OPERATOR'S MANUAL
®
HeartOn T15
AED Trainer
www.medianadefib.co.uk
Distributed by:
Reliance Medical LTD, West Avenue,
Talke, Stoke-on-Trent, Staffordshire,
ST7 1TL, United Kindom.
Part Number: A7427-0
Revised Date: 0814
Copyright © 2014 All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HeartOn T15 and is the answer not in the manual?

Questions and answers

Summary of Contents for Mediana HeartOn T15

  • Page 1 OPERATOR’S MANUAL ® HeartOn T15 AED Trainer www.medianadefib.co.uk Distributed by: Reliance Medical LTD, West Avenue, Talke, Stoke-on-Trent, Staffordshire, ST7 1TL, United Kindom. Part Number: A7427-0 Revised Date: 0814 Copyright © 2014 All rights reserved.
  • Page 2 This page is intentionally left blank.

  • Page 3: Table Of Contents

    Remote control ............................13 List of Components ............................13 Figures Figure 1. HeartOn T15 Components and Controls ....................3 Figure 2. HeartOn T15-G4 Components and Controls ..................3 Figure 3. Side and bottom panel of AED Trainer ....................4 Figure 4. Training Pads ............................4 Figure 5.

  • Page 4: Configuration Of Aed Trainer

    AED Trainer is pre-configured with 10 training scenarios that simulate realistic sudden cardiac arrest episodes. The 1 scenario can be simulated at first by using the MEDIANA OPTION button of the l remote control. (HeartOn T15 only. The MEDIANA OPTION button press is ignored on HeartOn T15-G4.)

  • Page 5: Description Of The Aed Trainer

    Description of the AED Trainer Components and Controls Figure 1. HeartOn T15 Components and Controls Figure 2. HeartOn T15-G4 Components and Controls...

  • Page 6: Figure 3. Side And Bottom Panel Of Aed Trainer

    Slide button is used to open the cover and turn on by Slide button pushing the slide button to right. SD card port is not used in HeartOn T15 and HeartOn T15- SD card port Infrared Infrared communication port is used to communicate with communication port the remote control.

  • Page 7: Table 2. Hearton T15 Action Icon

    Table 2. HeartOn T15 Action Icon Action icon Voice prompt “Check for response. Are you right?” “Call for help.” “Open the airway.” “Check breathing.” “Remove clothes from the patient’s chest. Place pads exactly as shown in the picture. Press pads firmly to patient’s bare chest.”...

  • Page 8: Remote Control

    Table 3. HeartOn T15-G4 Action Icon Action icon Voice prompt “Remove clothes from the patient’s chest. Place pads exactly as shown in the picture. Press pads firmly to patient’s bare chest.” “Plug in pads. Insert connector firmly.” “Adult pads” or “Pediatric pads”...

  • Page 9: Table 4. Aed Trainer Remote Control

    Motion artifact button Poor pad condition button Not used in HeartOn T15 and HeartOn T15-G4. Low battery condition button Error condition button Resumption button Freeze button MEDIANA OPTION button (HeartOn T15 only. The MEDIANA OPTION button press is ignored on HeartOn T15-G4.)

  • Page 10: Using The Aed Trainer

    MEDIANA OPTION button is toggles between starting point from the checking patient’s consciousness and starting point from the beginning part. (HeartOn T15 only. The MEDIANA OPTION button press is ignored on HeartOn T15-G4.) Note: When the pads are not connected during scenario simulation, the audio prompt...

  • Page 11: Custom Scenario

    Custom Scenario The default custom scenario is simulated if the custom scenario setting is not changed by user. Changing Custom Scenario 1. Open the external DIP switch box at bottom panel. 2. Place the 5 and 6 pin of the External DIP Switch to down position to activate custom scenario function.

  • Page 12: Table 6. Scenario

    CPR(30:2, 5CYCLE) * HeartOn T15 only. The MEDIANA OPTION button press is ignored on HeartOn T15-G4. Note: When the standard scenario is selected, AED trainer starts the simulation from ‘Analyzing rhythm’ step. To start the simulation from ‘Checking patient’s consciousness’ step, select the desired standard scenario after pressing the MEDIANA OPTION button on the remote control.

  • Page 13: Table 7. Scenario (Continued)

    Table 7. Scenario (continued) Scenario 6 Scenario 7 Scenario 8 Scenario 9 Scenario 10 Checking patient’s Checking Checking patient’s Checking patient’s Checking patient’s consciousness patient’s consciousness consciousness consciousness consciousness Calling to EMS Calling to EMS Calling to EMS Calling to EMS Calling to EMS Open the airway Open the airway...
  • Page 14 CPR(30:2, 5CYCLE) * HeartOn T15 only. The MEDIANA OPTION button press is ignored on HeartOn T15-G4. Note: When the standard scenario is selected, AED trainer starts the simulation from ‘Analyzing rhythm’ step. To start the simulation from ‘Checking patient’s consciousness’ step, select the desired standard scenario after pressing the MEDIANA OPTION button on the remote control.

  • Page 15: Maintenance

    Static Current : < 5uA l Maximum Current : < 10mA List of Components Description Q’ty Unit HeartOn T15 (including the battery) HeartOn T15-G4 (including the battery) Remote control Training pad for adult/pediatric (It can use 100 times) Operator’s manual Storage bag (Nylon Bag)
