Summary of Contents for DPtech DPX19000 Series
- Page 1 DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual...
- Page 2 DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual Hangzhou DPtech Technologies Co., Ltd. provides full- range technical support. If you need any help, please contact Hangzhou DPtech Technologies Co., Ltd. and its sale agent, according to where you purchase their products.
- Page 3 Hangzhou DPtech Technology Co., Ltd has the right to modify the content in this manual, as it is a user guides, Hangzhou DPtech Technology Co., Ltd made every effort in the preparation of this document to ensure accuracy of the contents, but all statements, information, and recommendations in this document do not constitute the warranty of any kind express or implied.
-
Page 4: Table Of Contents
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual Table of Contents CHAPTER 1 PRODUCT INTRODUCTION ................1 1.1 P ......................... 1 RODUCT OVERVIEW 1.2 DPX19000 ..................1 PRODUCTS APPEARANCE 1.3 P ......................7 RODUCT SPECIFICATION 1.3.1 D ......................7 IMENSION AND WEIGHT 1.3.2 E... - Page 5 DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual 3.2.10 S ......................5 PACE REQUIREMENTS 3.3 R ........................5 EQUIRED TOOLS 3.3.1 A .................. 5 CCESSORIES SUPPLIED BY THE SWITCH 3.3.2 U .................. 5 SUPPLIED TOOLS AND EQUIPMENT CHAPTER 4 DEVICE INSTALLATION ..................1 4.1 B...
- Page 6 DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual 6.2M ....................1 AIN CONTROL BOARD FAILURE 6.3 S ......................2 ERVICE BOARD FAILURE 6.4 S ................... 2 WITCHING NETWORK BOARD FAILURE 6.5 F ..........................3 AN FAILURE 6.6 C .................. 3...
- Page 7 DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual List of Figures Figure1-1 DPtech DPX19000-A6 front view.................... 1 Figure1-2 DPtech DPX19000-A6 rear view ..................... 2 Figure1-3 DPtech DPX19000-A10 front view..................3 Figure1-4 DPtech DPX19000-A10 rear view ................... 4 Figure1-5 DPtech DPX19000-A1 front view.................... 5 Figure1-6 DPtech DPX19000-A18 rear view ...................
- Page 8 DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual List of Tables Table1-1DPX19000 chassis ........................1 Table 1-2 Dimension and weight ......................7 Table1-3 Voltage and current specification ....................7 Table1-4 Line card fan tray specification ....................8 Table1-5Switching network board fan tray specification ................. 9 Table1-6 Working environment table .......................
-
Page 9: Chapter 1 Product Introduction
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual Chapter 1 Product introduction 1.1 Product overview DPtech DPX19000 series routers include the models in Table 1-1. Table1-1DPX19000 chassis Chassis Main control board slot Service board slot Switching network board DPX19000-A6... -
Page 10: Figure1-2 Dptech Dpx19000-A6 Rear View
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual (3) Slot mask (4)Service board slot（L1） (6) Service board slot （L3） (5) Service board slot（L2） (7) Service board slot （L4） (8) Power module slot Figure1-2 DPtech DPX19000-A6 rear view (1)Line card fan tray (2) Switching network board（F6）... -
Page 11: Figure1-3 Dptech Dpx19000-A10 Front View
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual 2. DPX19000-A10 chassis view and description (10) (11) (12) (13) Figure1-3 DPtech DPX19000-A10 front view (1) Frame (2)Service board slot（L1） (3) Service board slot（L2） (4) Service board slot（L3） (5) Service board slot（L4）... -
Page 12: Figure1-4 Dptech Dpx19000-A10 Rear View
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual (10) (11) (12) Figure1-4 DPtech DPX19000-A10 rear view (1) Line card fan tray (2) Switching network board（F8） (3) Switching network board（F7） (4) Switching network board（F6） (5) Switching network board（F5） (6) Switching network board（F4）... -
