DELTA Temp BREEZER MACH 4 Quick Manual

QUICK GUIDE
BREEZER MACH 4 - ADIABATIC COOLER
I. SETUP
1. Mounting the fan head:
• Lock each of the rear wheels by pressing down
on the brakes.
• Open the lid latch by first pulling forward the
lower portion of the latch.
• Remove tank lid by first lifting up on the
transport handle and then pulling forward.
2. Adding water to the water tank:
• Do not fill the water tank above the max fill
level, as shown. If water tank is filled past this
level, water may leak out of the water tank and
cause a hazard around the Breezer.
• The water valve can be adjusted for optimal
performance according to your climate.
Delta-Temp Belgium
Lange Ambachtstraat 13, 9860 Oosterzele
T: +32 (0)9 362 74 87
E : info@delta-temp.com
www.delta-temp.be
• Lift the fan head straight up and align it with
the fan head support pole. Once the fan head is
seated on the support pole, rotate the fan head
horizontally until you feel it engage with the
support pole.
• Once installed, the atomizer (metal disk) will
be facing the water tank, air will be blown over
the water tank when the Breezer is turned on.
3. Routing power and water lines and replace
tank lid:
• Route the fan head power cord, atomizer
drain hose, and water inlet hose through
the openings in the back of the water tank as
shown above.
• Slide the lid tab into the corresponding water
tank notch in the back of the water tank.
• Lower the front of the tank lid onto the water
tank and re-lock lid latch.
