Summary of Contents for mychway MS-6651
- Page 2 If the machine is over warranty, please also do not hesitate to contact us. we will assure you of our best service all the time. ◆How to contact us? Phone:(+86) 189 -487-55929 Tel: 0755-86368500 Email: sales@mychway.com This product does not belong to medical,please don’t use for disease treatment! - 2 -...
-
Page 3: Introduction To Manual
1. Introduction to Manual 1.1 Purpose This instructions for use manual provides a description of the system components, its controls and displays, instructions for its operation, and other equipment information important to the user Warning: Do Not operate this machine before reading this manual thoroughly. In addition to this manual,additional clinical training may be available by the company or your local distributor. -
Page 4: Technical Parameters
Treatment Safety 1. Treatment Time is less than 30mins/Body Part/Each Treatment. 2. The energy setting is from low to high gradually which should be subject to skin comfortableness for different people. 3. The patient had better wear the protective eye glasses. 4. - Page 5 Bipolar 3D SMART RF for face and eyes Power supply output:66V Freqeuncy:3MHz Power:30W Cryo Cooling head: Power supply output:66V Tempreture:5 ℃ - 0 ℃ Power:35W Red Wavelength:650 - 730 nm IV.How to install the accessories? A =Cooling head Socket B=Bipolar 3D RF Socket C=Quadrupolar 3D RF Socket D=Eightpolar 3D RF Socket E=Sextupolar Vacuum 3D Smart RF Socket...
-
Page 6: Program Setting
Attention:please add water inside machine before turn on machine ,otherwise it will burned machine .when you add water , remember connect Cooling head with machine . Also please clear it dry after you filling water ,just in case it has water around machine. V Program Setting 1. - Page 7 2.Click any place of the screen to enter into the main interface. 40K Cavitation 1. Press button to enter into 40k unoisetion function display as follow: - 7 -...
- Page 8 2. Please click to set working time. 3. Please click to increase or decrease the ENERGY 4. Please click to chose working model. 5. Please click to start or pause function. 6. Please click to come back to the main function interface. B.
- Page 9 2. Please click to set working time. 3. Please click to increase or decrease the RF ENERGY. 4. Please click to set the time for the suction and release. 5. Please click M1, M2, M3, M4,M5 to choose the model. 6.
- Page 10 1. Press button then login BODY RF operation display as bellow: 2. Please click to set working time. 3. Please click to increase or decrease the RF ENERGY. 4. Please click to start or pause function. 5. Please click to come back to the main function interface. Quadrupolar 3D RF - 10 -...
- Page 11 1. Press button then login Face Radio Frequency operation display 2.Please Click to choose Function of head . 3. Please click to set working time. 4. Please click to increase or decrease the ENERGY. 5 Please click to start or pause function. 6.
- Page 12 E. Eye Radio Frequency 1. Press button then login Eye Radio Frequency operation display. Please click to set working time. 3. Please click to increase or decrease the RF ENERGY. 4. Please click to start or pause function. 5. Please click to come back to the main function interface.
- Page 13 2.Please click to set working time . 3.The temperature of cooling head is 0~5. 4. Please click to start or pause function. . Please click to come back to the main function interface. About Treatment 1）Abdomen, thigh, buttock, arms slimming Please clean the skin and then put the ultrasound gel on the treatment area, then turn on the machine, set the time and energy.
- Page 14 the best comfortable temperature, then follow this steps: 1. Use the Body RF head 5 mins. 2. Use the unoisetion 40k cavitation head 20-25mins. 3. Use the RF Vacuum head 10-15mins. 4. Use the Body RF head 15~20 mins. 5.Use the Cooling head 10-15mins. Work time: 2-3 times/ week 2）Face, eyes around, neck skin lifting: Please clean the skin and then put the rf gel on the treatment area, then turn on the machine , set...
- Page 15 3. Massage the triangle zone of both sides of the face in circles. 4. Massage from jaw to angulus oris to ear in lines. THIGH Treated time: 30 minutes 1. From down to upper, pushing to the groin to dredge the lymph. 2.
- Page 16 Treated time: 20 to 30 minutes 1. Along the lymph direction, pulling to the waist. 2. From upper to down, by anticlockwise gesture, pull come-and-go. 3. Along the muscle of arm, pull up to lift and tight the muscle. BACK Treated time: 20 to 30 minutes 1.
- Page 17 4. Using lymph drainage gesture, pull the toxin to the lymph node, can help improving the back curve. - 17 -...
- Page 18 - 18 -...
- Page 19 Package Listing : 1 x Main Machine 1 x Unoisetion Probe 1 x Sextupolar Vacuum 3D SMART Probe RF for Body Slimming 1 x Octupole 3D SMART RF Probe for Body Sculpture 1 x Quadrupole 3DSMART RF Probe for Arm/face/small area of body 1 x Bipolar 3D SMART RF Probe for face and eyes 1 x Cooling head 1 x Holder...
- Page 20 Cleaning and Care : 1.Please clear each handle after one treatment .since there has many Gel on head during treatment . 2.Please change water every one week . 3.Please clear filter once you see dirty thing inside it . 4.Conservation methods:a cool dark dry preservation. - 20 -...