Page 13: Figure1-5 Dptech Dpx19000-A1 Front View
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual （1） （22） （21） （20） （2） （19） （18） （17） （16） （15） （14） （3） （13） （12） （11） （10） （4） （9） （8） （7） （6） （5） Figure1-5 DPtech DPX19000-A1 front view (1) Frame (2) Network board fan tray0... -
Page 14: Figure1-6 Dptech Dpx19000-A18 Rear View
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual (21) Service board slot(L2) (22) Service board slot (L1) (10) (11) (12) Figure1-6 DPtech DPX19000-A18 rear view (1) Line card fan tray (2) Switching network board (F8) (3) Switching network board (F7) -
Page 15: Product Specification
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual 1.3 Product specification 1.3.1 Dimension and weight Table 1-2 Dimension and weight Model Weight Dimension（W×D×H） DPX19000-A6 100Kg 440mm×848mm×353mm DPX19000-A10 200Kg 436mm×900mm×842mm DPX19000-A18 300Kg 440mm×860mm×1200mm 1.3.2 Electric voltage and current Table1-3 Voltage and current specification... -
Page 16: Backplane
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual Note: The device power module are hot swappable. You can pull out one power module while the system service is working normally. Before you pull it in and out, you should make sure the power switch is off. -
Page 17: Working Environment
Working attitude -60m～4km 1.4 Product component 1.4.1 Main control board（N-MPUA） 1. Introduction The main control board (N-MPUA) takes leading effect in DPX19000 series products, which realizes initialization configuration, management and control packet processing of the system. (11) (15) （5） （2） （3）... -
Page 18: Figure1-7 Main Control Board (N-Mpua) Front View
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual Figure1-7 Main control board (N-MPUA) front view (1) Ethernet management port(MGMT) (2) CONSOLE port(CON) (3) USB port (0) (4) USB port (1) (5) MPU status LED(MPU1) (6) MPU status LED(MPU2) (7) LPU status LED(LPU1) -
Page 19: Figure1-8 N-Mpua (N-Mpua) Status Led
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual Note: Flashcard is used to store the “Conboot” boot file. Memory card is used to store system running data and also it can be data-cache when you forward ... - Page 20 DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual Status Description power up. Green Means fan is working normally. (20)Fan status LED（FAN0） Means the fan has serious problem, which must be handled immediately. (23) Ethernet management Steady on Means the management port is connected.
-
Page 21: Figure1-9 Rj45 Connector
(2)RJ45 connector 10 /100/1000M Ethernet electrical interface and management interface of DPX19000 series use RJ45 connector, support MDI/MDIX auto-sensing, and adopt category-5 cable. Figure1-9 RJ45 connector (3)Connection cable Ethernet electrical port uses category-5 twisted pair to connect network, as shown in Figure1-10. -
Page 22: Interface Board (N-32Xges)
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual different. It connects a terminal device (PC or router) to another terminal device (PC or router). You make crossover cables by yourself. （4）Ethernet electrical port attributes Attributes of Ethernet electrical port:... -
Page 23: Figure1-11 Interface Board (N-32Xges) Front View
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual （1） （2） （6） （4） （3） （5） Figure1-11 Interface board (N-32XGES) front view (1) 10GE SFP+ optical interface（0） (2) 10GE SFP+ optical interface（16） (3) 10GE SFP+ optical interface LED（1） (4) 10GE SFP+ optical interface LED（0）... -
Page 24: Interface Board (N-48Gep)
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual 4.10GE Ethernet optical interface For the 10GE Ethernet optical interface attributes, please refer to Table1-8. For the connector and optical fiber, please refer to Chapter 1.4.6 optical module. 1.4.3 Interface board (N-48GEP) 1. -
Page 25: Interface Board (N-48Get)
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual Status Description interface LED(1)Green Blink Means GE optical interface 1 is sending and receiving data. Steady off Means GE optical interface 1is disconnected. (4)1000M Ethernet optical Steady on Means GE optical interface 0 is connected. -
