INSTALLATION INSTRUCTIONS
CAM-AM
DEFENDER MAX

Advertisement

loading
Need help?

Need help?

Do you have a question about the HardCabs CAM-AM DEFENDER MAX and is the answer not in the manual?

Questions and answers

Summary of Contents for DFK HardCabs CAM-AM DEFENDER MAX

  • Page 1 INSTALLATION INSTRUCTIONS CAM-AM DEFENDER MAX...

  • Page 2: Safety Instructions

    CAN-AM DEFENDER MAX SAFETY INSTRUCTIONS Warning: Failure to heed all safety and operating instructions and warnings regarding use of this product can result in serious bodily injury. READ PROPERLY COMPLETE ASSEMBLY INSTRUCTIONS BEFORE STARTING OF ASSEMBLY Install all parts indicated in assembly instructions. Failure to fully assemble product before use could result in personal injury.

  • Page 3: Maintenance And Cleaning

    CAN-AM DEFENDER MAX WARNING: For safety purposes, if the DFK Cab doors are removed, it is mandatory that the OEM manufactured Half Doors or Nets are REINSTALLED before operating the vehicle. MAINTENANCE AND CLEANING To clean polycarbonate surface use soapy water solution or other subtle means.

  • Page 4: Preparation For Installation

    CAN-AM DEFENDER MAX PREPARATION FOR INSTALLATION: Uninstall all additional systems from the roller cages (work lights, rear mirrors, drink holders etc.) It is necessary to uninstall rear side tubes (red lines) from the UTV’s from both sides. Save the tubes with the original screws for later usage.
  • Page 5 CAN-AM DEFENDER MAX CAB PREVIEW HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 6 CAN-AM DEFENDER MAX FRONT PANEL Place the front console assembly onto UTV roll cage and fix by included fixing assembly on both sides. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 7 CAN-AM DEFENDER MAX Place the front panel onto UTV roll cage and adjust to the best position. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 8 CAN-AM DEFENDER MAX Fix the front panel with included fixing assemblies. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 9 CAN-AM DEFENDER MAX Install gas spring onto gas spring holders on both sides. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 10 CAN-AM DEFENDER MAX Adjust the front glass stop assembly into the best position and tighten screws hard on both sides. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 11 CAN-AM DEFENDER MAX ROOF Uninstall the rear roof panel holders screw before the rear roof panel installation. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 12 CAN-AM DEFENDER MAX Place and adjust the rear roof panel onto the UTV roll cage. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 13 CAN-AM DEFENDER MAX Close the rear roof panel holders and fix with included washers, screws and covers. Tighten hard. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 14 CAN-AM DEFENDER MAX If you install the cab without the doors, fix the rear roof panel with the fixing assemblies. If you have the complete cab with the doors, fix the rear roof panel with the rear doors frame hinges (page 23). HardCabs 630-324-8585 www.hardcabs.com...
  • Page 15 CAN-AM DEFENDER MAX Uninstall the front roof panel holders (red circles). HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 16 CAN-AM DEFENDER MAX Place and adjust the front roof panel onto UVT roll cage. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 17 CAN-AM DEFENDER MAX Connect the front and rear roof panel together and fix with included fixing assemblies. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 18 CAN-AM DEFENDER MAX Install the front roof panel holders to the correct position and tighten the screws correctly. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 19 CAN-AM DEFENDER MAX Fix the front roof panel onto UTV roll cage with included fixing assemblies. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 20 CAN-AM DEFENDER MAX REAR PANEL Losen the rear panel holders screws and turn the rear panel holders. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 21 CAN-AM DEFENDER MAX Place and adjust the rear panel to the best position onto UTV roll cage. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 22 CAN-AM DEFENDER MAX Turn the rear panel holders to the correct position and tighten the screws correctly. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 23 CAN-AM DEFENDER MAX LEFT REAR DOOR + RIGHT REAR DOOR Install the left rear door hinges and fix onto UTV roll cage with included fixing assemblies. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 24 CAN-AM DEFENDER MAX Install the door stop assembly into the rear left door stop holder. Fix by included fixing assemblies. