JUST TRAC jt300 User Manual

Your tracker was preconfigured and set-up, it is ready for
operation, you only need to charge the battery and can then
switch on and go.
Tracker Description
Start-up
- Charge the battery using the battery charger and mini-USB
cable supplied. Carefully open the USB rubber weather
proofing port cover to access the USB socket.
- During charging the Power LED will flash fast and when the
battery is fully charged the PWR LED will be solid ON.
- The unit can also be charged using a standard mini-USB
cable and your PC or standard USB power unit.
Note: when using the jt300 for the 1
battery is fully charged.
Device Tracking Service
To track your device using a PC, mobile or any user device just
go to www.justtrac.co.za under registration and sign-up for a
monthly, quarterly or annual service bundle. Once we received
your registration we will set-up a user account and reply with
your login details which will include your email and a default
password.
To view your device, go to "map" tab and select your team and
select all the devices you wish to monitor. To view your riders
on a specific route you need to import the route. To do this go
to "zones" tab and then in the right top select the .gpx upload
button. Browse to the route you wish to import and complete
the process.
Once the route is imported, a small menu will pop-up on the
bottom right, before clicking save, choose the advance option,
then select the group you wish to save the route in, give the
route a name and then click save.
jt300 Personal Tracker User Guide
st
time, please ensure the
Once your route is imported you can view your devices on the
route by selecting the "overlay" button on the map screen and
select "routes" on the "overlay" drop down menu.
See www.justtrac.co.za for more information or contact us on
service@justtrac.co.za or on Facebook.
USER OPERATION
POWER Switch ON:
KEY: Press at least 3 seconds and release to turn on
jt300. The POWER LED will come on. Once the
unit is ready the POWER LED will go OFF for
battery saving.
Switch OFF:
Press at least 2 seconds. The POWER LED will
flash fast and then turn off. Turning off the
jt300 is not possible when being charged.
FUNCTION This is set to SOS mode. Long press the key to
KEY: activate SOS alarm.
MINI USB Connect a 5VDC adapter to power up the jt300
and charge the internal battery.
LED OPERATION
POWER OFF - Jt300 is ready for use if the Power
LED: LED is OFF, GSM slow-flash and
GPS is on (battery saving mode)
- or device is off when no other
LED's are on.
Solid RED Charger is inserted and charging
complete
Fast flash - Charger is inserted and charging
- or Power key was pressed and unit
is shutting down.
- or Abnormal state
Slow flash Power low alert
GSM Slow flash SIM locked and ready
LED:
Fast flash Searching for GSM signal
GPS Solid GPS signal fixed and ready
LED:
Fast flash Getting GPS is signal fix
Slow flash GPS on and GPS data wrong
Dark GPS off
