ASSEMBLY, DISASSEMBLY,
AND USER INSTRUCTIONS

D040373A

Advertisement

loading
Need help?

Need help?

Do you have a question about the Altitude Steel 250 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Duarib Altitude Steel 250 Series

  • Page 1 D040373A HEAD OFFICE  Route de la Limouzière – BP 41  44310 – Saint Philbert de Grand Lieu  Phone: +33 (0)2 40 78 97 22  Fax: +33 (0)2 40 78 78 71  Mail: welcome@duarib.fr  Compliant with NF norm EN 1004  Compliant with 01/09/04 decree  ASSEMBLY, DISASSEMBLY,  AND USER INSTRUCTIONS  ...
  • Page 2: Assembly And Use Instructions

    ASSEMBLY AND USE INSTRUCTIONS D040373A LOADING CONDITIONS NF EN1004 - 3 – 6,8/6,8 – D Rolling Floor: maximum allowed load spread over the Follow the assembly and use instructions floor = 140 kg Access type Whole scaffolding: maximum allowed load spread over the floors = 400 kg Maximum height for outdoor/indoor use...
  • Page 3 D040373A 11110 11106 Sabilizer's position according number of rungs. 11107 Example: 6th 1400 mm 11113 1570 mm 11116 Stabilizer A min. dimensions 11105 Size in mm Anchoring point of the stabilizers to the Code Hauteur rung, starting at the plancher bottom 11152 1,7 m...
  • Page 4 ASSEMBLY AND USE INSTRUCTIONS D040373A NF EN1004 - 3 – 6,8/6,8 – D Rolling LOADING CONDITIONS Follow the assembly and use instructions Floor: Maximum allowed load spread over the floor = 190 Kg Access type Whole scaffolding: Maximum allowed load spread over the floors = 500 Kg Maximum height for outdoor/indoor use...
  • Page 5 D040373A 11111 11106 Sabilizer's position according number of rungs. Example: 6th 11108 1800 mm 11114 1970 mm 11116 Stabilizer A min. dimensions 11105 Size in mm Anchoring point of the stabilizers to the rung, Code Floor starting at the bottom height 11202 1,8 m...
  • Page 6 ASSEMBLY AND USE INSTRUCTIONS D040373A NF EN1004 - 3 – 6,8/6,8 – D Rolling LOADING CONDITIONS Floor: Maximum allowed load spread over the Follow the assembly and use instructions floor = 240 Kg Access type Whole scaffolding: Maximum allowed load spread over the floors = 500 Kg Maximum height for outdoor/indoor use...
  • Page 7 D040373A 11112 11106 Sabilizer's position according number of rungs. Example: 6th 11109 2250 mm 11115 2420 mm 11116 Stabilizer A min. dimensions 11105 Size in mm anchoring point of the stabilizers to the rung, Code Floor starting at the bottom height 11252 1,8 m...
  • Page 8 D040373A DUARIB PATENT Base body assembly Set the ladder perpendicular to the base body, Hang the base body on a ladder by setting it on a without forcing, then set the pins. rung, while the ladder is slightly tilted. The screeds of the base body must wrap around the ladder's upright.
  • Page 9 D040373A DUARIB PATENT Brace's safe assembly Brace's safe assembly: Hang the other end of the brace by opening the lock From a distance, hang the brace's upper part. slightly. Check the lock is properly set. Check the lock is properly set.
  • Page 10 D040373A DUARIB Safety rail's safe assembly PATENT Safe assembly of the safety rail with the brace: Hang one end of the Hang the brace to the Use the brace as a Set the brace close to safety rail by wrapping...
  • Page 11 D040373A DUARIB Floor's safe assembly PATENT Insert the floor with its locks open in the scaffolding at Set the floor's extremities one after the other to reach the first height possible without trying to set it at work the proper work height.
  • Page 12 D040373A DUARIB Stabilizer's safe assembly PATENT Move the stabilizer closer and vertically to the Tilt the stabilizer ladder's upright. Hang the upper end to the rung, as advised by this user guide on page 3, 5 or 7. Lower the brace horizontally and tighten the collar.
  • Page 13: Assembly Steps

    D040373A Assembly steps Insert the wheels on the 2m ladder. Hang the base body to a ladder by setting it on a Set the pin so the assembly holds together. rung, with the ladder slightly tilted. The base body Lock the wheels for the next steps of the assembly. screeds must wrap around the ladder's uprights.
  • Page 14 D040373A Hang one end of the safety rail by wrapping around Joint the upper ladders the upright from the outside. Hang the brace to the safety rail by inserting the Bring the upright's brace closer and the safety rail hook in the hole. Use the brace as a pole to install will be set on the ladder's rung.
  • Page 15 D040373A Set the floor's extremities one after the other to Set the floor horizontally to the work height and reach the proper work height. set the locks of the floor's lift-off protection. The hooks' sliding ramps allow for a tilted orientation of the floor Move the stabilizer vertically closer to the ladder's Tilt the stabilizer...
  • Page 16 D040373A Assembly on a difference in height For an assembly on a difference in level, you must link the ladder’s first rungs together with braces, as shown on the below schematic. The base body must be set horizontally on the first rung of the ladder assembled on top of the difference in level.
  • Page 17 Special case: Anchors assembly D040373A Amarrage With a wind speed superior to 45 kmph, it is mandatory to either disassemble or anchor it at the top. If you chose to anchor:  Set the stabilizers according to the below picture ...
  • Page 18 Special case: Support assembly D040373A Supporting bar Here are some ways to guarantee the scaffolding's stability when mounted in front of a building:  Set the stabilizers according to the below picture  Add 2 support bars on the upper end (one on each vertical upright) ...
  • Page 19: Safety Measures

    Safety measures D040373A  It is forbidden to move a scaffolding that has a rolling bridge, a crane or handling equipment.  the moving area must be free of obstacles.  The scaffolding can only be manually moved on solid ground (for a loose ground, plan a roll out walkway), free of personnel or tools, with the space between stabilizers and the ground being very low.
  • Page 20 Safety measures D040373A  Assembly and disassembly must be performed by operators who have been trained in assembly and security instructions.  Only use parts in good condition we have manufactured and are referenced in the nomenclature.  For any use not compliant to the user guide, please contact the manufacturer. ...

This manual is also suitable for:

Altitude steel 200 seriesAltitude steel 150 series