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 25 CAN-AM DEFENDER MAX Place the left rear door stop assembly onto the UTV roll cage. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 26 CAN-AM DEFENDER MAX Fix the rear left door stop assembly with included screws, washers and covers. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 27 CAN-AM DEFENDER MAX Place the left rear door onto the hinges. If necessary install the washers 10 onto the hinges pins. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 28 CAN-AM DEFENDER MAX If necessary losen the hinge srews (red circles) and set the door to the best position. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 29 CAN-AM DEFENDER MAX Adjust the rear left door stop assembly into the best position and tigheten the screws hard. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 30 CAN-AM DEFENDER MAX Install the gas spring holder onto UTV roll cage and fix with included fixing assembly. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 31 CAN-AM DEFENDER MAX Install the gas spring pins and fix with included washers, screws and covers. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 32 CAN-AM DEFENDER MAX Install the gas spring onto the gas spring pins. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 33 CAN-AM DEFENDER MAX Repeat previous steps with right rear door. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 34 CAN-AM DEFENDER MAX LEFT FRONT DOOR + RIGHT FRONT DOOR Unscrew the cover fixing screws (red cricles) and uninstall the plactic cover. Save the fixing assemblies for later usage. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 35 CAN-AM DEFENDER MAX Remove the plastic cover HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 36 CAN-AM DEFENDER MAX Install the bottom left front door hinge and fix onto UTV roll cage with included fixing assemblies. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 37 CAN-AM DEFENDER MAX Remove the hinge cover (red rectangle) HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 38 CAN-AM DEFENDER MAX Place the plastic cover back to the correct position and fix with original fixing assemblies. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 39 CAN-AM DEFENDER MAX Install the upper left front door hinge and fix onto UTV roll cage with included fixing assemblies. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 40 CAN-AM DEFENDER MAX Install the door stop assembly into the front left door stop holder. Fix with included fixing assemblies. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 41 CAN-AM DEFENDER MAX Place the left front door stop assembly onto the left front console and fix with included fixing assemblies. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 42 CAN-AM DEFENDER MAX Place the left front door onto the hinges. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 43 CAN-AM DEFENDER MAX If necessary losen the hinge srews (red circles) and set the door to the best position. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 44 CAN-AM DEFENDER MAX Adjust the left front door stop assembly into the best position and tigheten the screws hard. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 45 CAN-AM DEFENDER MAX Install the gas spring holder onto UTV roll cage and fix with included fixing assembly. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 46 CAN-AM DEFENDER MAX Install the gas spring pins onto gas spring holders a fix with included washers, nuts and covers. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 47 CAN-AM DEFENDER MAX Install the the gas spring onto the gas spring pins. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 48 CAN-AM DEFENDER MAX Repeat previous steps with right front door. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 49 CAN-AM DEFENDER MAX ELECTROINSTALLATION WIPER/WASHER Install the washer tank holder to the rear part of vehicle (red circle). Carefully unistall the central tunel cover. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 50 CAN-AM DEFENDER MAX Lead the washer harness through the central tunel and under the dashboard. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 51 CAN-AM DEFENDER MAX Install the washer tank onto the washer tank holder and connect the washer motor to the washer harness. DETAILED VIEW HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 52 CAN-AM DEFENDER MAX Carefully cut of the dashboard switch blank. Lead the wiper/washer switch harness branch through the dashboard. Connect the wiper/washer switch with the wiper/washer switch harness branch and press the switch into the dashboard. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 53 CAN-AM DEFENDER MAX Drill the hole Ø16 mm into the upper part of the dashboard. Install the grommet into the hole. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 54 CAN-AM DEFENDER MAX Lead the wiper motor harness branch with the washer tube around the UTV roller cage to the wiper motor. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 55 CAN-AM DEFENDER MAX Install the harness cover ledge into the position and fix by included fixing assemblies. Lead the washer tube through the front glass and connect the tube to the washer jet. Connect the wiper harness branch to the wiper motor. DETAILED VIEW HardCabs 630-324-8585 www.hardcabs.com...
