Easy Obelisk
Assembly Instructions
Components Supplied
Ref Description
A
Top curved
tubes
B
Central leg
tubes
C
Lower leg
tubes
D
Rings
E
Finial
F
Assembly
screws
G
Finial retaining
screw
Consumer Helpline
If you have any problems or queries with
this product then please contact our
helpline number: 01406 372227,
or write to: Gardman Ltd. High Street,
Moulton, Spalding, Lincs, PE12 6QD.
Fax: +44 (0) 1406 372233.
Illustration
Qty
3
3
3
3
1
15
1
Tools Required (not supplied)
Phillips cross-head screwdriver
Mallet
Tape Measure
Before You Start
• Layout all of the component parts and
make sure you have all of the parts listed.
• When you are ready to start, make sure
that you have the right tools to hand,
plenty of space and a clean dry area for
assembly. Always try to assemble the
product as close as possible to the
intended location.
• Remove all plastic bags and dispose of
safely.
• Retain the instructions for future use.
Caution
This pack contains small items which should
be kept away from children.
07701
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Gardman Easy Obelisk
Summary of Contents for Gardman Easy Obelisk
- Page 1 Finial retaining screw Consumer Helpline If you have any problems or queries with this product then please contact our helpline number: 01406 372227, or write to: Gardman Ltd. High Street, Moulton, Spalding, Lincs, PE12 6QD. Fax: +44 (0) 1406 372233.
- Page 2 Assembly Helpful hints: You may find it easier to assemble your obelisk horizontally on its side and then carefully stand it upright to install. If the screw holes on the poles are covered with a thin layer of the protective coating, carefully remove this by pushing a small nail through the coating.
