Intelligent Micro Electron iReminder IME-B6 User Manual

Multiple iReminder
1 1
Introduction Introduction
The iReminder is the most effective loss prevention solution
IME-B6
for your BLE iPhone/iPad, ex. iPhone 4S/New iPad/ iPhone5/iPad
mini. It is an "electronic leash" that notifies you with an audible
alarm whenever your iPhone/New iPad leaves your vicinity
(Out-of-Range) or whenever you leave your BLE iPhone/iPad
behind . The iReminder SB10 also assists you in locating your
misplaced BLE devices within a 65' radius (FindMe function).
2
Specification
Communication Standard Bluetooth®
Frequency Range 2.4GHz～2.4835GHz
Search Range 65 ft /20m (*Distance will vary depending on terrain and other factors.)
Alert Range 7~30 feet adjustable
Battery Type CR2032x1
Battery Life 6 months
Weight 9.5g
Dimension 61.5x36x11.6mm (2.42x1.42x0.46inch)
Working Temperature Temperature: 5℃～40℃、humidity: 20％～80％
3
Package components
A) iReminder
Unit x 1~4
IME-B6
C) Battery(CR 2032) x 1~4
If any components are missing from the package, please return
the product to your dealer immediately.
4 3
Product Description
Product description
Front
LED
Device FindMe
Button
Disable FindMe
Button Function
Enable FindMe
Button Function
Hold Switch
5
Quick Setup Guide
Quick setup guide
Step 1 - Download App "HiProx Multi"
Download "HiProx Multi" on App Store for free.
(Please search for HiProx Multi on App store, or search for BLE
and find the HiProx Multi application)
Step 2 - Enable Bluetooth on your iPhone/iPad
Go to Setting General
Step 3 - Place battery into iReminder Units
a. Open the battery cover by placing your thumb on the cover
(as shown) and pulling it backwards until it clicks open; then lift
off the cover.
(Figure 1)
b. Insert the battery into the battery compartment with the the "+"
sign on the battery facing up. Then replace the battery cover
by sliding it up into compartment opening.
Figure 1
Notice : Once the battery is inserted, the power will turn on
automatically and enter pairing mode. Green LED will blink per
second to indicate device is ready to pair.
4.0 Low Energy Wireless Technology
B) Key Chain Hock x 1~4
D) User Manual x 1
Back
Battery Cover
Key Chain Hock
Enable Bluetooth
(Figure 2)
Figure 2
User Manual
IME-B6
Step 4 - Run "HiProx Multi" application
a. Open "HiProx Multi" and tap the
corner to discover all avaiable devices.
b. "HiProx Multi" will pop up Bluetooth Pairing Request.
c. Select "Pair" from "Bluetooth Paring Request" for each device.
The Green LED light will blink once every 5 seconds in the
connecting mode.
d. Once the pairing process is completed, the iReminder
function is enabled.
Help
Discover New devices
Figure 3
Find Button
Setting Button
Figure 6
Step 5 - Test the iReminder
a. From MainView available devices table, you can tap desired
item to select that device. Once device has been selected,
button will appear in that row.
b. Press button, the iReminder unit will beep to do FindMe
function.
c. Set "Hold Switch" to "Left" from iReminder to enable "FindMe"
function. (Please refer to
d. Press "FindMe" button on the iReminder unit , and your BLE
device will beep.
e. Press and release "Find Me" button to stop the FindMe function.
f. Set alarm "threshold level" depends on the alarm distance you
like.
Step: Range Alarm Threshold
bar depends on the distance alarm you need.
g. Test your setup by placing the iPhone in a stationary location.
Then take the Reminder and walk away from the iPhone - when
you reach 7-30 feet from the iPhone, the Reminder will begin to
beep. If you move back into the range, the alarm will cease.
(Figure 8)
6
FindMe Function
To locate the missing item, tap green
device list. The missing device will continue beep for 5 secounds
from each request. Re-tap green
searching function.
Press and Release Device 'FindMe' button (hardware button
under the LED) will gernerate "FindMe Request" from that Device.
Your iOS device (iPhone / iPad...) will issue Alert sound contin-
uesly. Press and Release Device FindMe button to stop this
request.
Tap green button from iOS Device will Mute 'FindMe Request
Alert Sound.
Page 1
button in the upper right
(Figure 3)
(Figure 5)
Signal Indication
Figure 4
Battery Status
Change DeviceName
Figure 7
system
IME-B6
(Figure 6)
Product description Front picture)
4
Move the threshold
(Figure 7)
7-30 Feet
Figure 8
button from available
button again to continue
(Figure 4)
IME-B6
Figure 5
Enter Airplane
Mode
