Summary of Contents for Vido WD010220850
- Page 1 WD010220750 WD010220850 750W/850W...
- Page 2 WD010220750/WD020220850 Thank you for purchasing a VIDO product. We are confident that you will appreciate the quality of the product and you will be entirely satisfied with your purchase. Please read carefully the user safety and operating instruction on how to operate this product correctly within safety...
- Page 3 WD010220750/WD020220850...
-
Page 4: Component List
750W/850W IMPACT DRILL COMPONENT LIST 1) Chuck 2) Depth gauge 3) Drill/impact action selector switch 4) Lock on button 5) Switch trigger 6) Variable speed control 7) Forward/reverse rotation selector switch 8) Auxiliary handle NORMAL ACCESSORIES 1) Auxiliary handle: 2) Depth gauge: 3) Chuck key: 4) Spare carbon brush: 1set... -
Page 5: General Power Tool Safety Warnings
750W/850W IMPACT DRILL GENERAL POWER TOOL SAFETY WARNINGS Warning: Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term "power tool"... - Page 6 750W/850W IMPACT DRILL of the power tool in unexpected situations. f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
-
Page 7: Double Insulation
750W/850W IMPACT DRILL possible. Holding the work by hand or against your body is unstable and may lead to loss of control. Do not use damaged or worn drill bits. Make sure drill bit are tightened securely in chuck. Do not start the drill with the chuck key in chuck. 10) Be sure no one is below when using the tool in high locations. -
Page 8: Technical Data
750W/850W IMPACT DRILL TECHNICAL DATA Model WD010220750 WD010220850 Voltage -120V AC 220-240V AC -120V AC 220-240V AC Frequency 50-60Hz 50-60Hz 50-60Hz 50-60Hz Power input 750W 750W 850W 850W No load speed 0-2800/min 0-2800/min 0-2800/min 0-2800/min Impact rate 0-44800/min 0-44800/min 0-44800/min 0-44800/min 1/2″... -
Page 9: Operating Instructions
750W/850W IMPACT DRILL OPERATING INSTRUCTIONS NOTE: Before using the power tool, read the instruction manual carefully. 1. Intended use The machine is intended for impact drilling in brick, concrete and stone as well as for drilling in wood, metal and plastic. Machines with electronic control and right/left rotation are also suitable for screwdriving and thread-cutting. -
Page 10: Maintenance
750W/850W IMPACT DRILL Adjust the variable speed control to increase or decrease the speed according to the material and accessory to be used. Turn the variable speed control in clockwise direction to increase speed and in anticlockwise direction to decrease speed (See Fig 5). High speed gives higher torque and low speed will provide low torque. -
Page 11: Troubleshooting
750W/850W IMPACT DRILL 2. Never use water or chemical cleaners to clean your power tool. Wipe clean with a dry cloth. 3. Your power tool requires no additional lubrication. 4. Always store your power tool in a dry place. 5. If you see some sparks flashing in the ventilation slots, this is normal and will not damage your power tool. - Page 12 750W/850W IMPACT DRILL EXPLOSIVE VIEW OF WD010220750...
- Page 13 750W/850W IMPACT DRILL PART LIST OF WD0102 20750 DESCRIPTION Q’TY DESCRIPTION Q’TY Left head screw Rotor Chuck Cap of brush holder Output spindle Carbon brush Steel ball Brush holder Dust cover Stator Bearing Left housing Circlip Switch Gear Right housing Circlip Screw Spring...
- Page 14 750W/850W IMPACT DRILL EXPLOSIVE VIEW OF WD010220850...
- Page 15 750W/850W IMPACT DRILL PART LIST OF WD010220850 DESCRIPTION Q’TY DESCRIPTION Q’TY Left head screw Bearing Chuck Rotor Output spindle Carbon brush Steel ball Brush holder with spring Dust cover Stator Bearing Left housing Circlip Switch Gear Right housing Circlip Screw...
- Page 16 MADE IN CHINA Copyright @ WIDO Machinery Co., Ltd. All rights reserved. www.widopt.com...
