- Page 1 ETAN1 R01_EN XETK-S22.0B ECU Adapter, SAMTEC ERM - SAMTEC SFM (40mc - 12fc), 0m150...
- Page 2 The data in this document may not be altered or amended without special notification from ETAS GmbH. ETAS GmbH undertakes no further obligation in relation to this docu- ment. The software described in it can only be used if the customer is in possession of a general license agreement or single license.
-
Page 3: Table Of Contents
Mechanical Dimensions ....................7 Temperature Range ....................... 7 Ordering Information ......................8 ETAS Contact Addresses ....................... 9 ETAN1 R01_EN XETK-S22.0B ECU Adapter, SAMTEC ERM - SAMTEC SFM (40mc - 12fc), 0m150... - Page 4 ETAS Figures Figures Figure 1: 3D View ............................ 5 Figure 2: Pin arrangement ........................6 Figure 3: Bottom View, Units inches [mm] ..................... 7 Figure 4: Side View, Units inches [mm] ....................7 ETAN1 R01_EN XETK-S22.0B ECU Adapter, SAMTEC ERM - SAMTEC SFM (40mc - 12fc), 0m150...
-
Page 5: Introduction
Introduction The ETAN1A cable adapts the ECU 12 pin SAMTEC TFM-106 connector to an XETK-S22.0B. 3D View Figure 1: 3D View ETAN1 R01_EN XETK-S22.0B ECU Adapter, SAMTEC ERM - SAMTEC SFM (40mc - 12fc), 0m150... -
Page 6: Technical Data
Technical Data ECU Connector In order to be able to use the ETK adapter cable ETAN1A in the ECU, a 12 pin SAMTEC connector (e.g. TFM-106-02-S-D-P) must be available on the ECU. Depending on ECU connector lead style mated height is between 6,35mm and 11,81mm (distance between the PCB’s). -
Page 7: Mechanical Dimensions
Mechanical Dimensions The ETAN1A adapter cable has a minimum bend radius of 0.125 inches [3.175mm]. See figure 3 and figure 4 for mechanical dimensions. Figure 3: Bottom View, Units inches [mm] Figure 4: Side View, Units inches [mm] Temperature Range... -
Page 8: Ordering Information
Ordering Information Short Name Order - Number ETAN1A F 00K 110 951 ETAN1 R01_EN XETK-S22.0B ECU Adapter, SAMTEC ERM - SAMTEC SFM (40mc - 12fc), 0m150... -
Page 9: Etas Contact Addresses
Germany WWW: www.etas.com ETAS Subsidiaries and Technical Support For details of your local sales office as well as your local technical support team and product hotlines, take a look at the ETAS website: ETAS subsidiaries WWW: www.etas.com/en/contact.php ETAS technical support WWW: www.etas.com/en/hotlines.php...
