Summary of Contents for Legion Furniture WT7460-WB
- Page 1 SINK BASE WT7460-WB VANITY CABINET + VANITY TOP + MIRROR VANITY SET: WT7460-WB INSTALL ATION INSTRUCTIONS www.legionfurniture.com Version 1.0...
-
Page 2: Installation Accessories
VANITY CABINET + VANITY TOP + MIRROR VANITY SET: WT7460-WB PRODUCT PACKAGE COMPONETS/ TOOLS REQUIRED VANITY COMBINATION P-TRAP AND POP AND POP-UP MAIN COMPONENTS INSTALLATION DIAGRAM Sink Pop-up Silicon Washer Silicon Washer Wall Mount Mirror Brass Nut Rubber Washer Mounting... -
Page 3: Dimensions And Specifications
VANITY CABINET + VANITY TOP + MIRROR WT7460-WB VANITY SET: DIMENSIONS & SPECIFICATIONS 58" Mirror 2 2/5" 60" 22" 13 3/5" 27 3/10" 21 1/2" 1 9/10" Front View Side View ATTENTION! Due to manufacturing process any dimensions may have a tolerance up to 3/8". All sizes are for reference only. -
Page 4: Installation Steps
VANITY CABINET + VANITY TOP + MIRROR WT7460-WB VANITY SET: INSTALLATION STEPS INSTALL DOOR & DRAWER HANDLES All WT7460-WB vanity cabinets by LegionFurniture come pre-assembled. All door and drawer handles are installed from the inner side of the drawer to avoid damage during transportation. Open the drawers to install the handles. -
Page 5: Mirror Installation
VANITY CABINET + VANITY TOP + MIRROR WT7460-WB VANITY SET: INSTALLATION STEPS MIRROR INSTALLATION Using a tape measure find a length of the vanity IMPORTANT! Using a stud finder locate wooden top and divide it by 2. The result of the division studs. - Page 6 VANITY CABINET + VANITY TOP + MIRROR WT7460-WB VANITY SET: Retain these installation instructions for future reference! Legionfurniture reserves the right to modify this installation instructions at any time. It is a customer's sole resposibility to inquiry for the updates of the installation instructions.
