- Page 1 COBALT SERIES NETWORK ANALYZER 4209, 4409 4220, 4420 INSTRUCTIONS FOR CONNECTING FREQUENCY EXTENDERS TO A VNA WITH A TM0082 MODULE SET May 2019...
-
Page 3: Table Of Contents
T A B L E O F C O N T E N T S Introduction ........................4 1 Safety Instructions ......................7 2 General Overview ......................8 2.1 Description........................8 2.2 Standard Operating Set ....................8 2.3 Specifications ........................ 11 2.4 Principle of Operation .................... -
Page 4: Introduction
Introduction This document is a supplement to the operating manual of the Cobalt Series Vector Network Analyzers. This instruction sheet describes the general procedure for connecting frequency extension modules of any manufacturer. The Cobalt Series includes analyzers with loops on the configurable front panel enabling direct connection of frequency extension modules. - Page 5 Figure 1.2 Vector Network Analyzer. Connection of the TM0082 Module. The frequency extender modules are connected to the analyzer via a booster module set, the purpose of which is to ensure the mechanical mating of the device connectors and to set an acceptable power level of RF, LO and IF signals in the path.
- Page 6 Maintenance and operation of the analyzer should be performed by qualified personnel with basic experience in operating of microwave circuits. The manufacturer is not responsible for any consequences resulting from misuse of the ana- lyzer, including violation of safety rules or other necessary precautions. Additional information about vector network analyzers is available on the website: https://coppermountaintech.com...
-
Page 7: Safety Instructions
1 Safety Instructions Additional safety instructions can be found in the operating manuals of the analyzer and the frequency extenders to be used. Devices such as analyzer, booster, power supply, and frequency extender (refer to figure 1.2) must be grounded using their power cables. It is recommended to connect terminal on the device with the ground bus bar. -
Page 8: General Overview
2 General Overview 2.1 Description Analyzers in combination with the devices illustrated in figure 1.2 form a unified measurement system of complex transmission and reflection coefficients (elements of the scattering matrix) of N-port networks with extending the operating frequency range upper limit. This is the mil- limeter wave frequency extension system. -
Page 9: Locking Bar
Description Quantity, pcs. Power supply Power supply – Power (control) cable – Note: Usage of a power supply, power (control) cable and coaxial attenuators depends on the module. Table 2.2 Four-port analyzer Description Quantity, pcs. Analyzer С4409 or С4420 Power cable USB cable Software Frequency Extension Module... - Page 10 Description Quantity, pcs. Power supply Power supply – Power (control) cable – Note: Usage of a Power supply, power (control) cable and coaxial attenuators depends on the module. Each of the previously listed analyzers has an AUX option (an additional functional capability), the presence of which is determined upon ordering.
-
Page 11: Specifications
2.3 Specifications Table 2.3 Analyzer specifications for operation with the frequency extender modules Parameter Value «PORT» OUTPUT Output frequency range: С4209, С4409 100 kHz to 9.0 GHz С4220, С4420 100 kHz to 20 GHz Output power range: С4209, С4409 –60 to +15 dBm С4220, С4420 –60 to +10 dBm «LO OUT»... - Page 12 Parameter Value Connection to PC: Connector type USB B Interface USB 2.0 Warm-up time 40 minutes Power supply 110 to 240 V, 50/60 Hz Power consumption С4209 75 W С4409 145 W С4220 145 W С4420 270 W Dimensions (length, width, height): 355 ...
- Page 13 Table 2.4 Technical specifications of the booster module set Parameter Value TM0082. BIAS TEES «RF+12VDC OUT», «LO+12VDC OUT» outputs: DC voltage 11.5 to 12.5 V Max DC current 0.5 А Connector type 3.5 mm, female «RF IN», «LO IN» inputs: Connector type 3.5 mm, female TM0082.
-
Page 14: If Cable
Parameter Value «RF OUT» output: Connector type 3,5 mm, female MAX INPUT SIGNAL LEVELS Damage level: «RF+12VDC OUT», «RF IN» +16 dBm «LO+12VDC OUT», «LO IN» «IF IN», «IF OUT» +13 dBm Damage DC voltage: «RF+12VDC OUT», «RF IN» 15 V «LO+12VDC OUT», «LO IN»... -
Page 15: Principle Of Operation
2.4 Principle of Operation This section provides a brief description of the analyzer, the frequency extender module and the booster module set needed to understand the operation of these devices. VECTOR NETWORK ANALYZER Analyzer functions: PORT Output of - Generation of RF (test) and LO signals, (RF OUT) signal necessary for the Module to function as... - Page 16 Frequency range RF.IN Frequency Input of Directional couplers multiplier RF IN PORT Multiplication factor signal Frequency range Power range x DF RF.IN RF.OUT RF.IN Amplifier Frequency range LO IN Reference Test LO.IN channel channel Multiplication factor Input of signal Power range LO.IN Frequency multiplier...
