- Page 1 VIDEOSCOPIO ELETTRONICO MOD. 961 P6 ELECTRONIC VIDEO BORESCOPE MOD. 961 P6 VIDÉOSCOPE ÉLECTRONIQUE MOD. 961 P6 VIDEOSCOPIO ELECTRÓNICO MOD. 961 P6 ELEKTRONISCHES VIDEOSCOP MOD. 961 P6 ELEKTRONISCHE VIDEOSCOOP MOD. 961 P6 WIDEOSKOP ELEKTRONICZNY MOD. 961 P6...
-
Page 2: Table Of Contents
ELECTRONIC VIDEO BORESCOPE MOD. 961 P6 Thank you for having chosen a Beta product. Please read this user manual carefully in order to make the best use of our product. CONTENTS: 1 - Safety tips ..........................22 2 - Function description ......................23 3 - Technical specifications ...................... -
Page 3: Safety Tips
1. SafETY TIPS Before using the instrument, read all parts of this user manual carefully. 1.1 Instrument use • Exploration of the concealed machinery parts, car motors etc. • Research submerged or tubed objects. • Used for special applications, such as rear video camera for cars or other vehicles. •... -
Page 4: Function Description
. fUNCTIONS DESCRIPTION • Video films or individual photographs can be taken • The images can be rotated in photography mode. • Photos display featuring data and time. • Video and audio recording • Time and date display on images taken. •... -
Page 5: Technical Specifications
. TECHNICaL SPECIfICaTIONS Filming device ¼ inch CMOS sensor Sensor Pixel 640 x 480 Maximum Resolution 320 x 240 Maximum Number of Frames FPS 30FPS/S Colours (bit) Focus Method Manual Camera gooseneck length 1 metre Video Camera diameter 6 mm Video files played MPEG4/3GP/AVI/ASF Photo formats supported... - Page 6 Storage temperature -20°C to 70°C Storage humidity 15% to 85%RH Filming range 5 cm to 65 cm Data output USB Cable and SD Card Power Supply 3.7V, 2000mA/H battery Measurements (L, W, H) 240mm - 100mm - 160mm Accessories User manual, 3.7V lithium battery, USB cable, Adaptor, Video output cable...
-
Page 7: Instrument Description
. INSTRUMENT DESCRIPTION figure 1 Instrument description 3.2” TFT LCD screen Luminosity OK Button increase button Luminosity decrease ON/OFF button button Last song button Next SONG Button qUIT Button Grip and battery compartment... - Page 8 figure connector for instrument connection Video camera with gooseneck gooseneck video camera figure TV output and earphones USB data and charging port controls and connectors Locking connector SD card slot Reset button...
- Page 9 figure photo / video buttons camera shutter Button video film button figure video camera connector video camera connector back socket...
-
Page 10: Functions Description
. OPERaTION DESCRIPTION 1. Video filming mode 1.1 Power ON/OFF To switch the instrument on, hold the ON/OFF button down for three seconds and the following indications will appear on the screen: LED illumination active Date and time Display for viewing the images or photos Memory display... - Page 11 1. Screen brightness adjustment In the filming mode, press the BRIGHT+ button to increase the display brightness, press BRIGHT- to reduce it. The adjustment values range from 0 to 10. 1. Image rotation In video mode, press the Last/Next song button for 180 ° image rotation. 1. Photo In camera mode, Press the “SNAP”...
- Page 12 . System settings 2-1 Settings In Video Mode, press the “OK” button and a dialogue box will appear on the screen. Use the Right/Left buttons to select “YES” then press the “OK” button to access the system settings mode as shown below:...
- Page 13 Current time, battery power and SD card symbol Icons relative to the various functions available Current state of the operational buttons - Up • Enables the user to pass to the next photo during the photo viewing phase. • Enables the user to move upwards in the various on-screen menus. - Down •...
- Page 14 - Language The user interface language can be selected via this function. Using the Song button, select the desired language, then press the “OK” button to confirm and save the setting. Press “EXC” to exit the language setting mode. - Time Setting Using the Song button, position the cursor to the parameter to be changed, press “SNAP”...
- Page 15 -6 automatic Shut Down Setting See the following figure . TV-OUT Output To achieve a video output to an external monitor or another video device, insert the video cable jack into the TV-OUT socket of the instrument and insert the three-pin jack (Red-Black and Yellow) into the entrance of the device that you wish to use (monitor or DVD recorder etc.).
- Page 16 Select TV-OUT from the main system setting menu, then select the NTSC or PAL output according to the television standard used. Press the “OK” button to start the function. The instrument screen will turn black, then the “Operation” button to view the images on the external monitor. To return to the normal display on the instrument screen, access the main settings menu again, then select LCD Output to view the image on the instrument LCD screen once again.
- Page 17 -9 Picture and Video Explorer From the Video and Picture directory, press the “BRIGHT+” button to delete the current video and Explorer photo. Video player Picture view...
- Page 18 -10 Video settings Press the “SNAP” and “RECORD” buttons to increase or decrease the value of the video settings. -11 Power saving function settings From the Power Save mode, set the time desired for automatic turn-off of the instrument in the event of prolonged lack of use. To reactivate the display, press the button lightly and the menu will appear on the display once again.
-
Page 19: Notes
Remove the batteries if the instrument is not used for an extended amount of time. • Always clean the camera after use. • Use 3.7V Li batteries only. EC declaration of conformity Product 961 P6 complies with the electromagnetic compatibility directive 2004/108/EC issued by the European Community Commission.