Page 26: Interface Board (N-8Qxp)
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual Item Specification Electrical 48 *10/100/1000BASE-T Ethernet electrical interface interface(RJ45) 3. LED indicator (1) (3) Figure1-16 Interface board (N-48GET) running status LED Status Description (1)10/100/1000M Ethernet Steady on Means GE electrical interface 0 is connected. -
Page 27: Figure1-17 Interface Board (N-8Qxp) Front View
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual (2) (3) Figure1-17 Interface board (N-8QXP) front view (1) 40G Ethernet optical interface(0) (2) 40G Ethernet optical interface LED(2) (3) 40G Ethernet optical interface LED(3) (4) 40G Ethernet optical interface(1) 2. Speciation... -
Page 28: Optical Module Introduction
Optical module transmits signals over optical fibers. Optical transmission features low loss and is fit for long distance transmission. DPtech devices support several kinds of optical module. You can select a kind of optical module as needed for data transmission over optical fibers. -
Page 29: Figure1-19 Sfp Module Appearance Diagram
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual Central wavelength represents the wave band used for optical signal transmission. At present, there are mainly three central wavelengths for common optical modules: 850nm, 1310nm, and 1550nm, respectively representing three wavebands. -
Page 30: Figure1-20 Sfp+ Optical Module Diagram
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual Attributes Description wavelength 62.5/125 μ 9/125 μ m 9/125 μ m 9/125 μ m 9/125 μ m Fiber types single-mode single-mode single-mode single-mode multimode fiber fiber fiber fiber fibers Max transmission 0.55km... -
Page 31: Figure1-21 Xfp Optical Module Diagram
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual Attributes Description Central wavelength 850nm 1310nm 1550nm μ 9/125 μ m single-mode Optical fiber 62.5/125μm multi-mode 9/125 fiber single-mode fiber fiber transmission 300m 10km 40km distance Operating mode 1000Mbps, full-duplex mode 4. -
Page 32: Figure1-22 Qsfp+ Optical Module Appearance
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual Attribute Description Receiver sensitivity -7.5dBm -10.3dBm -11.3dBm -24dBm -7dBm Central wavelength 850nm 1310nm 1550nm 1550 nm DWDM 62.5/125 μ 9/125 μ m 9/125 μ m 9/125 μ m single Optical fiber 9/125μm single... -
Page 33: Table1-11 Sfp 2.5Ge Pos Optical Interface Attributes
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual 6. POS optical interface attributes Table1-11 SFP 2.5GE POS optical interface attributes Attribute Description Connector type SFP/LC Interface rate 2.67Gbps Type Short-haul single Medium-haul Long-haul Ultra-long mode single mode single mode... -
Page 34: Figure1-23 Lc Connector Appearance
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual Attribute Description μ single single mode mode fiber mode fiber mode fiber fiber multimode fiber transmission 300m 10km 40km 80 km 200 km distance Interface standard SONET OC-192c/SDH STM-64c 7. LC connector Optical fiber connector (also called union joint), which is a necessary passive component in optical fiber connector and also is the removable connector in optical channel. -
Page 35: Power Supply Mode
1.4.7 Power supply mode DPX19000 series products have two kinds of power supplies: AC power supply and DC power supply, which allow user to select according to their real need. DPX19000 series products do not support power supplies intermixing. DPX19000-A6 series has 4 power-module slots, which can realize power module N+M redundancy;... - Page 36 DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual (1) Power input LED (2)Power output LED (3) Over-temperature LED (4) Power failure LED AC power supply specification: Item Specification Rated input voltage AC power supply type:100V AC～120V AC/ 200V AC～240V AC；50/60Hz Max input current AC power supply type:13.3A...
