Benavis YOOSEE Instruction Manual

3d panoramic vr wireless camera alarm system
Hide thumbs

Advertisement

Quick Links

Download this manual
3D Panoramic VR Wireless Camera
BENAVIS 2018
DOCUMENT REV 20180728 REV03
MORE INFO PLS VISIT WWW.BENAVIS.NET


Alarm System

Benavis
More help to visit www.benavis.net
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the YOOSEE and is the answer not in the manual?

Questions and answers

Summary of Contents for Benavis YOOSEE

  • Page 1: Alarm System

    3D Panoramic VR Wireless Camera Alarm System Benavis  More help to visit www.benavis.net  BENAVIS 2018    DOCUMENT REV 20180728 REV03  1  MORE INFO PLS VISIT WWW.BENAVIS.NET   ...

  • Page 2: Product Overview

    Maximum SD card storage 128 GB 2 operation ways to trigger “Arm”: Remote or APP control Night Vision: Infrared night distance is 8 meters Illumination Light function: 500mw pure white light, 2 square meters covering area BENAVIS 2018    DOCUMENT REV 20180728 REV03  2  MORE INFO PLS VISIT WWW.BENAVIS.NET ...
  • Page 3 3). If your home network is 2 lays, eg there are 2 routers, pls use root one to configure the camera. 4). The camera only supports 2.4GHz WiFi, can't support 5GHz. Making sure the WiFi BENAVIS 2018    DOCUMENT REV 20180728 REV03  3  MORE INFO PLS VISIT WWW.BENAVIS.NET ...
  • Page 4 5) If your are going to install camera into ceiling light fixture, pls check if the light cover is metal. Metal housing will affect wifi signal strength. ***If you are not sure about real application, pls contact us at Stonebird.yi@benavis.com.cn www.benavis.net for help. BENAVIS 2018    DOCUMENT REV 20180728 REV03  4  MORE INFO PLS VISIT WWW.BENAVIS.NET   ...

  • Page 5: Installation Procedure

    ‘Yoosee’ app from the Google Play Store Using an Apple device: Install the ‘Yoosee' app from iTunes App Store* Once the app has downloaded and completed installation, launch the app. Go to the website http://www.yoosee.co/ to get the relative files If you need some help pls go to www.benavis.net...
  • Page 6 If this is your first time using Yoosee you will need to create an account. Select “Quick Register” at the middle of the Yoosee login screen and follow the steps to create a new account. Note: If you forget the account number or password, you may simply register another account. Invalid email address is not allowed in account registration.
  • Page 7 C). Add IP Camera Into Your Yoosee Account 1. After login your account, you will see below page, click “+” at the middle of screen or choose upper right corner “+”, APP will go to next page. Please Select Option “Add new Device” at the top of screen.
  • Page 8 2. Then you can see next page, pls choose “Smartlink” option to add your Camera into your account. That means using the sound wave technology to add the camera into your yoosee Account. 3. Then input your wifi SSID and Wireless password here, go to next page and following guideline...
  • Page 9 (C). Make surroundings is clear no very loud noise at the background. (D). Make sure you are using root Wifi SSID to configure it If there are 2 or 3 wireless routers in your home. BENAVIS 2018    DOCUMENT REV 20180728 REV03  9  MORE INFO PLS VISIT WWW.BENAVIS.NET ...
  • Page 10 Note: Default password is one time password, once IP camera is added into your account. That means you are administrator for this camera, you want to share this IP camera with “ ” other people. The receiver needs to download Yoosee APP and register an account also. BENAVIS 2018    DOCUMENT REV 20180728 REV03  10  MORE INFO PLS VISIT WWW.BENAVIS.NET   ...
  • Page 11 BENAVIS 2018    DOCUMENT REV 20180728 REV03  11  MORE INFO PLS VISIT WWW.BENAVIS.NET   ...
  • Page 12 Option#2:”Fast Networking” Operation Process A). Choose “+”, click “Add new device”, select “Fast networking” mode, follow the screen shown and prompt voice reminding “waiting for configuration”, click “Hear a beep for connection” BENAVIS 2018    DOCUMENT REV 20180728 REV03  12  MORE INFO PLS VISIT WWW.BENAVIS.NET   ...
  • Page 13 AP mode, you need to reset camera, try as above procedure. D).If find AP device, click device name, APP will request to you swtich your phone Wifi to this AP GW_AP_xxxxxx. After swtiching Wifi already, APP will pop up paring process and transfer BENAVIS 2018    DOCUMENT REV 20180728 REV03  13 ...
  • Page 14 Some times, you need try 2 times to add it successfully. It \ depends on what kind of phone Ios or Android. So if you failed at 1st time, pls click the Try Again button. “ ”     BENAVIS 2018    DOCUMENT REV 20180728 REV03  14  MORE INFO PLS VISIT WWW.BENAVIS.NET   ...
  • Page 15 PIR motion sensor etc. “Remotely monitored sensor” means remote control, sos bracelet, SOS pendant, or push button. “Special sensor” means smoke detector, gas detector, carbon monoxide detector, or water leakage detectors, which need 24 hours standby. BENAVIS 2018    DOCUMENT REV 20180728 REV03  15 ...
  • Page 16 2. Trigger the sensor twice to emit wireless radio signal, once App pop-ups 'Success', then it's done, then you can see device in that category.   3. Rename the sensor and installation area to conveniently recognize it.     BENAVIS 2018    DOCUMENT REV 20180728 REV03  16  MORE INFO PLS VISIT WWW.BENAVIS.NET   ...
  • Page 17 5. “Motion detection” here means open or off picture motion detection function, the prompt switch is off Note: To receive the alert message, you need make sure that Yoosee APP working on the background always, and give APP permission for sending alert message from mobile phone privilege panel.
  • Page 18 2. Test if system works well: Shake your hands before PIR, you should get alert message. 3. Clik the”X” to close alert on the phone, and use remote control to diarm the system. BENAVIS 2018    DOCUMENT REV 20180728 REV03  18  MORE INFO PLS VISIT WWW.BENAVIS.NET ...
  • Page 19 6). Hang up the PIR and camera where you want to monitor, enjoy it. BENAVIS 2018    DOCUMENT REV 20180728 REV03  19  MORE INFO PLS VISIT WWW.BENAVIS.NET   ...