- Page 17 center conductor of cables to external RF - Increasing the upper limit of RF and LO and LO signal amplifiers. signals output power range of the Analyzer to +13 dBm Rigid cables to Test set RF, LO, IF cables Amplifiers Analyzer connect RF OUT +12VDC...
- Page 18 Figure 2.4 Typical gain RF and LO signal amplifiers Figure2.5 Typical gain IF signal amplifiers of test set Figure 2.6 Typical transmission coefficient (insertion loss) bias tees of test set...
- Page 19 Cable Test set Analyzer Module amplifiers RF OUT RF IN Frequency +12VDC G=8...13 dB RF cable PORT DF=3.9…20 GHz multiplier RF IN 3.5mm(f) SMA(m) (RF OUT) SMA(m) 3.5mm(f) +12VDC RF OUT RF IN 3.5mm(f) SMA(m) Adapter SMA(m) 2.92mm(f) 2.92mm(f) Cable -60…+10 dBm 0 dBm max RF.IN...
-
Page 20: Preparation For Use
3 Preparation for use 3.1 General information The maximum distance from the modules to the analyzer will depend on length of utilized RF, LO and IF cables and ability of the booster module set to provide the required extender mod- ules’... -
Page 21: Connection Procedure
4 Connection procedure CONNECTION: The analyzer and the TM0082 module should both be OFF while performing any connection of cables, adapters or external amplifiers. The maximum input power of the RF signal or the maximum DC peak voltage as indicated on the devices’ housing should not be exceeded, doing so may damage them. - Page 22 Follow ESD and safety precautions while operating the devices. Remove the front handles of both devices. Screw the locking bars into place. When the analyzer is powered OFF, connect the loops to the configurable front panel, if they were disconnected before. Consistently connect the analyzer to the PC using the USB cable, and then to AC power.
- Page 23 Main Menu > System > Misc Setup > Frequency Extender > Custom Make sure that after connecting the instrument to the software, frequency sweep is performing over operating frequency range of the analyzer, and there are no errors indicated. Select the measurement mode with the external modules.
- Page 24 Figure 4.8 Example diagram of TM0082 connection to an analyzer Connection Analyzer TM0082 PORT 1, PORT 2, RF1 IN, RF2 IN, PORT 3, PORT 4 RF3 IN, RF4 IN LO1 OUT, LO2 OUT, LO1 IN, LO2 IN, LO3 OUT, LO4 OUT LO3 IN, LO4 IN R1 IN, R2 IN, IF R1 OUT, IF R2 OUT,...
- Page 25 Connect all RF and LO cables to the “RF + 12VDC OUT” and “LO + 12VDC OUT” ports of TM0082. It is supposed that the specified parameters should be identical for each RF cable. Similar requirements are applied to the LO cables as well.
-
Page 26: Power Cable
Power level setting of �� and �� signals ����.���� ����.���� is performed by using the RF power meter (or power sensor) within frequency ranges ∆�� ����.���� and ∆�� accordingly. The recommended ����.���� power level of these signals is referred in the specification of the applied modules. - Page 27 Figure 4.10 Setting of LO power level according to power meter reading (amplifier’s output of RF signal is not connected) Main menu > System > Misc Setup > Frequency Extender > Custom Open the settings dialog window of the module. While gradually increasing the value of LO output power, set the required level of ��...
- Page 28 Switch the analyzer and TM0082 module OFF. Disconnect the power meter. Figure 4.11 Connect the amplifier to “LO IN” input port of the module via the adapter. Connect the power meter to RF signal path. Figure 4.11 Switch the analyzer and TM0082 ON. Leave the module in OFF condition.
- Page 29 Figure 4.11 Setting of RF power level according to power meter reading (LO signal amplifier should already be connected to the module; there is no need to connect the module to power supply) Set the stop frequency of ∆�� range. ����.������...
- Page 30 Figure 4.12 RF and LO signal amplifiers are connected to the module via adapters (module is OFF condition) Connect SHORT standard to test port of the module. Connect IF cable to “IF TEST” output port of Figure 4.13 the module (from the first port side of the analyzer only).
- Page 31 Switch the analyzer and TM0082 module ON. After connecting the analyzer to the software, set the start frequency of ∆�� range in CW ����.������ mode of the analyzer. Switch the module ON using the external – power supply or the analyzer as the power source (when it is possible).
- Page 32 Figure 4.14 Example diagram of module connection to test set from the first port side of analyzer Connection TM0082 Amplifier Module RF+12VDC IN → RF OUT RF+12VDC OUT RF IN RF+12VDC IN → RF OUT LO+12VDC OUT LO IN IF R1 IN –...
- Page 33 Keep the devices in ON condition for 1 hour. – Similarly repeat the power checking of the RF, LO and IF signals after warming up the devices. After checking, the modules can be connected with a device under test. Maximum module movement depends on –...