-
Page 37: Figure1-26Ac Power Module (Pwr-Dc2000) Diagram
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual 2. AC power module (PWR-DC2000) （1） （2） （3） （4） Figure1-26AC power module (PWR-DC2000) diagram (1) Power input LED (2)Power output LED (3) Over-temperature LED (4) Power failure LED AC power supply specification:... - Page 38 DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual LED(color) Status Description LED(Green) Means power module isn’t inputted. Blink Means power module input is overload. (3)Over-temperature Steady Over-temperature LED. LED(Yellow) Means power module is working normally. (4)Power failure Steady Means power module is failure.
-
Page 39: Chapter 2Device Slot And Interface Number
2.1 Slot number ordering DPX19000 series service board slots are numbering from top to bottom, the fan slots are numbering from top to bottom 0 and 1, the power module are numbering from top to bottom, from left to right. -
Page 40: Interfaces Illustration
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual X: means slot number. The slot number of service board on the device ranges from 1 to 16(main control board with service interfaces are the same. Y: interface number, which is the interface number on service board. The range number varies from different service boards. -
Page 41: Chapter 3Installation Preparation
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual Chapter 3Installation preparation To avoid possible bodily injury and equipment damage, read all safety recommendations carefully before installation, pay attention to the installation, operation and maintenance precautions. Note that the recommendations do not cover every possible hazardous condition. -
Page 42: Cleanliness
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual materials, greatly lower the device reliability, and hence significantly shorten its service life. 0 describes the details of device temperature/humidity. Table3-1Temperature/ humidity requirement for equipment room Temperature Relative Humidity 5℃～40℃ 20%～80%（non- condensation）... -
Page 43: Anti-Interference Requirements
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual the device can be badly damaged when excessive static electricity is present. To get much better ESD effect, you should: Connect your device to the earth ground properly. Keep the equipment room as clean as possible. -
Page 44: Wiring Cable Requirements
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual 3.2.7 Wiring cable requirements Cables connect the device should be indoors, not wiring outdoors. When you wiring indoors, you should pay attention to the followings: Do not wiring cables in working area, so that it can avoid the cables to be damaged or dropped from ceiling. -
Page 45: Space Requirements
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual 3.2.10 Space requirements (1)For moving the switch and servicing the modules, make sure the width of the aisle in the equipment room is at least 0.8 m. (2)The equipment room is at least 3 m high (3) Reserve at least 0.8 m of clearance between the rack and walls or other devices. -
Page 46: Chapter 4 Device Installation
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual Chapter 4 Device installation 4.1 Before installation You have read Chapter 3 carefully. The requirements in Chapter 3 are satisfied Power off your device before installation. 4.2 Installation Procedure Chapter 4 Device installation... -
Page 47: Figure 4-1 Device Installation Procedure
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual Start Install to a specific site Connecting ground wire Install general module Connecting power cord Connecting interface cable Wiring and binding cable during installation Installation check Turn on power switch Troubleshooting Turn off power switch Normal？... -
Page 48: Installing The Device In A Rack
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual 4.3 Installing the device in a rack Confirm the following preparations before starting installation. 4.3.1 Installing a chassis air filter（Optional） 4. 3.1 Installing an air filter on A6 Slowly push the dust screen along the slide rails to the end, use Phillips screwdriver to fasten the captive screw. -
Page 49: Installing Device To A Work Bench
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual (1) Left mounting ear (2) Cable rack (2) Installing the mounting ear Before installing device in a cabinet, you should install the mounting ear on each side of the device. A10 has the same left and right mounting ears. -
Page 50: Installation Procedures
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual 4.4.2 Installation procedures (1) Hold the two sides of the switch and steadily move the switch to the workbench. (2) Lift the switch a little higher than the workbench and put on the workbench gently. -
Page 51: Installing General Module
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual Fasten the grounding screw, which is attached with the OT terminal of the grounding cable, into the grounding screw hole with a screwdriver. Connect the other end of the cable to the ground. -
