Airfoil Kit Parts List & Installation Instructions
PARTS LIST
1
2
Item
4
3
Qty Description
1
1
Airfoil
ns
1
Hardware Kit
B61413 Hardware Kit
2
4
3/8-16 x 1 Hex Cap Screw G5
3
8
3/8 Hardened Flat Washer
4
4
3/8-16 Hex Locknut GC
ns = not shown
A DIVISION OF DOUGLAS DYNAMICS, L.L.C.
Part
B52092
B52093
B81041
Airfoil Kits
B52092 B52093 B81041
B61423 B61246 B81046
B61413
B61034
G = grade
B52092, B52093, B81041
April 15, 2007
Lit. No. 29729, Rev. 00
Airfoil Kit ID
Description
Model 8611
Model 760HD/800HD/860HD/810
Model 700LT/760LT
Part
90039
29233
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Douglas Dynamics Blizzard B52092
Summary of Contents for Douglas Dynamics Blizzard B52092
- Page 1 B61423 B61246 B81046 Hardware Kit B61413 B61413 Hardware Kit 3/8-16 x 1 Hex Cap Screw G5 90039 3/8 Hardened Flat Washer 29233 3/8-16 Hex Locknut GC B61034 ns = not shown G = grade A DIVISION OF DOUGLAS DYNAMICS, L.L.C.
-
Page 2: Installation Instructions
Tighten fasteners to 31 ft-lb. Copyright © 2007 Douglas Dynamics, L.L.C. All rights reserved. This material may not be reproduced or copied, in whole or in part, in any printed, mechanical, electronic, film or other distribution and storage media, without the written consent of Blizzard. Authorization to photocopy items for internal or personal use by the Blizzard outlets or snowplow owner is granted.
