OST iConverter 8867-2 User Manual

The transmitter optical output power and receiver optical sensitivity values can be
obtained from the manufacturers of the respective equipment. Please consult the
iConverter data sheets for CWDM/AD optical specifications.
For more information, access Omnitron's documentation download web page to
view all relevant documents:
http://www.omnitron-systems.com/downloads.php
Model Number
Channel Port
Model Number
ITU Center Wavelength (nm)
8867-1 Add/Drop lower band (1271 to 1451)
8867-2 Add/Drop upper band (1471 to 1611)
8867-27 to -45 Add/Drop any one channel between 1271 and 1451
8867-47 to -61 Add/Drop any one channel between 1471 and 1611
8868-27 to -45 Add/Drop any two channels between 1271 and 1451
8869-47 to 61 Add/Drop any two channels between 1471 and 1611
iConverter
See CWDM/AD 1 and 2 Channel Optical Add/Drop Multiplexer Data Sheet (091-18867-001) for
exact model numbers.
Warranty
The operating description in this Instruction Manual is for use by qualified personnel only. To avoid electrical
shock, do not perform any servicing of this unit other than that contained in the operating instructions,
unless you are qualified and certified to do so by Omnitron Systems Technology.
This product is warranted to the original purchaser against defects in material and workmanship for
a period of ONE YEAR from the date of shipment. You may register your product on the Internet at
http://www.omnitron-systems.com. During the warranty period, Omnitron will, at its option, repair or
replace a product which is proven to be defective.
For warranty service, the product must be sent to an Omnitron designated facility, at Buyer's expense.
Omnitron will pay the shipping charge to return the product to Buyer's designated US address using
Omnitron's standard shipping method.
Limitation of Warranty
The foregoing warranty shall not apply to defects resulting from improper or inadequate use and/
or maintenance of the equipment by Buyer, Buyer-supplied equipment, Buyer-supplied interfacing,
unauthorized modifications or tampering with equipment (including removal of equipment cover by
personnel not specifically authorized and certified by Omnitron), or misuse, or operating outside the
environmental specification of the product (including but not limited to voltage, ambient temperature,
radiation, unusual dust, etc.), or improper site preparation or maintenance.
No other warranty is expressed or implied. Omnitron specifically disclaims the implied warranties of
merchantability and fitness for any particular purpose.
Exclusive Remedies
The remedies provided herein are the Buyer's sole and exclusive remedies. Omnitron shall not be liable
for any direct, indirect, special, incidental, or consequential damages, whether based on contract, tort,
or any legal theory.
Omnitron Systems Technology * 140 Technology Dr. #500 * Irvine, CA 92618
949.250.6510 tel * 949.250.6514 fax * www.omnitron-systems.com
Common Port
ITU Center Wavelength (nm)
1271 to 1611
1271 to 1611
1271 to 1451
1471 to 1611
1271 to 1451
1471 to 1611
WARNING
Warranty
040-08867-001C 12/10
iConverter CWDM/AD
1 and 2 Channel Add/Drop Multiplexers for Fiber Pair
USER MANUAL
Port Definitions
Figure 1: Front Panel View of a 1-Channel CWDM/AD module
Figure 2: Front Panel View of a 2-Channel CWDM/AD module
Product Overview
iConverter CWDM/AD modules are Course
Wave Division Multiplexing (CWDM) Optical
Add/Drop Multiplexers (OADM). The
CWDM/AD modules add (multiplex) and
drop (demultiplex) selected channels, or
wavelengths, on both directions of a CWDM
fiber link. Access points can be added to
linear, bus, and ring networks.
Page 1
