER Maschinenbau as optional accessory or from the specialized tool trade.
Page 4 On fueling the machine, the engine must be shut down, it must not be smoked, and there must be some distance to open fires. The machine is to be operated with as little noise and emissions as possible. - 4 - EDER planer EPH1, 01.07.09...
Page 5 (e. g. pull the plug). Foreign substance or material parts may not be removed from near moving parts. Apt tools are to be used for maintenance and installation. Only original EDER spare parts are to be used for replacement! Instructions for the Use of Personal Protective Equipment On operating the planer, all regulations and security provisions as for the operation of power saws are applicable.
Page 6 / engines which are in accordance with the EC Directive for Machines and are thus marked CE. The mount may only be executed to machines / engines which are expressly named in the accompanying documents / bill of delivery. Wolfenbüttel, 01/02/2009 Ulrich Schrader managing director - 6 - EDER planer EPH1, 01.07.09...
Page 7 18 0204 V-belt pulley 09 0213 Bolt short 19 0619 Folding plate 10 0217 Retaining ring 0620 Hexagonal wrench DIN 911 With the spare parts marked by * please indicate your type of power saw. - 7 - EDER planer EPH1, 01.07.09...
