Page 3: Table Of Contents
Index Technical safety instructions ................................ 4 Qualified staff ................4 Disclaimer of liability..................................4 Email service ................4 Authorizations ................5 Installation ....................................... 6 Safety information ................6 Environmental conditions ..............6 Degree of protection ................ 6 Power supply ................6 Digital and analog inputs .............. -
Page 4: Technical Safety Instructions
In no event shall Elbro AG or its suppliers be held liable for any loss of revenue or profits or for indirect, consequential or incidental reasons, whether for reasons (including negligence) arising out of or in connection with the use or inability to use the product, even if El-bro AG has been advised of the possibility of such damages. -
Page 5: Authorizations
Elbro. The use, copying, modification, disassembly or transmission of the software is prohibited, except as specifically authorized by this license. All rights not expressly authorised are reserved to Elbro AG and/or its suppliers. Any other trademark or pro-decret cited refers to its owner. -
Page 6: Installation
Installation In order to safeguard the safety and safety of the operator and the correct functioning of the device, the SMSB121TH device must be installed only and exclusively by a qualified person. The following standards must also be observed. Safety information •... -
Page 7: Dimensions / Interfaces
Dimensions / Interfaces 1. Stand-by RGB LED This LED indicates if device is running. In stand- by is flashing BLUE. When relay switching, it changes from GREEN (OFF) and (RED ON). 2. GSM/3G LED Indicates the status of the GSM/3G network. Status Meaning no service... -
Page 8: Installation Diagram
Installation diagram Power supply, relay outputs and digital inputs Analog input Pt100 Pt1000 0..10V 0..20mA probe probe probe probe probe LO O P LO O P 0 ..1 0 V +2 4 V G N D transm itter transm itter Connecting digital inputs Connect the inputs (as shown in the installation diagram) to contactors, contactors, contactors and/or electromechanical switches, in as-without electrical potential (clean contact) and following... -
Page 9: Inserting The Sim Card
Inserting the SIM Card Before you insert the SIM Card into your device, you must deactivate the PIN code with a mobile phone. It is also rec- ommended that the telephone answering machine and all addi- tional functions of the telephone operator are deactivated. Also make sure that your SIM card has credit and, if new, micro micro... -
Page 10: Programming
Programming Web-server link The SMSB121TH has a web server contained in the device itself. To connect to it, you must use a smartphone or an electronic device capable of con- necting to the Wi-Fi network. Each SMSB121TH has a unique SSID name (Wi-Fi network name). 1. -
Page 11: Sensors
Sensors SMSB121TH integrates a sensor able to keep under control the temperature and humidity of the room in which it is installed. Thanks to the "thermo- stat" and "hygrostat" functions, it is possible to program the threshold at which the relay is acti- vated automatically. -
Page 13: Relay Output
Relay output Response Message The relay can be operated from a console or via SMS (see chapter 'SMS commands'). When sending a power on or power off command, the SMSB121TH responds with a standard notification SMS ('ON' for 'COM-NO' status, 'OFF' for 'COM-NC') Telephone call The device is able to store a list of telephone numbers with the relative names (max 1000) enabled... -
Page 14: Periodic Status Message
Periodic status message This function allows you to send the enabled users a system status SMS periodically (daily, weekly or monthly). This mode is useful for monitoring a sys- tem or for preventing SIM cards from expiring (Switzerland). Users list This list contains the telephone numbers of users (up to 1000) authorized to receive alarm messages and SMS and email notification. -
Page 15: Settings
Settings Wi-Fi Access Point(AP) Mode AP mode allows a device with Wi-Fi connectivity to connect to the SMSB121TH directly via its IP ad- dress of 192.168.4.1. By default, access is unpro- tected. Enter a password to protect the product. Station Mode(STA) This mode allows the device to connect directly to a personal Wi-Fi router. -
Page 16: Sms Commands
SMS commands SMSB121TH has a set of configuration and control commands that can be sent via text message. The command message is protected by a password (see system password chapter). The command message format is as follows: [PASSWORD]#[COMMAND] Password is always 4 characters and #: hash is a mandatory separator. You can replace it with the 'dot' character. -
Page 17: Technical Data
Sending SMS: 500mA Switching relays: 800mA GPRS/UMTS 1500mA Declaration of Conformity Elbro AG hereby declares that the product SMSB121TH complies with the essential requirements and other relevant provisions of the RED directive, in particular: 2014/53/EU (RED) 2014/30/UE (EMV) 2014/35/UE (LVD) FCC/CE/TELEC/KCC/SRRC/IC/NCC...
