8.

MISCELLANEOUS DRYER DATA

Capacity Correction Factory

All dryer ratings shown are at 100ºF inlet temperature,
100ºF ambient temperature, 100 PSIG inlet pressure. To
correct for different conditions, use Table A, B, C, and D.

Correction Formula:

New Capacity SCFM = (Cat. Rating SCFM) x (A) x (B) x (C) x
(D)
Example: What is the new rating for a Model 3000 at:
(A) Operating PSI of 100 PSIG
(B) Ambient Temperature of 90ºF.
(C) Inlet air temperature of 110ºF. and
(D) Dew point of 35 - 39ºF
Answer:
(SCFM) = 3000 x (1) x (1.05) x (.83) x 1 = 2614.5 SCFM
Airtek 4087 Walden Avenue, Lancaster, NY 14086 TEL: (716) 685-4040 FAX: (716) 685-1010 E-MAIL: airtek@airtek.com

Inlet Air Pressure Correction

A
PSI 50
Factor 0.8
Ambient Air Temperature Correction
B
Temp. ºF 90
Factor 1.05
Inlet Air Temperature Correction
C
Temp. ºF 80
Factor 1.5
Dew Point Correction Factors
D
Dew Point 35ºF - 39ºF
Factor 1
75 100 125 150
0.9 1 1.02 1.05
100 110 --- ----
1 0.9 --- ---
90 100 110 120
1.22 1 .83 .69
42ºF - 45ºF 50ºF
1.10 1.25
