- Page 1 DIGITAL MULTI MEDIA PLAYER ER-1 ER-3 ER-4 Warning:Before attempting to connect,operate or adjust this Amplifier, please read these instructions completely and carefully and save this Manual...
- Page 3 1.CAUTION Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. 2.Batteries (battery pack or batteries installed) shall not be exposed to excessive heat such as sunshine, fire or the like. 3.WARNING Do not ingest the battery, Chemical Burn Hazard(The remote control supplied with) This product contains a coin/button cell battery.
-
Page 4: Table Of Contents
Table of Contents Table of Contents Introductions ----------------------------------------- 2 Front panel --------------------------------------------3 Rear panel -------------------------------------------- 6 Accessories --------------------------------------------8 Remote Control ---------------------------------------9 Bluetooth -------------------------------------------- 10 Network Setting for Internet Radion ------------11 Internet Radio Menu ------------------------------- 14 Connecting Station -------------------------------15 Specifications --------------------------------------16... -
Page 5: Introductions
Introductions Introductions FM TUNER/CD/USB/SD/BT/DAB+/INTERNET RADIO The ER-1 is an All-In-One audio source device with intergrated FM RDS tuner,Internet Radio, UPNP and USB,SD media player,compatible with MP3,WMA,FLAC and WAV audio files. It combines a FM tuner, CD-player, Media-player and Internet Radio into one single rack space 19’’... -
Page 6: Front Panel
Front Panel Front Panel 1.SD connection port: An USB storage device can be inserted to this slot.Tracks stored on here can be played through the ER-1 and it will start to play when the media is inserted and selected SD function by BACK button. 2.USB connection port: An USB storage device can be inserted to this slot.Tracks stored on here can be played through the ER-1 and it will start to play when the media is inserted and selected USB function by BACK button. - Page 7 Front Panel • Bluetooth mode: Press:The music from the Bluetooth feature is activated on your Bluetooth device and paused with this button. It will resume to play after pressing this button again. • Standby mode Press the button,the device can be turn on. 8.Tuning down / CD-Mp3 Track selection down ( •...
- Page 8 Front Panel • Bluetooth mode In Bluetooth mode, pressing this button long term,you can see MCU version for Bluetooth. 12.Mute (MUTE) Pressing this button, all variable output and fixed output can be muted/unmuted. When the outputs are muted, the message ‘MUTE’ will display on the LCD. In CD(USB) mode,by pressing this button long term,you can see MCU version for CD(USB).
-
Page 9: Rear Panel
Rear Panel Rear Panel 1.Power inlet The main power supply (100~240VAC,50/60 Hz) has to be applied to this AC power inlet. The connection is made by an IEC C14 power connector which is fitted with a fuse.When replacing the fuse, make sure that the value of the replacement fuse matches the value of the original fuse. - Page 10 Rear Panel 8.Bluttooth/AUX output The output terminal has output connection for two analog signals, bluetooth and AUX. Their output levels are fixed and not controlled. Two types of analog signal output can be from RCA(unbalance) and Euroblock (balance) at the same. 9.Media output The output terminal has output connection for two analog signals, CD,USB and SD.
-
Page 11: Accessories
WiFi Antenna x 2 (M5 MODEL) WiFi Antenna x 1 (M4/M3 MODEL) Remote Control x 1 Power Cord x 1 Euroblock Connector ER-1 MODEL : 2PIN,5.08 x 1 6PIN,3.5 x 6 ER-3/ER-4 MODEL : 2PIN,5.08 x 1 6PIN,3.5 x 5... -
Page 12: Remote Control
Remote Control Remote Control (Power):When the device is in standby mode, you can press this key to turn on the power. Once again, the device switches to the standby mode. (Mute):Mutes the sound. USB REC: USB direct recording. (Skip/Search) : *Skips Fast backward or Forward. -
Page 13: Bluetooth
Bluetooth device, a list of the found devices may appear in the Bluetooth device display depending on the type of Bluetooth device. Your unit appears as “ER-1”(ER-3,ER-4). 3.When this unit is successfully connected with your Bluetooth device, “BT PAIRED” will be appear on the display window. -
Page 14: Network Setting For Internet Radion
Network Setting for Internet Radio Network Setting for Internet Radio Before you are able to use your internet radio,you will need the following items: • A broadband internet connection. • A wired/wireless access point,or router connected to your broadband internet connection. If your wireless network is configured to use Wired Equivalent Privacy(WEP)or Wi-Fi Protected Access(WPA)data encryption,you will need to know the WEP or WPA code so that you can setup your internet radio to communicate with your wireless network.Consult your network... - Page 15 Network Setting for Internet Radio When the Internet Radio search out Wireless Network, names of Networks will be showed on the LCD screen. Wireless Network List Menu Wizard *If your wireless network is not found, check that your wireless access point or router is switched on and connected to your broadband internet connection.
- Page 16 Network Setting for Internet Radio Connecting to a wired network Use the following procedure to connect the WI-FI radio to a wired router. 1.Connect an ethernet cable (not supplied) between the ethernet port on the rear of the WI-FI radio and a wired router. 2.Power On the Wi-Fi router.
-
Page 17: Internet Radio Menu
Internet Radio Menu Internet Radio Menu... -
Page 18: Connecting Station
Connecting Station Connecting Station Notice: If an error occurred, please press the BACK button to return to last stage of the function table. Choose the Internet Radio you want to listen. 1.Turn the “PUSH TO SELECT”control until the following screen is displayed. Press down “PUSH TO SELECT”... -
Page 19: Specifications
Specifications Specifications FM Tuner Tuning range 87.5 - 108 MHz Sensitivity (26dB S/N)@ 75Ω unbalanced 2.0 μV Channel selectivity (67.5KHz) 40 dB 50 kHz (Option,100kHz) Tuning step size 60 dB Audio S/N ratio FM Audio bandwith 30 - 15 kHz Fixed Output: 0dB Analog out(MODE:75KHz,1kHz) Vriable Output(EQ,Bypass,vr,max): 0dB... - Page 20 Dimensions (L x W x H) 482 x 320 x 44 mm Color Black Weight 3.82kg Remarks: *ER-4 model has no Internet radio/DAB+ function. *ER-3 model has no Internet radio/DAB+ and CD function. Necessary modifications are carried out without notice.