  • Page 20: App Interface Introduction

    : Edit the device information, rename the device name or delete the camera from your account ② : Camera online or offline status Icon, pay more attention here. ③ : Add the camera: 3 Ways to add the cameras BENAVIS 2018    DOCUMENT REV 20180728 REV03  20  MORE INFO PLS VISIT WWW.BENAVIS.NET   ...
  • Page 21 : Message submenu will show alert message history which is caused by external sensors or picture motion detections under “Arm” status. ⑫ : Your mobile captured image from video feed stream ⑬ : Your Yoosee account info BENAVIS 2018    DOCUMENT REV 20180728 REV03  21  MORE INFO PLS VISIT WWW.BENAVIS.NET ...
  • Page 22 2. Camera Setting Menu Introduction Here Camera's Setting Submenu Device Name: Current Device Name Device ID: Unique ID Yoosee assigned Device information: Check the version of your camera's firmware Time settings: Set the date and time zone of your IP...
  • Page 23 3. Camera View Window Introduction: Camera Viewer  Number of Viewers:  Maximum of 5 viewers can view the same camera live feed at the same  time.  Expand View: Change from portrait to full screen landscape viewing mode    Previous Snapshots: Scroll through and quickly access your previous snapshots.  Speaker: Sound or Mute Intercom: Touch intercom icon to speak with your camera    Snapshot: Press to capture a screenshot and save it directly into your smartphone  Viewing Your Camera  ①  From the ‘Device list’ menu, ensure that the camera’s status is on‐line. Press the large camera image  icon to launch the camera viewer  BENAVIS 2018    DOCUMENT REV 20180728 REV03  23  MORE INFO PLS VISIT WWW.BENAVIS.NET   ...
  • Page 24 ⑩ While viewing your camera feed , use this icon to mute camera mic ⑪ While viewing your camera feed , use this icon to go to camera setting menu to adjust camera parameter BENAVIS 2018    DOCUMENT REV 20180728 REV03  24  MORE INFO PLS VISIT WWW.BENAVIS.NET   ...
  • Page 25 5). Do I need a light function also? The camera LED light is quite weak, just can support 2 square meters area, LED light is pure white. You can manually control the light on or off. BENAVIS 2018    DOCUMENT REV 20180728 REV03  25 ...

  • Page 26: Technical Information

    Once Camera get PIR or Door sensor signal, you can get push message from APP White LED Light Luminous 45~65LM/W Light Color Temperature 6500K Light Power Consumption 500mw LED Light Life Cycle 5,000Hours LED Suitable Area 2 Square meters Alarm BENAVIS 2018    DOCUMENT REV 20180728 REV03  26  MORE INFO PLS VISIT WWW.BENAVIS.NET   ...
  • Page 27 -20 to +60 °C (-4 to +140 °F) Operating humidity 20~80%RH(Non-condensing) Storage humidity 20~95%RH(Non-condensing) Dimensions(W x D x H) Dia. 80X140mm Weight 124g(Main Body) Package Dimension 17x11x9cm Package Weight 324g PC system requirements Operating system Windows Web browser Not Support BENAVIS 2018    DOCUMENT REV 20180728 REV03  27  MORE INFO PLS VISIT WWW.BENAVIS.NET   ...

  • Page 28: Safety Information

     Small parts may cause a choking hazard, keep away from the children  Only use approved Benavis accessory and sensors to get better performance  Do not cover the bulb, infrared lights product heat which may create a fire hazard ...
  • Page 29 This camera is compliant ONVIF standard (2.4 version, Profile S), it can Can the camera work with NVR? work with third-party NVRs & VMS. ONVIF port: 5000; Device discovery port: 3702. It also supports RTSP stream, the RTSP URL address is: BENAVIS 2018    DOCUMENT REV 20180728 REV03  29  MORE INFO PLS VISIT WWW.BENAVIS.NET ...
  • Page 30 Refer to this website: http://www.speedtest.net/mobile Does camera support PC to view and Yes, go to website http://www.yoosee.co/ to down load the CRMclient management? files, reach us to get the instruction files. Does camera support Max OS View and No, but you download VLC and play URL the streams.
  • Page 31 "Sou" and “reset to default setting” How to rest the camera? tone. Once the camera keeps making "di, di, di" and “waiting for configuration” sound, then you can start to add the camera via “Smartlink” or “Fast networking” BENAVIS 2018    DOCUMENT REV 20180728 REV03  31  MORE INFO PLS VISIT WWW.BENAVIS.NET   ...
