- Page 1 FlowPath Control ™ Owner's Manual ALL PURPOSE-BATTERY VENTILATOR San Diego Luxembourg Dubai Ningbo | Singapore...
-
Page 2: Table Of Contents
CONTENTS Introduction ............................ 3 About Euramco ........................ 3 Warning Labels and Safety Instructions ................ 4 Safety Checklist ........................ 5 Unit Description ..........................5 Parts List ..........................5 Technical Specifications ....................6 Dimensions ........................6 Main Interface ........................7 Plug Type .......................... 8 Adjusting Angle ........................ -
Page 3: Introduction
Introduction Congratulations on your purchase of the high-end ventilator RAMFAN EX150Li. WARNING! Read this manual before starting for the first time! You now own an industrial ventilation unit that offers endless possibilities. Before using, make sure that no damage was done to your ventilator during transport. If this is the case, do not use the product and immediately contact your authorized Euramco dealer. -
Page 4: Warning Labels And Safety Instructions
Warning Labels and Safety Instructions This is the safety-alert symbol. When you see this symbol on your ventilator or in this manual, be alert to the potential for personal injury or damage to your equipment. Be sure you understand all safety messages and always follow recommended precautions and safe operating practices. -
Page 5: Safety Checklist
Safety Checklist √ Always purchase from a Euramco's authorized dealer to ensure you are getting real RAMFAN products, a full product warranty, and the best customer service. √ Flexible electrical cables connected to the equipment may not be used when damaged √... -
Page 6: Technical Specifications
Technical Specifications Model EX150Li 18” (46 cm) Motor 1.9hp (1.4kw) EX150Li with wheel kit assembled (1), 52V 8Ah battery (2) and Order #EL6500 power cord (1) DC: 45 min Runtime @ Full speed DC Max: 30 min AC: Unlimited AC Input Multiple plug options available Battery System 52V Lithium-Ion, 832Wh, 16Ah... -
Page 7: Main Interface
Main Interface Control Panel: PUSH FOR PUSH FOR BAT. FAULT WAKE | STOP NO PWR AC PWR DC PWR DC MAX Intellisense FAULT STORAGE MODE LIGHTS SPEED Number Symbol Indicate Function Wake Button / Emergency Stop Button Press and hold WAKE button to start. Maximum Speed (DC) Button Press MAX button for 2 seconds. -
Page 8: Plug Type
Plug Types The EX150Li is suitable for worldwide applications. A voltage converter is not needed. The unit includes a simple removable cord that allows the unit to operate up to 250 VAC: Mainly used in Type Order # USA, Canada, Mexico and EL-CUS-4762 Japan Germany and France (and... -
Page 9: Adjusting Angle
Pull the plug out itself, never by the cord or by wiggling it out of the outlet. Adjusting Angle To adjust the ventilator angle to suit the desired position, unscrew the tilt adjustment knob and adjust it at the desired angle upwards and then lock it in position by tightening the knob. -
Page 10: Operational Modes
Operational Modes AC Operation • Input Voltage. 90-250VAC, 50/60Hz • The ventilator is capable of operating seamlessly in countries that supply electricity at either 120V AC/60 Hz or 240V AC/50 Hz without manual adjustments by the user. • Operation out of these limits can damage electrical components and will void the warranty. - Page 11 EX150 ALIGN BATTE Example of label placed on batter base EX50L LB9113 ALIGN BATTERY EX150Li ALIGN BATTERY EX50Li LB9113 • Gently pull up the yellow handle to remove the battery from the holder.
-
Page 12: Battery Operation Procedures
Battery Operation Procedures Please full charge battery before first use Using One Battery • The EX150Li allows the option of using one or two battery packs. • When using one battery, simply plug the battery into either one of the two battery connectors (left or right). -
Page 13: Run Time
Battery Operation Procedures • When AC is disconnected and Speed Control is off (speed = 0), the controller and battery(s) will enter a sleep mode to conserve the battery power after 60 minutes of no activity. • To wake the ventilator, push and hold WAKE | STOP Button on Control Panel. -
Page 14: Charging Procedure
Charging Procedure Make sure the battery pack is connect correctly into the ventilator, as described above in “Connection of Battery Pack”. • The next step is to leave the ventilator off. During charging, the battery indicator lights will flash. The battery charge level can be recognized by the number of lights that are constantly lit. -
Page 15: The Fuel Gauge
The Fuel Gauge The Battery Fuel Gauge provides battery status information using five red LEDs. Press the Fuel Gauge button to display the lights. The fuel gauge lights will remain lit for approximately five seconds. The numbers represent each LED and the grid is how they're laid out: Fuel Gauge Lights Diagnosis Solution... -
Page 16: Status Indicator Lights
Battery Status Indicator Lights On the control panel there are 2 sets of lights: on the top side of the battery lights indicate the charge level in the battery attached to the left side of the ventilator, on the bottom side of the battery lights indicate the charge level in the battery attached to the right side of the ventilator. -
Page 17: Storage/Transport Modes
Storage/Transport Modes • Make sure the power cord is disconnected before activate the Storage/Transport Mode and 1 or 2 battery pack(s) are connected to the ventilator (at battery mode). • To activate Storage/Transport Mode, press and hold the WAKE|STOP and the MAX buttons at the same time for 8 seconds or until the top Status LED Light switches to yellow flash mode (STORAGE MODE). -
Page 18: Cord Storage
Cord Storage After use, store the power cord on the holder on the side of the fan, where there is a label representation of how to store it: CORD STORAGE How to Store Batteries Temperature range for battery storage: • Store less than 1 month: -20°C to +60°C (-4°F to +140°F) •... -
Page 19: Maintenance And Disposal
Maintenance and Disposal • DO NOT disassemble the ventilator for maintenance reasons. • Do not loosen screws on control box without contacting Euramco customer service. They are torqued to a setting to achieve water tightness. Clean ventilator periodically to remove accumulated dust or particles from ventilator guards. •... -
Page 20: Certification
FlowPath Control ™ AMCA Euramco Safety Inc. certifies that the Portable PPV Blower shown below is licensed to bear the AMCA Seal. The ratings Euramco Safety Inc. Euramco Safety Inc. shown are based on tests and procedures in accordance with certifies that the... -
Page 21: Declaration Of Conformity
UL 508 – Industrial Control Equipment UN 3481 – Lithium-Ion Batteries when Packed with Equipment Euramco Safety, Inc. hereby declares that the equipment described above conforms to the relevant Essential Health and Safety Requirements of the European Machinery Directive 2006/42/EC and The additional Directives and Standards listed above. - Page 24 SM-EX150LI REV C 121719 MADE IN THE USA Use with all LUXEMBOURG US Firefighting MIDDLE EAST – UAE CHINA literature 2746 Via Orange Way 1 Rue Edmond Reuter, Jebel Ali FTZ, Dubai A11, No. 1 Jinxi Road Spring Valley, CA 91978 USA 5326 Contern, Luxembourg Phone: +1 (619) 670-9590 x114 Qingshuipu, Zhenhai, Zhejiang...