  • Page 56 CAN-AM DEFENDER MAX Connect the wiper washer harness to the UTV original electroinstalation. FILL THE WASHER TANK WITH THE WASHER LIQUID BEFORE FIRST USE. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 57 CAN-AM DEFENDER MAX ELECTROINSTALLATION HEATER IMPORTANT IT IS ABSOLUTELY NECESSARY TO TAKE OUT THE RUBBER PLUGS FROM THE HEATER TUBES!!! HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 58 CAN-AM DEFENDER MAX Uninstall front floor cover from the UTV. Cut the hole 12cmx12cm to the bottom part. DETAILED VIEW Install the cover back. SEE NEXT PAGES HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 59 CAN-AM DEFENDER MAX Before drilling holes, check the space under the dashboard, and if necessary take the harness out of the way to prevent damage. Cut two holes Ø55mm into the dasboard for the air vents … lead the hot air hoses through DETAILED VIEWS HardCabs 630-324-8585 www.hardcabs.com...
  • Page 60 CAN-AM DEFENDER MAX Lead the hot water tube with the el.valve to the front radiator(red arrow). DETAILED VIEW Cut the hot water hose and install the hot watter pump, fix the hot water pump by tightening straps and tighten hard. Connect the hot water pump to the pump harness and lead the harness back to the heater.
  • Page 61 CAN-AM DEFENDER MAX Secure the original cooling system hot water hose by clamps (not included), cut the hose and install included “Y” coupling into the hose. Connect the heater hose to the coupling and fix all ends by inlcuded tightening straps. Cut the hose with the air vent to the correct length.
  • Page 62 Repeat this procedure until heater/cooling system is completely bleeded out. The DFK Cab heater, like the heater in a car, generates heat from the vehicle’s engine. In nearly all cases, the heater should generate enough heat from your UTV, side by side, or tractor engine that you may need to turn the heater off periodically otherwise the air in the cabin may be too hot.
  • Page 63 CAN-AM DEFENDER MAX Secure the original cooling system cold water hose by clamps (not included), cut the hose and install included “Y” coupling into the hose. Connect the heater hose to the coupling and fix all ends by inlcuded tightening straps. Connect the el, valve to the el.valve harness branch.
  • Page 64 CAN-AM DEFENDER MAX Connect the heater to the heater harness branch. DETAILED VIEW Install the heater holder onto the heater and fix by included screws and washers. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 65 CAN-AM DEFENDER MAX Place the heater assembly onto the UTV floor and fix by icluded fixing assemblies. It is necessary to drill holes for the rubber nuts in accordance with the heater holder holes. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 66 CAN-AM DEFENDER MAX Connect the prepared hot air hoses PVC to the heater vens and fix by included Al. tape. DETAILED VIEW Prepare two shorter pieces of the hot air hose PVC to the rest of heater vents and fix by al. tape. DETAILED VIEW HardCabs 630-324-8585...
  • Page 67 CAN-AM DEFENDER MAX Connect the valve harness and the pump to the pre-installed valve switch. Connect the heater harness to the heater switch base. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 68 CAN-AM DEFENDER MAX Cut the hot air hoses PVC to the correct length, connect the hoses to the air vent and fix by tightening straps. DETAILED VIEW Repeat previous step with the dashboard air vents and press the vents into the dashboard. HardCabs 630-324-8585 www.hardcabs.com...
  • Page 69 CAN-AM DEFENDER MAX Lead the harness under the dashboard and connect the heater harness to the original electroinstalation. SEE NEXT PAGES HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
  • Page 70 CAN-AM DEFENDER MAX Place the heater cover with all tubes and harnesses connected into the best position and fix it by included rubber rivets. If necessary drill holes Ø8mm for the rubber rivets. HardCabs 630-324-8585 www.hardcabs.com 2464 Wisconsin Ave. Downers Grove, IL 60515 info@hardcabs.com...
