Jack Sealey sm1311 Instructions

thank you for purchasing a sealey product. manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
refer to Wear eye
instruction protection
manual

1. saFetY

1.1.

electrical saFetY

WarninG! it is the user's responsibility to check the following:
‰
check all electrical equipment and appliances to ensure that they are safe before using. inspect power supply leads, plugs and
all electrical connections for wear and damage. sealey recommend that an rcd (residual current device) is used with all electrical
products. You may obtain an rcd by contacting your local sealey dealer.
if the product is used in the course of business duties, it must be maintained in a safe condition and routinely PAt (Portable
Appliance test) tested.
electrical safety information, it is important that the following information is read and understood.
1.1.1. ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply.
1.1.2. regularly inspect power supply cables and plugs for wear or damage and check all connections to ensure that they are secure.
1.1.3. important: Ensure that the voltage rating on the appliance suits the power supply to be used and that the plug is fitted with the
correct fuse - see fuse rating in these instructions.
DO nOt pull or carry the appliance by the power cable.
8
DO nOt pull the plug from the socket by the cable.
8
DO nOt use worn or damaged cables, plugs or connectors. ensure that any faulty item is repaired or is
8
replaced immediately by a qualified electrician.
1.1.4. This product is fitted with a BS1363/A 13 Amp 3 pin plug.
if the cable or plug is damaged during use, switch off the electricity supply and remove from use.
Ensure that repairs are carried out by a qualified electrician.
Replace a damaged plug with a BS1363/A 13 Amp 3 pin plug. If in doubt contact a qualified electrician.
a) Connect the GREEN/YELLOW earth wire to the earth terminal 'E'.
b) Connect the BROWN live wire to the live terminal 'L'.
c) Connect the BLUE neutral wire to the neutral terminal 'N'.
ensure that the cable outer sheath extends inside the cable restraint and that the restraint is tight.
Sealey recommend that repairs are carried out by a qualified electrician.
1.2. General saFetY
WarninG! disconnect the sm1311 from the mains power before changing accessories, servicing or performing any maintenance.
‰
locate the machine in a suitable working area. use the planer on a strong flat working surface. Keep area clean and tidy and free from
9
unrelated materials and ensure there is adequate lighting.
maintain in good condition (use an authorised service agent).
9
replace or repair damaged parts. use genuine parts only. unauthorised parts may be dangerous and will invalidate the warranty.
9
Keep the sm1311 clean for best and safest performance and check moving parts alignment regularly.
9
Wear an approved mask and eye, gloves, ear protection.
9
Handle loose blades with gloves or cloth as they are very sharp, but DO remove gloves and/or cloth before operating the SM1311.
9
Keep your hands and fingers away from the blade when operating.
9
remove ill fitting clothing. remove ties, watches, rings and other loose jewellery, and contain long hair.
9
maintain correct balance and footing. ensure the floor is not slippery and wear non-slip shoes.
9
ensure there are no foreign objects in the workpiece i.e. nails or screws.
9
DO nOt start with the workpiece touching the blade.
8
DO nOt use the sm1311 for a task it is not designed to perform.
8
DO nOt allow untrained persons to operate the sm1311, keep children and unauthorised persons away from the working area.
8
DO nOt get the sm1311 wet or use in damp or wet locations or areas where there is condensation.
8
DO nOt use sm1311 where there are flammable liquids, solids or gases such as paint solvents, waste wiping or cleaning rags etc.
8
DO nOt operate if any parts are damaged or missing as this may cause failure and/or possible personal injury.
8
DO nOt leave the sm1311 operating unattended.
8
DO nOt operate the sm1311 when you are tired or under the influence of alcohol, drugs or intoxicating medication.
8
DO nOt use without the appropriate guard in place and ensure it is correctly adjusted.
8
DO nOt use blades, which are blunt as this increases the danger of kickback.
8
Any portion of the cutter block not being used for planning shall be guarded.
9
When planing or thicknessing short workpieces, a push-stick should be used.
9
© Jack sealey limited
instructions for
planer/thicknesser 200 x 120mm
model no:
Wear ear Wear Wear a mask
protection protective
gloves
Original Language Version
sm1311
indoor use
only
recommended fuse rating
13 Amp
sM1311 | Issue:2 (H,F) 06/02/18
