- Page 1 M A M I MANUFACTURING AND MINOR INVENTIONS Mini TRACER M000037...
-
Page 2: Table Of Contents
TABLE OF CONTENTS MINI-TRACER G E N E R A L INFORMATION ..........................- 2 - EXTRA FUNCTIONS AND FEATURES........................- 3,4 - CONNECTIONS ................................- 5 - WIRELESS DETECTOR AND REMOTE CONTROL OPERATION................- 6 - - PROGRAMMING ..........................- 7 - INSTALLER SYSTEM PROGRAMMING: -SYSTEM OPTION REGISTERS ......................... -
Page 3: Mini-Tracer
M I N I - T R A C E R Radio Alarm Control Panel MARCH 2007 GENERAL FEATURES: he "MINI-TRACER" is a microprocessor based ALARM PANEL designed to perform all the functions associated with the monitoring of alarm conditions, in both wired and wireless environment, and subsequent transmission by Radio to a REMOTE MONITORING CONTROL ROOM. -
Page 4: General Information
GENERAL INFORMATION The "MINI-TRACER" is capable of monitoring BOTH WIRED and WIRE-LESS detector circuits at the same time. A REMOTE PANIC BUTTON option is built in as a standard feature. The "MINI-TRACER" will send an alarm/report whenever the following inputs are triggered: - Any of the 6 wired active inputs. -
Page 5: Extra Functions And Features
The Key Pad is used to do the following: - program the system's options. - access the 4 preset patterns and if necessary change them. - access each zone individually. - change the user codes ( 10 different user codes per key pad ). - activate a panic alarm . - Page 6 4- AUTO - ARMING When auto -arming is selected (programable for 2 hours or 15 minutes by installer) the system will arm itself if no movement or any other activations have been detected within the selected time period. A second (Installer programmable) option is to enable the entry / exit zone (zone 1 - Wired only). When the last activation was detected on zone 1 the system will arm itself at Level ‘D’...
-
Page 7: Connections
CONNECTIONS Installing the "MINI-TRACER" is very simple. The connections are easy to read and understand. Connect the battery, the external transformer and wire up the different zone circuits and audible devices such as the buzzer and siren. These connections are as follows : SIREN BUZZER ZONE CIRCUITS 1 to 6 1 - ALARM CIRCUIT CONNECTIONS:... - Page 8 WIRELESS DETECTORS and REMOTE CONTROL operation Using wireless sensors is simple provided you are aware of the following facts: 1 - The operating range may vary widely from one installation and location to another. The position of the radio receiver is therefore critical and must be chosen accordingly.
- Page 9 INSTALLER PROGRAMMING THE MINI-TRACER - 1 - ENCODING THE WIRELESS DETECTORS AND REMOTE CONTROLS THE TRACER IS ORIGINALLY PROGRAMMED WITH A "FACTORY DEFAULT" SET OF OPTIONS. ALTHOUGH THE "FACTORY" OPTIONS REFLECT THE CHOICE OF THE MAJORITY OF - 2 - SYSTEM OPTION REGISTERS. INSTALLERS AND END-USERS, PROPER OPERATION AND COMPLIANCE WITH SPECIFIC - 3 - SYSTEM I.D.
-
Page 10: Programming
PROGRAMMING = ON OPTIONS REGISTER NO. 1 NOTE: = OFF OFF = SILENT PANIC BUTTON ON = SIREN WITH PANIC BUTTON ON = MULTI-USER OPERATION OFF = NORMAL OPERATION ON = AUXIL. SIGNALS ON BUZZER & SIREN OFF = AUXIL. SIGNALS ON BUZZER ONLY SPARE SPARE ON = WIRELESS RF BLOCKING ENABLED... - Page 11 INSTALLER ( 2 ): PROGRAMMING (CONTINUED) SETTING / DISPLAYING DETECTOR/ REMOTE CONTROL CODES TO PROGRAM THE DIP-SWITCH CODES OF THE DETECTORS AND REMOTE CONTROLS, ENTER THE INSTALLER CODE FOLLOWED BY THE "#" KEY. SELECT THE CODE YOU WANT TO CHECK /CHANGE WITH"1 ,A" or " 1, B "...
-
Page 12: Open/Close
PROGRAMMING (CONTINUED) CIRCUIT (ZONE) OPTION REGISTERS Each of the 6 zones can be programmed to behave in different ways and perform different tasks. To do this there are several registers: 1 2 3 4 5 6 7 8 TO PROGRAM EACH REGISTER: 1- ENTER THE INSTALLER CODE FOLLOWED BY THE CORRESPONDING REGISTER NUMBER: 2- USING KEYS "1 to 6”... -
Page 13: Sensitivity
PROGRAMMING (CONT.) S.P.I. (SECTIONAL PERIMETER INTRUSION ) OPTION REGISTERS An extra 6 perimeter beams may be connected to the new MINI-TRACER-Combo.( See SPI installation instructions) The unit will monitor these perimeter beams and indicate which beam was triggered. The activation of the beams will either sound locally or will report the activation to the control room using exclusively zone 6. -
Page 14: Mains
PROGRAMMING (CONT.) KEYPAD OPTION REGISTERS ENTER THE INSTALLER CODE FOLLOWED BY A LONG "#" KEY AND THE NUMBER OF THE REGISTER YOU WANT TO MODIFY. NOTE : THE " # " MUST BE HELD DOWN UNTIL YOU HEAR A LONG BEEP. THE CURRENT CONTENT OF THE SELECTED REGISTER WILL BE DISPLAYED.USE BUTTONS 0 TO 8 TO = OFF... -
Page 15: Battery
MINI-TRACER CONNECTIONS(1) Uhf antennae SIREN RELAY 12V 7 A/H BATTERY BATTERY FUSE Arm/Disarm TRANSFORMER indication 15-17V AC EXTERNAL NOTE 3: REFER TO SPI INSTRUCTIONS FOR CONNECTION DIAGRAM AND OPTIONS C D + - A B + TRACER “C” and “D” not Used TRANSMITTER WARN... -
Page 16: Buzzer
MINI TRACER CONNECTIONS (2) CONNECTIONS FOR: - DETECTION CIRCUITS (WIRED) - DETECTION CIRCUITS (WIRE-LESS) - EXTERNAL SIREN - EXTERNAL BUZZER TYPICAL ZONE CIRCUIT (ZONE 2) 2K7 ohm RESISTOR IN SERIES NORMALLY CLOSED CONTACTS 12V SUPPLY TO THE DETECTOR TYPICAL ZONE CIRCUIT (ZONE 1) -
Page 17: Summary Of All Key Pad Entries
Summary of ALL Key-Pad entries PROGRAMMING THE SPECIFIC KEYPAD OPTIONS ( ONLY AVAILABLE THROUGH THE INSTALLER PASSWORD 1000 #--># 1 = ENABLE LOCAL KEYPAD 1000 #--># 9 = CLEAR EEPROM ON LOCAL KP 1000 #--># 3 = SET LOCAL BEEPER FUNCTIONS ON KP 1000 #--># D = SET KEYPAD NUMBER 1000 #--># 4 = CHANGE KEYPAD SYSTEM ID... -
Page 18: Notes
Notes: M000037... - Page 19 M A M I MANUFACTURING AND MINOR INVENTIONS M000037...
