König FTA DVB-T SCART receiver Manual page 2

FTA DVB-T SCART receiver
1. Connections
(Product options)
1. SCART
ANT IN: CONNECTTOANTENNA
2. SCART 180"
Antenna out
infrared cable
position
ENGLISH
POWER
CONNECTTO
DC + 5V
INFRARED RECEIVER
POWER
DC + 5V
After connecting the SCART to your TV please be sure to select from
your TV remote control the key that allow you to select SCART source
(could be "AV" or "source" or "INPUT" or "SCART").
2
CONNECTTO
INFRARED RECEIVER
ANT IN: CONNECTTOANTENNA
