Summary of Contents for New England Slimline 4 UW505
- Page 1 New England Slimline 4 Drawer Unit Assembly Instructions - please keep for future reference UW505 464/3944 Dimensions Width - 30cm Depth - 30cm Height - 81.5cm Important – Please read these instructions fully before starting assembly Issue 1 - 16/05/2016...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • During assembly do not stand • We do not components and tools listed on or put weight on the product, recommend the use page 2 this could cause damage.
- Page 3 Components - Panels Please check you have all the panels listed below 80x28. 5x1. 5cm 28x24. 5x1. 2cm 30x30x1. 5cm 80x28. 5x1. 5cm 24. 5x4. 5x1. 2cm 24. 5x7. 5x1. 2cm 24. 5x4. 5x1. 2cm 10X4 11x4 12x1 25. 7x22. 7x0. 3cm 22x11.
- Page 5 Assembly Instructions Step 1 Connect 2 x Drawer sides 12 to 1 x Drawer Back 13 using 4 x Screw D 2. Slide Drawer base 14 into place. 3. Connect Drawer front 11 to side panels 12 using 4 x Screw D Repeat to assemble remaining drawers Step 2...
- Page 6 Assembly Instructions Step 4 1. Insert 4 x Dowels into 2 x Panels 5 as shown 2. Insert 1 x Dowel A into 1 x Panel 6 2. Insert 2 x Dowels into the edge of Base panel 8 3. Into Front Plinth 9 insert 2 x Dowels A 4.
- Page 7 Assembly Instructions Step 6 1. Into the underside of Top Panel 1 insert 4 x Male Camlocks shown. 2. Insert 4 x Dowels into the top edge of side panels 2 and 3. Locate Top Panel into position. 4. Insert 4 x Female Camlocks and Tighten Step 7...
- Page 8 Assembly Instructions Step 9 1. Add 4 x Feet I Step 10 This unit is floor standing but we recommend 1. On the reverse of the unit, in position shown, fix 1 x Wall Straps using 1 x Screws L 2.