Page 52: Installing A Fan Tray
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual 2. Installing an AC power supply Installation procedure of AC and DC power supply module are same. To install an AC power supply, follow these steps: 4.6.2 Installing a fan tray (1) Select a slot to install the fan tray. -
Page 53: Connecting To Service Port
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual Caution： PC serial port does not support hot-swap. You cannot plug wire if PC is still running. To connect PC to device, you should plug DB9 to PC first then plug RJ45 to device. To disconnect them, you plug out RJ45 port wire first then plug DB9 port wire. -
Page 54: Connecting Adc Power Cord
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual 4.8.2 Connecting a DC power cord 1. DC power supply DC power input range: -48V～-60V DC. 2. DC power supply module DC power supply module appearance is shown in Figure1-18. 3. Connecting a DC power cord Loosen the fastening screw of grounding terminal by using of Phillips screwdriver. -
Page 55: Owering On The Device
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual Chapter 5 Powering on the device 5.1Powering on the device 5.1.1 Construct a configuration environment 1. Connect device to terminal PC Use one end of configuration wire (RJ45) to connect device Console port and use the other end of (DB9) to connect terminal computer. -
Page 56: Figure5-3 Setting The Serial Port Used By The Hyperterminal Connection
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual dropdown menu. The serial port must be the same port connected by the console cable Figure5-3 setting the serial port used by the HyperTerminal connection Set the serial port parameters Table5-1 describes the details of the serial port parameters shown in Figure5-3. -
Page 57: Figure5-4 Serial Port Settings
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual Figure5-4 Serial port settings After you finish configuring serial port parameters, click Ok button, then the HyperTerminal windows popped-up. Chapter 5 Powering on the device... -
Page 58: Figure5-5 Hyperterminal Windows
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual Figure5-5 HyperTerminal windows Select File/Properties/Settings. In the Properties dialog box, select the Settings tab, as shown in Figure 5-6. Select VT100 or Auto detect in the Emulation dropdown menu. Click <OK>. -
Page 59: Powering On The Device
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual Figure5-6 Terminal setup 5.1.2 Powering on the device 1. Verification before power-on Before powering on the device, please verify the followings: Power cords and the grounding cable are correctly connected. -
Page 60: Booting Procedure
Verify whether the terminal PC displays normally. Inspection method: you can view the initial information on terminal PC when you start the device. After that (after self-inspection), press Enter key and configure if <DPtech> displayed. 5.1.3 Booting procedure Powering on your device, PC HyperTerminal displays the device self-inspection information. Then type in the system password and enter the prompt interface. -
Page 61: Default Web Login Method
Here, the default password is “DPTECH”. 5.2 Default Web login method DPX19000 Series product allow administrator login through web management interface. The default IP address is 192.168.0.1. Administrator logins into DPX19000 web management interface and manage the device directly. - Page 62 DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual Figure5-7 WEB management interface Caution: We do not suggest you that use both of the http and https protocol to login on the same PC. We recommended you that you should modify the default password after first login.
-
Page 63: Chapter 6 Troubleshooting
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual Chapter 6 Troubleshooting 6.1 Power system failure Fault phenomenon The PWR LED on main control board front panel is OFF. Troubleshooting The PWR LED on main control board front panel is used for indicating power module operation status. If it is off, power supply module may not work. -
Page 64: Service Board Failure
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual MPU LED is on or flash, which means the device system fault or failure. Troubleshooting Please check the serial port HyperTerminal and management software displayed information (system temperature, MPU board voltage warning information). -
Page 65: Fan Failure
DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual 6.5 Fan failure 1. Fan status LED off Fault phenomenon Fan status LED is off, which means the fan isn’t connected power or hardware failure. Troubleshooting Please check the following: Check whether the device power-on is normal. - Page 66 DPtech DPX19000 Series Deep Service Switching Gateway Installation Manual If terminal display is garbled after you power on the device. Troubleshooting Please verify the HyperTerminal parameters: Baud rate 9600, Data bits-8, Parity-none, Stop bits-1, Flow control-none, Emulation-VT100. If these parameters are not correct, please configure them again.
- Page 67 Chapter 6 Troubleshooting...
