Installation Instructions
02'+ RSX Sport Pedals (Manual)
Contents:
Tools Required: 7mm socket wrench, Phillips screw driver or power drill with Phillips attachment
Disclaimer: Please use caution and proper safety equipment when using power tools, Strut King
and its affiliates are not responsible for any injuries occurred during installation.
1.
2.
SK06-HPDL-RMT01
1x Gas Pedal
1x Footrest
2x Brake/Clutch Pedal
2x Brake/Clutch Rubber Insert 2x Drill Bit
10x Self-tapping screws
8x Bolts (6 short, 2 long)
8x Locking Nuts
Place the stainless steel gas pedal cover
over the existing plastic pedal. Using the
power drill, drill 4 holes where at the
mounting locations on the pedal. Install the
two self-tapping screw onto the top
locations. The bottom two holes require
the use of the longer bolts & nuts. They
should extend out the opposite end just
enough for the nuts. The self tapping screws
can be used on the bottom two mounting
locations but the use of nuts & bolts are
highly suggested.
Remove the stock rubber pads on the
brake & clutch pedal.
1 of 2
Advertisement
Table of Contents
Summary of Contents for Strut King SK06-HPDL-RMT01
-
Page 1: Installation Instructions
Tools Required: 7mm socket wrench, Phillips screw driver or power drill with Phillips attachment Disclaimer: Please use caution and proper safety equipment when using power tools, Strut King and its affiliates are not responsible for any injuries occurred during installation. - Page 2 Place one of the brake/clutch pedals over the clutch to use as a template. Using the provided drill bit, drill the 3 holes needed. The brake pedal has existing holes that need to be enlarged. Using the provided drill bit, enlarge the existing holes to the needed size.
