Sams ADVIN-1 User Manual For Use And Maintenance

Sdi/multiformat analog logo inserter

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

ENGLISH

Z10-3 edition 1

Code: 004.100

ADVIN-1

SDI / multiformat analog logo inserter

USER MANUAL FOR USE AND MAINTENANCE

Read the instructions before using the device.

Keep this manual for periodic usage.

Sams elektronik d.o.o.

48 Zivka Davidovica st.

11050 Belgrade

Serbia

Tel/Fax: +381 11 3806 253

+381 11 2402 212

sams@sams.rs

www.sams.rs

Published: 15. july 2008.

Updated: 03. november 2014.

Table of Contents

Need help?

Do you have a question about the ADVIN-1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Sams ADVIN-1

Page 1 Keep this manual for periodic usage. Sams elektronik d.o.o. 48 Zivka Davidovica st. 11050 Belgrade Serbia Tel/Fax: +381 11 3806 253 +381 11 2402 212 sams@sams.rs www.sams.rs Copyright © 1999 - 2014 Sams elektronik d.o.o. Published: 15. july 2008. Updated: 03. november 2014.
Page 2 Any technical failure or deficiency that occurs during the warranty period specified on the invoice of the purchased equipment will be inspected and serviced by Sams elektronik doo or an authorized service center of the manufacturer, with the conditions set out in the warranty statement.
Page 3 CLASS I DEVICE Grounding is connected to the chassis of the device. The power supply is protected with fuse against overload. Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs ADVIN...
Page 4 Design and specifications of the device may change without prior notice. TECHNICAL SUPPORT AND SERVICE Sams elektronik has made every effort to ensure that the equipment works in perfect condition. In the event that problems that occur can not be resolved, or if you have any questions regarding this...
Page 5: Table Of Contents
CABLE WIRING BETWEEN DEVICE AND REMOTE CONTROL ..........31 CABLE WIRING FOR CONNECTION TO PC ...............31 CABLE WIRING BETWEEN THE LOGO INSERTER AND DigiTIM-1 ........31 GPI / TALLY PINOUT ......................31 NOTES .........................32 Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs ADVIN...
Page 6: Unpacking And Installation
Strictly comply to all steps for proper connection of devices in the system. Places for fastening MAINTENANCE The system maintains only person authorized by Sams elektronik doo. Any voluntarily opening device, upgrading or servicing is strictly prohibited and is subject to warranty void, and the possibility of injury.
Page 7: Description
Control of device via network trought web browser GPI control and TALY The ADVIN-1 is device witch stores and recalls up to 229 individual, dynamically positionable logos from multiformat analog or digital to multiformat analog or digital program signal. It supports real-time play back of video, and can store animated logos lasting up to 9 seconds.
Page 8: Installation
Analog input input output Connector for connection to the remote control External reference input (be sure to connect Device supports signal generator (like Sams MSG-2). remote control before power switch NOTE is pressed) Presence of external reference is mandatory! Connect the device...
Page 9 INPUT OUTPUT PROGRAM PROGRAM CVBS CVBS EXT. REF. EXT. REF. SDI -> SDI PREVIEW DIGITAL DIGITAL G, Y B, U, R, V, INPUT OUTPUT PROGRAM PROGRAM CVBS CVBS EXT. REF. EXT. REF. Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs ADVIN...
Page 10: Block Diagram
RS 232 WEB SERVER EQ & PLL EDH & BB GENLOCK FADER LOGO GPI A FILL SD RAM MIXER GPI B LOGO STORE FLASH FLASH ADVIN-1 TALLY logo on TALLY no signal Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs ADVIN...
Page 11: Network Setup
NETWORK ACCESS AND DEVICE CONTROL The device can be configured through the web browser. First, the device must be found in the local network. To do this, start the Sams Netfinder software double clicking on the icon. The software first scans for devices.
Page 12: Playlist Selection
Transparency - this option sets the level of transparency of logo. The value is within the range of 0 to 100. The value is entered in the box next to the button, after which it is necessary to click with mouse button (do nor press ENTER/RETURN). Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs ADVIN...
Page 13: Logo Position
- Convert to 8-bit palette (Indexed colors) - Select logo (Ctrl+click on layer) -> Meni: SELECT -> INVERSE (Shift+Ctrl+I) - Paint background in BLACK (R:0 G:0 B: 0) - Save As BMP. Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs ADVIN...
Page 14 Palette. The most important thing is that to select an option Black and White in settings „Forced“. In this way BLACK will be the key. Picture 4 Logo edges will be without Anti-aliasing. Select layer (Ctrl+click on layer) -> Meni: SELECT -> INVERSE (Shift+Ctrl+I) Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs ADVIN...
