Ltech LT-874 Series Manual

2.4G Wireless DMX512 transceiver
LT-874-5A 4CH CV DMX decoder with OLED display, receiving standard DMX512 protocol data wirelessly. use with
our LT-870 wireless transmitter, supporting point to point, point to multi-point Network structure. A transmitter can
configure multiple receivers as long as they use the same frequency, self-testing function also available.
Adopt 2.4GHZ global open ISM frequency channel, 64 groups wireless network can be chosen independently to
avoid interference.
use relay settings or connect to Booster Antenna to further the communication distance.
1. Technical Specs:
LT-874-5A
Matched Wirless Transmitter:
LT-870
Receiving Wireless Signal:
DMX512
Input Voltage:
DC5V-DC24V
Max Load Current:
5A×4CH Max 20A
Max Output Power:
100W/240W/480W/(5V/12V/24V)
Working Frequency Channel:
2.4GHz ISM 64 channels
Receiver Sensitivity:
-96dBm
2. Product Size:
175mm
170mm
LT-874
Communication Distance:
350m
Working Temperature:
-20
Dimension:
L175×W44×H30mm
Package Size:
L178×W48×H33mm
Weight (G.W):
120g
1
3. Configuration Diagram:
Running Light
( Turns on when
connect to power supply)
DIP Switch
RX LED indicator light
flashed In data transmission
3. OLED Screen Interface Diagram:
DMX Address
DMX R e l a -
R
Please refer to the OLED display for the detailed information.
LT-874-5A will run the test scenes only when you enter "self-test" interface.
Screensaver enable time: undo for 2 min in the main display interface (Figure 1).
℃～ 55 ℃ [ estore the default parameters ： R
simultaneously, LT 874 5A will restore the default parameters, and the screen display -
then it will return to the main display interface Figure 1
5. Dip Switch Operation:
Dip Switch( 1st to 6th)
DIP 1
Value 001
Frequency value = the total place value amount of 1-6 dip switch+2400,
put the dip switch to ON position, user can get its place value,
Remark
put dip switch to OFF position, its place value is 0.
Example, As figure 1, the repeater frequency is 2437M, set the 1st, 3rd , 6th dip switch to "1", the rest to "0",
the Value summation from 1-6 is 1+4+32=37, so the repeater frequency is 37+2400=2437M.
OLED Screen
512
M
Function Key
DMX Address:001 DMX Address:001
1: 65535 2: 65535 CH1: 255 CH2: 255
i t m e D a a t
3: 65535 4: 65535 CH3: 255 CH4: 255
e s l o t u o i n
Resolution:16bit RES:8bit Gamma
Figure 1 A Main Display Interface Figure 1 B
Press M key to enter " " Press "M" key, switch entries.
the setting interface
Press " " or " " key, adjust parameters.
DMX Address:001
DMX Setup
Long press "M" key, return to the main
Test
System Exit
display interface(Figure 1).
Exit Return to the previous menu.
] In the main display interface( Figure 1)，Long press "M"
-
( ).
: 64 frequency option(2401-2464MHz), Frequency interval: 1MHz (As following table).
2 3 4
002 004 008 016
2
LED Lamp
Connection Socket
DC5V 24V ~
Power Input Socket
DMX Address
D M X Real time Data -
R e s l o t u o i n i D m m n i g C u v r e
∧ ∨
:
/" ∧"/"∨" 3 keys
"Device restore default" for 2s,
5
6
ON DIP
032
1 2 3 4 5 6
( )
Figure 2
