Summary of Contents for BENE P2
- Page 1 P2 MONITOR LIFT SAFETY AND OPERATING INSTRUCTIONS NOTE Please read all instructions carefully before operating the system. Keep instruction manualfor further reference. This document is alternative available on the official Bene - homepage. (www.bene.com)
-
Page 2: Table Of Contents
CONTENTS Contents ......... 2 Product overview ......3 Safety instructions ......5 Troubleshooting ....... 8 Capacitive manual switch ....9 Cleaning instructions. Certificates ... 10 Notes ........... 11... -
Page 3: Product Overview
PRODUCT OVERVIEW Flatscreen holder Monitor support Dual flap Compact control Lifting mechanism Capacitive manual switch Swivel unit Motor cable Connecting cable for the monitor Column sensor Power cable Column safety sensors... - Page 4 PRODUCT OVERVIEW P2 with slab-end P2 with sideboard...
-
Page 5: Safety Instructions
SAFETY INSTRUCTIONS Please observe the safety instructions! 7. Ensure that the safety distances are 25 Improper operation of the system may mm for movable parts (this also applies result in personal injury and cause for organisational elements which are damage to objects! fitted above or underneath the furniture, mounted to adjoining walls or building 1. - Page 6 SAFETY INSTRUCTIONS 12. Only professionals authorised by the Plugs and connection plug boards must manufacturer may do maintenance or be located in such a way that no fluids repair any electrical equipment. come into contact with electrical equipment when the office furniture is 13.
- Page 7 SAFETY INSTRUCTIONS 21. Do not spill liquids into the control unit Please take care to avoid the possible or power supply unit, as this could cause danger of crushin. electrical shock or short circuits. Warning: During all reset procedures 22. The operation of the control mechanism (section 5) the collision protection is and the power supply unit requires a not active.
-
Page 8: Troubleshooting
TROUBLESHOOTING 1. CONTROL UNIT FAILS TO OPERATE; GENERAL INSPECTION 3. LIFT MECHANISM DROPS DOWN If the manually operated switch does not work and the The lift mechanism stops during operation and drops down controls do not beep, you need to check the following: a few mm in the opposite direction. -
Page 9: Capacitive Manual Switch
CAPACITIVE MANUAL SWITCH The capacitive manual control switch is operated by touching AUTOMATICALLY TURNING THE MONITOR ON AND OFF: the wood surface directly in front of the lift column flap. Connect the coupler provided in the assembly package to the Before starting the system, you must reset the control unit. -
Page 10: Cleaning Instructions. Certificates
DISPOSAL surface is difficult to prevent. Never use polishes contain- Instructions for the disposal of Bene products can be found in ing silicon, caustic cleaning agents with ammonia additives, the sustainability report at: http://www.bene.com... -
Page 11: Notes
NOTES .............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................. - Page 12 Bene plays a leading role in responsible environmental management. It is practiced throughout all company divisions -from product development, procurement, production and logistics to product recycling. Bene considers ecology to be a central element of its responsible and sustainable corporate strategy. Bene sees the legal regulations as minimum requirements and strives for better and more sustainable environmental protection throughout the group.
