Jayu QC-240 Owner's Manual

Hide thumbs

1.0 Engine safety instructions

1. Read owner's manual carefully and follow all directions. Be

thoroughly familiar with the controls and the proper use of the

equipment. Know how to disengage the controls and stop the engine .

2. Check fuel before starting the engine. Never fill fuel tank when engine

is running or hot. Fill fuel tank outdoors. Replace gasoline cap tightly

and wipe off and spilled gasoline before starting the engine.

The engine exhaust from this product contains chemicals to cause

cancer, birth defects or other reproductive harm.

3. Dress properly. Wear safety glasses or goggles. Do not wear loose

clothing or jewelry that could get caught in moving parts. Pants,

gloves and safety footwear are recommended.

4. Keep operation area clear of all persons, particularly children and

pets.

5. Never operate on wet grass. Keep both hands firmly on the handles

when blade is rotating, and walk, never run. Keep feet away from

cutting area. Watch what you are doing and use common sense.

6. Do not attempt to remove cut material when engine is running or

when cutting member is moving. Shut engine off, wait until blade

comes to a complete stop and disconnect the spark plug wire before

clearing material that may clog blade guard or cutting member. Never

hold any material to be cut.

7. Have repairs made by a qualified dealer or repairman. Use accessories

and attachment supplied or recommended by the manufacturer. See

that only identical replacement parts are used

2.0 OPERATIONG SAFETY INSTRUCTIONS

Warning

Table of Contents

Need help?

Do you have a question about the QC-240 and is the answer not in the manual?

Questions and answers

Summary of Contents for Jayu QC-240

Page 1 1.0 Engine safety instructions 1. Read owner’s manual carefully and follow all directions. Be thoroughly familiar with the controls and the proper use of the equipment. Know how to disengage the controls and stop the engine . 2. Check fuel before starting the engine. Never fill fuel tank when engine is running or hot.
Page 2 Start the engine carefully. Make certain all attachments are disengaged before starting the engine. Keep hands, feet and clothing away from blade and other moving parts. Never attempt to make any adjustments while engine is running. Do not operate when barefoot or wearing open sandals. Always wear safety footwear and pants that cover your legs.
Page 3 recommended oil SAE-15W-40. When starting the engine, move the blade control lever (Fig 1) on the handle to the top adjustment hole. This disengages the cutting blade Fig 1 B: Before start, press down the throttle and quenching safety protection unit (as shown in Fig. 1); otherwise, the engine won’t start. Fig 2 2.0 When the engine runs, reduce the throttle till the half way, let the engine runs for 1 minute at this speed, so it can warm up.
Page 4 1.0 The engine oil should be changed once a year at minimum. Replace the engine oil for every 100hr use of the engine. 2.0 Your JAYU edger was designed and manufactured to provide years of trouble–free service with a minimum maintenance and adjustment.
Page 5 Mitsubishi CT240 Mitsubishi CT400 Engine model Power, HP/rpm 2.5/3600 4/3600 Displacement, cc Air –cooled 4 stroke Cooling type Fuel–tank capacity (L) Working depth, mm Working width, mm Weight, kg 28.6 31.8 Edger exploded view...
Page 6 Name Name Upper handle Mudguard block Upper handle grip Rubber mudguard Throttle control switch Press roller bent lever spring Throttle line Cutter head support Cut height control handle Front belt pulley...
Page 7 Cut height control line Belt drive washer Clutch dial Cutter head shaft Clutch handle Bearing Clutch lever Cutter head cast Clutch lever screw Cutter head washer Engine Asbestos washer Engine belt pulley Blade Belt drive cover Nut M12 Belt Blade cover Lower support Belt pulley cover Bottom support...

This manual is also suitable for:

Qc-400
