W-PA SIP Public Announcer - Admin Manual
Feb 13, 2020 06:37
W-PA SIP Public Announcer Manual - English
This guide explains how to install and use W-PA SIP Paging Gateway and provides a description of its
basic functions.
Available from WMS Version 3.88
Updated: April 2019
Permalink:
https://confluence.wildix.com/x/BQAVAQ
W-PA SIP Public Announcer Introduction
W-PA SIP Public Announcer Introduction
W-PA SIP Public Announcer is used to broadcast emergency messages and communication in large
environments
such as shopping malls, supermarkets, airports, hospitals
and it still allows you to connect external loudspeakers and microphones. It can also act as a relay for activating
door release switches or door locks via 1 embedded short-in detect port and 1 short-out control port. See
Datasheet
for detailed technical characteristics.
Before using W-PA
Please read the following safety notices before installing or using this W-PA. They are crucial for the safe and
reliable operation of the device:
W-PA SIP Public Announcer - Admin Manual
.
The device has 10 Watt audio output
W-PA
Page 1 of 7
Advertisement
Table of Contents
Summary of Contents for Wildix W-PA SIP Public Announcer
- Page 1 Connection of switch components Switch components configuration Placing calls W-PA SIP Public Announcer Introduction W-PA SIP Public Announcer is used to broadcast emergency messages and communication in large environments such as shopping malls, supermarkets, airports, hospitals The device has 10 Watt audio output and it still allows you to connect external loudspeakers and microphones.
- Page 2 W-PA SIP Public Announcer - Admin Manual Before using the device, make sure that the environment temperature and humidity requirements are within these ranges: Operating temperature: -30 ~ 70 Storage temperature: -40 ~ 70 Relative humidity: 10% - 95% Do not put any foreign objects into the ports of the device. It may cause electric shock or injury accident. If any foreign object gets inside the device, please stop using it Do not let non-technical staff to remove or repair the device.
- Page 3 W-PA SIP Public Announcer - Admin Manual 7 - Speaker output interface: connect external speakers or microphones 8 - Ground screw: connect external parts with metal housing to this interface to prevent static electricity and other interference caused the equipment to work abnormally Rear panel 1 - Speaker interface: according to the device input voltage adaptive output maximum power;...
- Page 4 Assign to user To assign a user to your W-PA SIP Public Announcer: Go to WMS -> Devices Choose your W-PA from the list of available devices and click Assign to user Enter the extension number of a user you want to assign the device to Note: you can assign W-PA to an existing user or create a new one in WMS ->...
-
Page 5: Factory Reset
Appendix 1: W-PA Intercom function Additionally, W-PA SIP Public Announcer can be used as the intercom system for unlocking doors. For this purpose, you need to connect and configure external switch components. You can connect such switch components as door release switches, door locks, intercom panels etc.:... - Page 6 W-PA SIP Public Announcer - Admin Manual The intercom function itself is implemented by placing calls from/ to the connected switch components. Note: W-PA and Viking W-100 Handsfree Doorbox To use W-PA with Viking W-1000, disconnect the circuit board and use 8 Ohm speaker, microphone and switch.
- Page 7 Unlocking doors with an incoming call To unlock the door with an incoming call to W-PA: Call the extension number you've assigned the device to from any Wildix IP phone/ Collaboration/ Mobile Use DTMF code 11 to open the door...