Page 15 Picture 6 - Inverse selection Paint background in black (R:0 G:0 B:0) (Picture 7) Picture 7 Save As BMP In BMP options select Windows File format and 8 bit Depth. Click on OK. Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs ADVIN...
Page 16: Pay Attention Before Inserting Logo
- On left and right edges appears green and magenta - Change Aspect Ratio to 1.09 or change the width of 2px. - Parts of logo “flicker” - correct logo in the parts that height have an odd number of pixels. Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs ADVIN...
Page 17: Software
CTRL key to select individual or SHIFT for group of images. After selecting press “>”. If you want all images in the folder to add click on the button “>>”. After that, the software will ask from Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs ADVIN...
Page 18: Remote Control
V.Pos: 40 Menu ON - to activate the logo in program with defined FADE IN time. LOGO test_001 LogoLvl: 80 Menu LOGO LogoLvl: 80 OFF - turn off logo from program Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs ADVIN...
Page 19: Joint Control Of Inserters
Step: test_001 test_001 Logo: test_001 LOGO/TIME HoldTime test_001 test_001 ON/OFF 00:00.00 H.Pos: 25 POSITION POSITION V.Pos: 40 test_001 Menu LOGO TIME LogoLvl: 80 Dual remote control panel for inserters IR-1d www.sams.rs Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs ADVIN...
Page 20: Lcd Touch Screen - Description
V. POS - represents the vertical position of the currently active macro. Values are changing in relation Logo < > to the selected corner. Level LOGO LVL - is the level of transparency of currently active macro. FadeIn Exit Show Exit Exit Time Logo PlayList Position Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs ADVIN...
Page 21: Macro Configuration
Exit 00:00.00 PlayList Select Logo Edit Position Anim Select Logo Exit Hor. Pos Exit Exit Exit Logo: Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs Ver.Pos: 40 ADVIN Step: Select Step Logo: test_001 test_001 Step Step: Step dit HoldTime Edit HoldTime...
Page 22: Adjust Logo Level
H. Phase SC Phase Macro Get Logo Edit CVBS Anim Anim Exit Exit Exit Adjust Select input LogoLvl Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs ADVIN Edit HoldTime Edit HoldTime Step: Step: Adjust Edit HoldTime HoldTime HV Pos. CVBS&Y/C 00:00.00 00:00.00...
Page 23: Adjust Hv Position
Exit Show Exit Exit Position Time Gpi B Logo Sel.Final Logo Open Level Logo: Gpi B test_001 FadeIn Exit Exit Exit Close Time t_001 Exit Exit Logo PlayList Position dTime 00.00 Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs ADVIN Exit...
Page 24: Play List
All that is behind the final frame is defined with a time 00:00.00, which the 00:00.00 device recognizes as the end of the animation, and start from the beginning. Once defined the last Anim image in the animation, press the OK button. Exit Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs ADVIN...
Page 25: Logo Position
The value is entered in FadeIn: 5.0s seconds. Shortest time for this effect is 0.1 and longest Exit Exit 25.5 seconds. After defining press the EXIT button. Exit Exit Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs ADVIN...
Page 26: Advanced Settings
Gpi A Close Show Exit Exit Edit LogoLvl Edit FadeIn Edit Position Gpi B LogoLvl: 80 FadeIn: 5.0s Hor.Pos: 25 Open Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs ADVIN Edit Position Hor. Pos Gpi B Ver.Pos: 40 Exit Exit Close...
Page 27: Software Support
- check the presence of the reference signal. This command gets the return value 1 or 0, where 1 - signal OK and 0 - signal ERROR. gpi_a_open - set the GPI Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs ADVIN...
Page 28 (problem with sending command in address bar, must press F5 - refresh to send) - AFTER SAVING (COMMAND PL_FLASH) FOR THE SELECTED MACRO, PLEASE CHANGE TO ANY MACRO AND RETURNED TO THE SAVED IN ORDER TO INITIALIZE SETUP. Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs ADVIN...
Page 29: Problems And Solutions In A Network Environment
If the software NETFINDER is not able to locate the device in the network try the following: 1. Right click on Local Area Connection 2. Select option “Change Windows Firewall settings” 3. When a window “Windows Firewall” opens select tab “Exceptions” 4. Click on button “Add program” Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs ADVIN...
Page 30 13. In the IP Address field enter 192.168.0.200 (can be some other IP) 14. Connect the UTP cable to the computer and the other side to the device. 15. Turn on device. 16. Wait the computer to show “10mb connected...” Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs ADVIN...
Page 31: Cable Wiring Between Device And Remote Control
GPI A, GPI B - Setting the GPI button TALLY A - LED is on when there is no incoming signal TALLY B - LED is on when the logo is on Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs ADVIN...
Page 32: Notes
Inserters elektronik NOTES Sams elektronik d.o.o. • sams@sams.rs • www.sams.rs ADVIN...
